China Small Garbage Compactor Truck
A 4x2 compact garbage compactor truck based on the EQ1080SJ8BDC chassis, powered by a CY4SK251 3.856L inline four-cylinder diesel engine rated at 115kW, with a 7m3 rectangular compaction chamber made of 4mm side and 5mm bottom steel. It features a manual transmission, 6x7.50R16 tyres, a 6350kg curb weight and a 1730kg rated load, designed for urban and municipal waste collection in markets where space and access are limited.
- Condition New
- Truck Model CLW5080ZYSD5
- Drive Wheel 4x2
- Wheelbase 3800 mm
- Curb Weight 6350 kg
Stock number held for this listing: 10067
Key Benefits
What This Unit Does Well
- CY4SK251 engine meets EURO 4 emission standards, avoiding the need for AdBlue in regions without urea infrastructure
- 7m3 rectangular compaction chamber maximises volume per trip in tight urban routes
- One-key automatic loading cycle reduces operator training and operational errors
- 6350kg curb weight leaves 1730kg payload margin within a 8275kg total weight limit
- 4x2 drive layout improves fuel efficiency on paved city roads compared to 6x4 units
- Manual transmission is simpler to maintain and repair in remote locations without specialist tools
Application Scenarios
Where It Is Used
- Daily waste collection in narrow city streets with limited turning radius
- Municipal solid waste transport from residential zones to transfer stations
- Waste hauling in markets or industrial parks with low clearance and uneven surfaces
- Short-haul collection where compaction reduces the number of trips required
Fit
Who It Is For
- Municipal waste departments needing compact, easy-to-maneuver trucks for dense urban areas
- Contractors managing small-scale waste routes with tight access points
- Local governments importing cost-effective, low-maintenance compactor trucks from China
- Waste management operators replacing older models with a standardised engine and transmission
Buyer Pain
Problems It Solves
- Trucks that are too large for narrow alleys and poorly maintained roads in developing cities
- High maintenance costs from complex automatic transmissions in areas without trained mechanics
- Inconsistent compaction performance due to outdated or manually operated systems
- Lack of spare parts availability for imported European or Japanese compactor models
- High fuel consumption from overpowered 6x4 units used on short, urban routes
Engineering
Technical Features
- CY4SK251 water-cooled four-stroke inline four-cylinder diesel engine with turbocharging
- Manual transmission with six forward gears and one reverse
- Rectangular compaction chamber with 4mm side walls and 5mm bottom plate
- 9 hydraulic cylinders for compaction, operated via electric and manual control
- One-key automatic loading cycle with hydraulic control system
- 6x7.50R16 radial tyres on steel rims with leaf spring suspension (8/10+7)
- Front axle load of 3300kg, rear axle load of 4975kg
- Approach angle of 20 degrees, departure angle of 12 degrees
- Cab with seating for three, standard air conditioning and factory paint finish
Specification
Specification Table for This Listing
Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.
| Condition | New |
|---|---|
| Truck Model | CLW5080ZYSD5 |
| Drive Wheel | 4x2 |
| Wheelbase | 3800 mm |
| Curb Weight | 6350 kg |
| Gross Vehicle Weight | 8275 kg |
| Rated Load | 1730 kg |
| Cargo Capacity | 7 m3 |
| Engine Model | CY4SK251 |
| Displacement | 3.856 L |
| Rated Power | 115 kW |
| Emission Standard | EURO 4 |
| Fuel Type | Diesel |
| Transmission Type | Manual |
| Number of Gears | 6 forward / 1 reverse |
| Tyre Size | 7.50R16 |
| Number of Tyres | 6 |
| Suspension | Leaf spring 8/10+7 |
| Front Axle Load | 3300 kg |
| Rear Axle Load | 4975 kg |
| Approach Angle | 20° |
| Departure Angle | 12° |
| Max Speed | 103 km/h |
| Cab Passengers | 3 |
| Compaction Type | Hydraulic, one-key operation |
| Compartment Material | Steel, 4mm side, 5mm bottom |
Materials
Materials and Build
- Welded steel chassis frame in the EQ1080SJ8BDC series
- Steel cab shell with factory paint finish, white by default
- Rectangular compaction chamber made of 4mm side and 5mm bottom steel plates
- 7.50R16 radial tyres on steel rims with steel wheel hubs
- Leaf spring suspension with 8/10+7 spring configuration
- Hydraulic cylinders made of carbon steel with rubber seals
Process
How an Order Is Handled
- You send the route profile, typical load type and access constraints for your site
- We match the CLW5080ZYSD5 chassis and compaction system against current stock or plant availability
- You confirm the final spec sheet including cab colour, tyre brand and control override type before deposit
- Unit is prepared, photographed and video recorded before loading
- We book RoRo or container shipment and issue the export documents your customs needs
Quality Control
Checks Before Loading
- Chassis, engine and transmission numbers are photographed and matched to the approved spec sheet
- Engine start, gear engagement and hydraulic compaction cycle are recorded on video before loading
- Compaction chamber, cab, glass and paint are checked for transport damage at the loading port
- Loading and lashing photos are sent before the vessel departs
Customisation
What Can Be Changed
- Cab colour other than the default white
- Tyre brand and spare wheel count
- Manual control override for compaction system
- Additional tool box or mounting bracket for onboard equipment
- Custom front grille or badge for local branding
Honest Comparison
How It Compares With the Alternatives
| 6x4 compactor truck | The 4x2 model has lower fuel consumption and maintenance cost on paved urban routes, but lacks traction on muddy or steep access roads |
|---|---|
| Automatic transmission compactor | Manual transmission is easier to repair in remote areas without specialist tools, but requires more operator skill |
Use Guide
Using It Well
- Replace engine oil and filters at the interval recommended for CY4SK251 engines, not on a generic schedule
- Inspect hydraulic hoses and seals monthly in high-dust or high-humidity environments
- Keep the compaction control panel clean and dry to prevent electrical faults
- Order the hydraulic cylinder seals and control valve with the truck to avoid service delays
Photographs
More Views of This Unit
Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.
Source Specification
Manufacturer Text We Hold for This Listing
China small garbage compactor truck Model CLW5080ZYSD5 Total Weight(kg) 8275 Cubage(m3) 7 Rated Load(kg) 1730 Curb Weight(kg) 6350 Dimension(mm) 7350,7100x2250x2750 Passengers 3 Drive Type 4x2 Approach/Departure Angle(°) 20/12 Front/Rear Overhang 1150/2400 Wheel base(mm) 3800/4100 Axle Load(kg) 3300/4975 Max Speed(Km/h) 103 Chassis Parameter Type EQ1080SJ8BDC Dimension(mm) 6740,5890,7190x2100x2390,2370 Tire Number 6 Tire 7.50R16 Leaf Spring 8/10+7 Engine Parameter Type CY4SK251 Displacement(L) 3.856 Rated Power(KW) 115 Other Parameter Compression garbage truck, rectangular compartment, side thick:4mm and bottom thick:5mm,9 hydraulic oil cylinder brake, with no vice clamp, hydraulic control system for the electric control and manual control operation, loading cycle is One-key operation
Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
