Cargo Trucks

China Water Watering Sprinkler Prices

It features a WD615.62 diesel engine, HW13710 manual transmission, and HF7 front/HW1279 rear axles. The truck is designed for road maintenance, landscaping, and dust suppression, with a maximum watering width of 14m and a jet range of 28m.

Condition New
Actual Volume 20 m3
Total Weight 25000 kg
Rated Loading Weight 14370 kg
Curb Weight 10500 kg

Ask for a Price on WhatsApp Email the Specification

Stock number held for this listing: 10050

White HOWO water sprinkler truck, side view

Key Benefits

What This Unit Does Well

20m3 tank capacity reduces refill stops on long routes
WD615.62 engine is widely available, simplifying parts sourcing
HW13710 transmission offers ten forward gears for varied terrain
Hydraulically tiltable body allows for easy access to the tank interior
Multiple spray options (front, back, side, cannon) provide versatility

Application Scenarios

Where It Is Used

Road construction and maintenance for dust control and compaction
Landscaping and agricultural applications for irrigation and spraying
Municipal services for street cleaning and park maintenance
Mining operations for dust suppression and material wetting
Emergency services for fire fighting support

Fit

Who It Is For

Municipal road maintenance departments needing a reliable water truck
Construction companies requiring on-site dust and soil stabilisation
Landscaping businesses needing a mobile water supply for irrigation
Mining operations looking for dust suppression solutions
Fire departments needing additional water capacity for emergency response

Buyer Pain

Problems It Solves

Frequent water refills slowing down road maintenance schedules
High dust levels causing visibility issues and health hazards
Lack of versatile spraying options for different applications
Difficult access to the tank for cleaning and maintenance
Dependence on unreliable water sources during road projects

Engineering

Technical Features

WD615.62 diesel engine meeting EURO II emission standards
HW13710 manual transmission with 10 forward and 2 reverse gears
HF7 front axle and HW1279 rear axle
20m3 water tank with multiple spray options
Hydraulically tiltable body for easy access
ZF8098 steering system

Specification

Specification Table for This Listing

Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.

Specification of China Water Watering Sprinkler Prices
Condition	New
Actual Volume	20 m3
Total Weight	25000 kg
Rated Loading Weight	14370 kg
Curb Weight	10500 kg
Dimensions L x W x H	9920 x 2490 x 3140 mm
Wheelbase	4550+1350 mm
Front Tread	1939 mm
Rear Tread	1958 mm
Approach/Departure Angle	20.5/13°
Engine Model	WD615.62
Fuel Type	Diesel
Emission	EURO II
Transmission	HW13710, 10 forward / 2 reverse
Front Axle	HF7
Rear Axle	HW1279
Tyre Size	295/80R22.5
Tyre Quantity	10+1
Air Displacement/Power	9726 L / 266 ps
Max. Speed	90 km/h
Transmission Type	Manual
Place of Origin	Shandong, China (Mainland)

Materials

Materials and Build

Steel water tank with anti-corrosion coating
Cast steel HF7 front and HW1279 rear axle housings
295/80R22.5 radial tyres on steel rims

Process

How an Order Is Handled

You specify the required tank capacity, spray options and chassis configuration
We confirm availability and pricing based on current stock or plant build schedule
You confirm the final specification sheet and provide a deposit
The unit is prepared, inspected and photographed before loading
We arrange RoRo or container shipment and provide export documentation

Quality Control

Checks Before Loading

Chassis number and engine serial number are verified against the order sheet
Water pump operation and spray nozzle function are tested before loading
Tank integrity and weld quality are visually inspected
Loading photos are provided before the vessel departs

Customisation

What Can Be Changed

Tank material (carbon steel or stainless steel)
Spray nozzle type and arrangement
Additional accessories such as a rear working platform
Paint colour and livery
Optional side protection bars

Honest Comparison

How It Compares With the Alternatives

Smaller 10m3 water tanker	A 20m3 tank reduces refill frequency, increasing productivity but adds to the initial cost
PTO-driven water pump	Dedicated pump provides consistent pressure and flow, but adds complexity and maintenance
Rear spray bar only	Multiple spray options offer greater versatility but increase system complexity

Use Guide

Using It Well

Check water pump pressure and spray nozzle condition regularly
Drain the tank completely before freezing temperatures to prevent damage
Inspect hoses and fittings for leaks or wear
Lubricate moving parts according to the maintenance schedule
Use appropriate cleaning agents to prevent corrosion inside the tank

Photographs

More Views of This Unit

Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.

Rear view of the water sprinkler showing the spray nozzles

Close-up of the water cannon on the sprinkler truck

Front view of the HOWO water sprinkler truck

Water pump and controls inside the sprinkler truck

Source Specification

Manufacturer Text We Hold for This Listing

China water watering sprinkler prices Technical Parameter Item unit specification Name HOWO Classis model ZZ 5 257M4647 Actual volume M3 20 Total weight kg 25000 rated loading weight 14370 Curb weight 10500 truck size mm 9920 x 2490 x3140 wheelbase 4550+1350 tread Front wheel 1939 Back wheel 1958 approach angle/departure angle ° 20.5/13 tire qity 11 pcs air displacement /power L / ps 9726 / 266 Max. speed km / h 90 Engine WD615.62 Fuel type Diesel Emission EURO II Transimssion HW13710 10 forwards and 2 reverse Front axle HF7 Rear axle HW1279 Steering system ZF8098 Color Optional Tyre 295/80R22.5 Tyre quantity 10pcs +1 spare Electrical system Battery 2X12V/165Ah Alternator 28V-1500kw Starter 7.5Kw/24V Cab HW76 with air conditioner and sleeper, all-steel forward control, 55° Hydraulically tiltable to the front, 2 arm windscreen wiper system with speeds, laminated windscreen with casted in

Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
