Home/Products/Brushed Stainless Steel Sign Letters/Brushed Stainless Steel Relief Lettering Ref 124
Brushed Stainless Steel · Relief Lettering
Brushed Stainless Steel Relief Lettering Ref 124
Built in stainless 304 or 316 — the grade is your call, not a default.
Reference 124 as photographed in our Shenzhen workshop before packing.
Product Overview
What Ref 124 Actually Is
Reference 124 is a full built-up lettering set, fabricated as one job so stroke weight and return depth stay identical across every character, made in brushed stainless steel with a directional satin grain. It is not a stock item. The photograph shows one set we built; what you receive is the same construction cut to your own letters, your own height and your own colour.
A brushed grain scatters reflections instead of mirroring them, so the letter reads as a solid shape from across a forecourt and fingerprints from installation do not sit on the face.
Letters are computer-cut for precision, fully welded, and painted to the PMS or RAL reference you supply.
- Construction
- Relief Lettering
- Material
- Brushed Stainless Steel
- From
- 6 mm thick, 40 mm high
- Lead time
- 5 to 7 days
Key Benefits
Why Buyers Specify This Build
Four things reference 124 gives you that a generic letter order does not.
Specified once, repeatable later
The build is written down — grade, thickness, return depth, finish, fixing — so a second store or a replacement character matches the first without a new conversation.
No redraw of your artwork
We cut from the vector file you send. Nothing is traced, so stroke weights and letter spacing survive the trip to the workshop.
One finish across the set
Face and returns are finished together after welding, so the grain runs the same way on every character.
Installs without a specialist crew
A 1:1 template, pre-welded studs and a flat-packed kit mean a general fitter can set the job out and hang it the same day.
The same construction installed on site — depth, finish and fixing carried over unchanged.
Application Scenarios
Where This Reference Belongs
Retail frontages, reception walls, building entrances and boundary walls.
Who it is for. Sign contractors and fit-out companies buying letter sets to install themselves, brand owners rolling an identity across several sites, and architects specifying lettering as part of a facade package.
The problem it solves. A flat vinyl or printed name has no depth, so it flattens out under facade lighting and reads as signage rather than as architecture.
- Restaurants and Hospitality — Letters that photograph well in low light — the sign ends up in every customer photo.
- Corporate Offices and Headquarters — Reception and facade lettering held to the brand sheet, not to a sign shop's interpretation.
Manufacturing Process
How Ref 124 Is Made
The same four stages run on every set, which is what makes a repeat order match the first one.
Artwork stage
Artwork is redrawn as cutting paths and the face is cut from 6 mm or thicker plate
Returns stage
Returns are formed to the depth you specify and welded to the face all round
Welds stage
Welds are ground back and the whole letter is finished to a single grain or polish
Studs stage
Studs are welded to the back and a 1:1 template is drilled from the same file
LED modules and power supplies used in our illuminated letters are CE, RoHS and UL approved.
Specifications
Technical Specification
Every value below comes from the build specification for this catalogue. Anything we cannot evidence is marked TBC rather than filled in with a plausible number.
| Reference | Ref 124 |
|---|---|
| Construction | Relief Lettering |
| Material | Brushed Stainless Steel |
| Stainless grade | 304 or 316 on request |
| Minimum thickness | 6 mm |
| Minimum letter height | 40 mm |
| Surface finish | A directional satin grain |
| Colour | Bare metal, or lacquered to any RAL or Pantone reference |
| Illumination | Optional — direct (front-lit) or indirect (halo) |
| Mounting | Pre-welded studs with a 1:1 paper template |
| Packing | Individually wrapped, packed flat as an installation kit |
| Lead time | 5 to 7 days fabrication, 4 to 5 days express transit |
| Shipping | DHL, UPS or FedEx; sea or air freight for larger orders |
| Payment | T/T, PayPal or Western Union |
| Minimum order quantity | TBC — confirmed with your quotation |
| Warranty | TBC — confirmed in writing with your quotation |
Materials and Quality Control
Material and Finish Notes
Grade 316 is the sensible choice within a few kilometres of the sea; 304 covers ordinary inland exposure.
Welds are ground back before the finish is applied, so the grain or polish runs across the joint rather than stopping at it. Faces are checked against the approval drawing for letter spacing and stroke weight before packing.
Letters are checked against the approval drawing before they are wrapped.
Certifications
LED modules and power supplies used in our illuminated letters are CE, RoHS and UL approved. Certification of the metalwork itself is TBC — ask for current documentation with your quotation.
Comparison
How This Compares With the Alternatives
| Build | What it is | Where it wins |
|---|---|---|
| Built-up relief letter | Face plus welded returns | Depth and shadow on a flat facade |
| Fabricated box letter | Closed deeper shell | Anywhere LED modules have to live inside the letter |
| Flat-cut letter | Single plate, cut through | Reachable positions, numbers and plaques |
| Printed or vinyl lettering | Applied film | Short-term promotion, not permanent identification |
Customization
What You Can Change
Artwork
Any typeface, any logo, any language. We cut from your vector file rather than redrawing it.
Size and depth
Letter height from 40 mm upward, material from 6 mm upward, return depth set to suit the fixing and any lighting.
Finish and light
Bare metal, or lacquered to your RAL or Pantone reference; unlit, halo-lit or front-lit.
Related Products
Other References in This Range
Ref 123Brushed Stainless Steel Box Letter Ref 123
Box Letter in brushed stainless steel
View reference →
Ref 122Brushed Stainless Steel Relief Letter Ref 122
Relief Letter in brushed stainless steel
View reference →
Ref 121Brushed Stainless Steel Relief Letter Ref 121
Relief Letter in brushed stainless steel
View reference →
Ref 219Mirror Polished Stainless Steel Box Letter Ref 219
Box Letter in mirror polished stainless steel
View reference →Related Reading
Guides That Cover This Build
Answers
Questions About Ref 124
The points buyers usually raise before ordering a relief lettering set.
Is there a warranty on the letters?
TBC — warranty terms are not stated in the material this catalogue was built from. Please confirm them in writing with your quotation.
What lead time should we plan for?
5 to 7 days for fabrication and a further 4 to 5 days in transit by DHL, UPS or FedEx. Sea and air freight are available for larger orders.
Do you quote installation as well?
We manufacture and ship; installation is carried out by your own fitter or a local sign contractor. The 1:1 template and pre-welded studs are what make that straightforward.
Can you match our brand colour?
Yes. Letters can be lacquered in any colour — send the RAL or Pantone reference and we match to it rather than to a colour name.
Can you supply a mixed set of materials?
Yes. A logo in one material next to lettering in another is built as a single assembly so the alignment is set in the workshop, not on the wall.
How thick are the letters?
Material starts at 6 mm and goes thicker on request. The right thickness depends on letter height and how close people get to the sign.
Send Your Artwork for Ref 124
Quote the letter height and the colour reference and we will come back with a drawing, a price and a ship date.
