16Ton Chinese 4x2 Hook Lift Garbage Truck
A 4x2 Sinotruk HOWO hook lift garbage truck with a 16-ton payload capacity, built on a DongFeng, FAW, Foton, Sino, JAC or Shacman chassis, powered by a Weichai diesel engine, rated at EURO 4 emission standard, with a manual transmission and a 12.00R20 tyre configuration. The unit features a fully sealed compaction tank that directs waste water into a slop tank to prevent secondary pollution, and includes a computer-controlled hydraulic system for automated loading and unloading. It is designed for municipal and private waste collection in urban and semi-urban environments where space and access are limited.
- Condition New
- Truck Model HOWO
- Drive Wheel 4x2
- Dimensions L x W x H unloaded 10510 x 2550 x 3520 mm
- Wheelbase 4350+1350 mm
Stock number held for this listing: 10077-1-2-1-2-1-1-2
Key Benefits
What This Unit Does Well
- Fully sealed tank and slop tank system prevents leakage and secondary pollution during transport
- Computer-controlled hydraulic system enables semi- or fully automated loading and unloading with minimal operator effort
- 16-ton payload capacity allows for double the load of non-compacting trucks of similar weight class
- Manual transmission with high reduction ratio improves performance under heavy load on inclines
- EURO 4 emission standard ensures compliance with most international waste transport regulations
- Hook lift mechanism allows quick and safe container exchange without manual lifting
Application Scenarios
Where It Is Used
- Daily collection of municipal waste in narrow city streets with limited turning radius
- Private waste hauling for industrial sites where container exchange must be fast and efficient
- Contractor operations in construction zones where debris and mixed waste must be compacted before transport
- Municipal fleet expansion where reducing the number of trips per day is critical for cost control
Fit
Who It Is For
- Municipal waste departments seeking to reduce collection frequency and fuel use
- Private waste haulers operating in markets with strict environmental regulations
- Contractors managing construction site debris with limited access and tight schedules
- Fleet managers replacing older non-compacting trucks with higher-capacity units
Buyer Pain
Problems It Solves
- Leaking waste and secondary pollution from open or poorly sealed compaction systems
- High labour cost and safety risk from manual container lifting and dumping
- Inefficient use of vehicle capacity due to lack of compaction in non-compressing trucks
- Frequent trips required due to low payload, increasing fuel and maintenance costs
- Difficulty in meeting environmental compliance in regions with strict waste transport rules
Engineering
Technical Features
- Fully sealed compaction tank with integrated slop tank for waste water collection
- Computer-controlled hydraulic system for automated loading and unloading
- Hook lift mechanism with manual and automatic operation modes for safety redundancy
- Weichai diesel engine with EURO 4 emission standard and manual transmission
- 12.00R20 radial tyres on steel rims for durability on urban and rough roads
- 4x2 drive layout with 4350+1350 mm wheelbase for improved stability and turning radius
- Manual transmission with high reduction ratio for better torque under heavy load
Specification
Specification Table for This Listing
Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.
| Condition | New |
|---|---|
| Truck Model | HOWO |
| Drive Wheel | 4x2 |
| Dimensions L x W x H unloaded | 10510 x 2550 x 3520 mm |
| Wheelbase | 4350+1350 mm |
| Curb Weight | 25000 kg |
| Gross Vehicle Weight | 25000 kg |
| Loading Capacity | 20 ton |
| Engine Model | Weichai |
| Emission | EURO 4 |
| Fuel Type | Diesel |
| Transmission | Manual |
| Transmission Type | Manual |
| Tyre | 12.00R20 |
| Chassis Brand | DongFeng, FAW, Foton, Sino, JAC, Shacman |
| Compaction System | Fully sealed with slop tank |
| Hook Lift | Yes |
| Control System | Computer-controlled, semi- or fully automated |
| Dumping Gear | Garbage can or refuse hopper |
| Warranty | 1 Year |
| Certifications Stated by Supplier | CCC |
| Emission Standard | Euro 4 |
| Place of Origin | Shandong, China (Mainland) |
| Brand Name | Sinotruk |
| Model Number | HOWO |
Materials
Materials and Build
- Galvanised steel compaction tank with welded seams and sealed joints
- Steel frame and chassis from DongFeng, FAW, Foton, Sino, JAC or Shacman series
- Cast steel hook lift mechanism with hydraulic cylinders
- 12.00R20 radial tyres on steel rims with reinforced sidewalls
- Hydraulic system components with imported seals and valves for high pressure and leak resistance
Process
How an Order Is Handled
- You provide the collection route, container type, and preferred dumping method (can or hopper)
- We confirm the chassis brand, engine, and emission standard based on current stock or production schedule
- You review the final specification sheet including colour, cab type, and dumping gear before deposit
- Unit is prepared, tested, and photographed with video of hydraulic and control system operation
- We book RoRo or container shipment and issue export documents including commercial invoice and bill of lading
Quality Control
Checks Before Loading
- Chassis, engine, and transmission numbers are photographed and matched to the approved specification
- Hydraulic system pressure test and control sequence are recorded on video before loading
- Seal integrity of the compaction and slop tanks is verified with a water test
- Paint, glass, and cab trim are inspected for damage at the loading port
Customisation
What Can Be Changed
- Custom cab colour to match fleet livery
- Choice of dumping gear: fixed garbage can or refuse hopper
- Optional additional fuel tank or tool box
- Left-hand or right-hand drive as required by local registration
- Adjustable fifth wheel height for different container types
Honest Comparison
How It Compares With the Alternatives
| Non-compacting 4x2 garbage truck | The compactor allows double the load per trip, reducing fuel and labour costs over time |
|---|---|
| EURO 3 emission model | EURO 4 avoids future compliance issues in markets where EURO 3 is no longer permitted |
| Automatic transmission model | Manual transmission is cheaper to buy and maintain, but requires more driver input during operation |
Use Guide
Using It Well
- Keep the slop tank drained regularly to prevent overflow and contamination
- Use only recommended hydraulic fluid to avoid seal degradation and system failure
- Train drivers on both manual and automatic modes to ensure safe operation during system faults
Photographs
More Views of This Unit
Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.
Source Specification
Manufacturer Text We Hold for This Listing
16Ton Chinese 4x2 hook lift garbage truck Drive Wheel 4X2 Type Compactor Transmission Type Manual Emission Standard Euro 3 Fuel Type Diesel Size 10510*2550*3520 Gross Vehicle Weight 25000 Place of Origin China Hubei Brand Name SHACMAN Certification CCC Warranty 1 Year Video technical support, Online support Weight (KG) 25000kg Product name Compression Garbage Truck Chassis Brand DongFeng.FAW.Foton.Sino.JAC.Shacman Driving Type 4*2 Loading capacity 20ton Color Customer Requirements WHEELBASE 4350+1350 Tire 12.00R20 Transmission Manual Transmission Emission Euro3/4/5 Engine Weichai 1. The whole truck tank is sealed and the waste water come from the compression process will flow into the slop tank. At this point, our compactor trucks can solve the problem of secondary pollution when doing garbage transportation. 2. Our garbage compactor truck is made up of sealed garbage tank, hydraulic sys
Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
