LED Warning Light Head
XA302 Warning Light Head Grill Light
XA302 Warning Light Head Grill Light XA302 series high performance warning lamps are universal fit all cars, SUV, vans and trucks, motorcyle
View specifications
What this lamp is for
XA301 series warning light head are universal fit all cars, SUV, vans and trucks, motorcyles with DC 12V-24V. There are different power ranges(1W/3W/6W) and colors(single/split/dual) available for satisfying various warning requirements. Meet the standards of ECE R10/ECE R65 Class 1/SAE J595 Class1/California Title 13 Class B 6 pcs high intensity LEDs ensure consistent performance, low current draw.
- XA301 series warning light head are universal fit all cars, SUV, vans and trucks, motorcyles with DC 12V-24V. There are different power ranges(1W/3W/6W) and colors(single/split/dual) available for satisfying various warning requirements.
- 12.3mm thick lamp body.
- Meet the standards of ECE R10/ECE R65 Class 1/SAE J595 Class1/California Title 13 Class B
- 6 pcs high intensity LEDs ensure consistent performance, low current draw.
- Fully encapsulated for moisture, vibration and corrosion resistance.
- Aluminum die-cast housing provides excellent heat dissipation.
Specification table
Values below are transcribed from the original Katuo product page.
| Approvals | ECE R10(EMC), ECE R65 Class 1/Class 2, SAE J595 Class 1/Class 2, California Title 13 Class B |
|---|---|
| LEDs | 6 pcs*1W/6 pcs*3W/12 pcs*3W |
| Colors | Amber/Red/Blue/Amber+Red/Amber+Blue/Red+Blue |
| Operating Voltage | 12/24V |
| Operating temperature | -40℃~ +65℃ |
| Wires | Red: Positive(+) |
| Cable length | 300mm |
| Lens | Clear PC |
| Housing | AL Die-cast |
| Mounting | Screw |
| Waterproof | IP67 |
| Net Weight | 80g/pc |
| Packing | Inner box: 140x35x55mm; Outer box: 290x190x290mm; Qty.: 50 Pcs/Carton |
Questions buyers actually ask
What markings are listed on XA301 Warning Light Head/Grill Light?
The source spec table prints: ECE R10(EMC), ECE R65 Class 1/Class 2, SAE J595 Class 1/Class 2, California Title 13 Class B. Confirm color and length before treating that string as valid for every option.
What voltage does XA301 Warning Light Head/Grill Light accept?
Operating voltage on the listing is 12/24V.
What ingress rating is printed?
IP67. That rating applies to the assembled lamp as shipped.
How does it mount?
Mounting options listed: Screw.
