CHINA Garbage Can Cleaning Light Truck
A 4x2 Sinotruk HOWO light-duty garbage compactor truck with a 6500ml diesel engine, 16000kg gross weight, and a sealed hydraulic compaction system. The CLW5123ZBSZZ chassis features a 4700mm wheelbase, 10.00-20 to 275/80R22.5 tyre options, and a 2 or 3-seat cab. It is designed for urban and municipal waste collection where compacting capacity, sealed containment and automated operation reduce spillage and secondary pollution.
- Condition New
- Truck Model CLW5123ZBSZZ
- Drive Wheel 4x2
- Transmission Type Manual
- Emission Standard Euro IV
Stock number held for this listing: 10068
Key Benefits
What This Unit Does Well
- 6500ml diesel engine with Euro IV emission standard ensures compliance in markets requiring low emissions without AdBlue dependency
- Hydraulic compaction system increases payload capacity by up to twice that of non-compacting trucks of similar weight class
- Fully sealed tank and slop tank system prevents leakage and secondary pollution during transport
- Computer-controlled automation allows single-driver operation for loading and unloading, reducing labour intensity
- Dual work modes (automatic and manual) provide backup in case of system failure or power loss
- Multiple tyre size options allow adaptation to local road conditions and spare parts availability
- 16000kg GVW rating supports high payload in urban routes with frequent stops and loading cycles
Application Scenarios
Where It Is Used
- Daily municipal waste collection in densely populated urban areas with narrow streets and frequent stops
- Waste transport from commercial districts to transfer stations where spillage must be avoided
- Garbage collection in coastal cities with high humidity, where sealed systems prevent corrosion and odour
- Route-based operations where automated loading reduces driver exposure to manual handling
- Municipal contracts requiring compliance with environmental regulations on waste containment
Fit
Who It Is For
- Municipal waste departments needing reliable, automated compaction for daily collection
- Private waste haulers operating in markets where secondary pollution is regulated
- Contractors managing urban construction site waste with tight schedules and limited labour
- Procurement teams sourcing trucks with proven compaction performance and spare parts availability
- Fleet managers standardising on one chassis and engine family across multiple waste vehicles
Buyer Pain
Problems It Solves
- Spillage and odour during transport due to open or poorly sealed waste containers
- High labour cost from manual loading and unloading of refuse in urban settings
- Inconsistent payload due to non-compacting trucks reaching weight limits too early
- Downtime from mechanical failure in unattended compaction systems without backup mode
- Difficulty in meeting environmental compliance when transporting wet or liquid waste
Engineering
Technical Features
- 6500ml diesel engine with Euro IV emission standard
- Manual transmission with 6 forward gears and 1 reverse
- Hydraulic compaction system with sealed waste tank and slop tank
- Computer-controlled automation system with manual override
- Sealed body with pressure-resistant construction to prevent leaks
- Chassis model ZZ1168GLJ3 with 4700mm wheelbase and 2 axles
- Cab with 2 or 3 seats, air conditioning optional
- Multiple tyre size options: 10.00-20, 10.00R20, 9.00R20, 10R22.5, 275/80R22.5
- Maximum speed of 90 km/h
- Overall dimensions: 8800 x 2480 x 3250 mm
- Curb weight: 10200 kg
- Gross vehicle weight: 16000 kg
Specification
Specification Table for This Listing
Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.
| Condition | New |
|---|---|
| Truck Model | CLW5123ZBSZZ |
| Drive Wheel | 4x2 |
| Transmission Type | Manual |
| Emission Standard | Euro IV |
| Fuel Type | Diesel |
| Place of Origin | Shandong, China (Mainland) |
| Brand Name | Sinotruk |
| Model Number | HOWO |
| Gross Weight | 16000 kg |
| Curb Weight | 10200 kg |
| Cab Seats | 2, 3 |
| Number of Axles | 2 |
| Overall Dimension | 8800 x 2480 x 3250 mm |
| Wheelbase | 4700 mm |
| Max Speed | 90 km/h |
| Chassis Model | ZZ1168GLJ3 |
| Chassis Brand | Chinese Brand |
| Chassis Dimensions | 8450 x 2480 x 2970 mm |
| Engine Capacity | 6500 ml |
| Number of Wheels | 6 |
| Tyre Specification | 10.00-20 16PR, 10.00R20 16PR, 9.00R20 16PR, 10R22.5 16PR, 275/80R22.5 16PR |
Materials
Materials and Build
- Welded steel chassis frame in ZZ1168GLJ3 series
- Sealed steel waste tank with corrosion-resistant coating
- Hydraulic cylinder and pump components from imported suppliers
- Steel cab shell with factory paint finish, white or custom colour
- 10.00-20 to 275/80R22.5 radial tyres on steel rims
- Control panel and wiring harness with industrial-grade connectors
Process
How an Order Is Handled
- You send the route profile, waste type, and frequency of collection you expect
- We match a chassis code and axle ratio against available stock or plant build schedule
- You confirm the final specification including tyre size, cab seat count, and dumping gear
- Unit is prepared, photographed, and video recorded before loading
- We book RoRo or container shipment and issue export documents for customs clearance
Quality Control
Checks Before Loading
- Chassis and engine numbers are photographed and matched to the specification sheet
- Hydraulic system pressure test and leak check are recorded on video before loading
- Sealed tank integrity is verified with a water fill test before shipment
- Cab interior, paint, and glass are inspected for transport damage at the loading port
Customisation
What Can Be Changed
- Cab colour other than default white
- 2-seat or 3-seat cab configuration
- Tyre size and brand selection from available options
- Dumping gear: garbage can or refuse hopper
- Additional tool box or storage compartment
- Optional air conditioning in the cab
Honest Comparison
How It Compares With the Alternatives
| Non-compacting 4x2 waste truck | This unit carries twice the effective load due to compaction, but requires more maintenance on hydraulic components |
|---|---|
| Euro III emission truck | Euro IV avoids future compliance risks in regulated markets but may require more frequent filter changes |
| 6x4 compactor truck | 4x2 has lower fuel consumption and better turning radius on city streets, but less traction on wet or uneven terrain |
Use Guide
Using It Well
- Use manual mode only when the computer control system fails; do not rely on it as a primary operation mode
- Keep the throttle valve and control panel clean to prevent sensor misreads during compaction
Photographs
More Views of This Unit
Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.
Source Specification
Manufacturer Text We Hold for This Listing
CHINA garbage can cleaning light truck Main parameters Brand BOLI Product model CLW5123ZBSZZ Gross weight (Kg) 16000 Curb weight (Kg) 10200 Cab seats 2,3 Number of axles 2 Overall dimension(mm) 8800*2480*3250 Wheel base(mm) 4700 Max speed (Km/h) 90 Chassis parameters Chassis model ZZ1168GLJ3 Brand Chinese Brand Dimentions 8450x2480x2970 Fuel diesel Number of wheels (mm) 6 Tire specification 10.00-20 16PR,10.00R20 16PR,9.00R20 16PR,10R22.5 16PR,275/80R22.5 16PR Engine capacity (ml) 6500 Emission standard Euro III Equipment Equipped with hermetic dustbin, hydraulic system and operating system. Automatic compress and uninstall, sewage can be collected by the dump tank.Pressure is large, leakproofness is good, operation is convenient and security is dependable. 1. The whole truck tank is sealed and the waste water come from the compression process will flow into the slop tank. At this point,
Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
