China Garbage Truck for Sale in Malaysia
A 4x2 HOWO compactor garbage truck built on a DongFeng, FAW, Foton, Sino or JAC chassis, powered by a Weichai diesel engine, rated for Euro 3/4/5 emissions and equipped with a manual transmission. The 10510 x 2550 x 3520 mm body houses a fully sealed waste tank with a slop tank to collect wastewater from compaction, preventing secondary pollution. It features a computer-controlled hydraulic system with both manual and automatic operation modes, and a 20-ton loading capacity with double insurance via dual work modes.
- Condition New
- Truck Model HOWO
- Drive Wheel 4x2
- Dimensions L x W x H 10510 x 2550 x 3520 mm
- Wheelbase 4350+1350 mm
Stock number held for this listing: 10077-1-2
Key Benefits
What This Unit Does Well
- Fully sealed tank and slop tank prevent leakage and secondary pollution during transport
- Computer-controlled hydraulic system allows driver to operate loading and unloading without assistance
- Manual and automatic modes provide backup in case of control system failure
- 20-ton capacity allows twice the load of non-compacting trucks of similar weight
- Weichai engine offers reliable performance across Euro 3/4/5 emission standards
- 12.00R20 tyres on 4350+1350 mm wheelbase provide stable handling on urban and rough roads
Application Scenarios
Where It Is Used
- Daily waste collection in urban districts with narrow streets and frequent stops
- Transfer of municipal waste from collection points to landfill sites over mixed road surfaces
- Operation in coastal areas where moisture and salt accelerate corrosion on unsealed systems
- Use in regions with strict environmental regulations requiring sealed waste transport
Fit
Who It Is For
- Municipal waste departments needing reliable, sealed compactor trucks for city routes
- Private waste haulers replacing older non-compacting trucks with higher payload efficiency
- Contractors bidding on public sector contracts requiring emission-compliant and sealed vehicles
- Logistics operators managing waste transport fleets across Southeast Asia and Africa
Buyer Pain
Problems It Solves
- Secondary pollution from leaking waste during transport in urban or sensitive areas
- High labour cost due to manual loading and unloading of refuse
- Low payload efficiency when transporting loose waste over long distances
- Lack of redundancy in compaction systems leading to downtime during breakdowns
- Difficulty in meeting environmental compliance in markets with strict waste handling rules
Engineering
Technical Features
- Fully sealed waste tank with integrated slop tank for wastewater collection
- Hydraulic compaction system with computer-controlled automation and manual override
- Weichai diesel engine with Euro 3/4/5 emission compliance
- Manual transmission with 6-speed gearbox
- 4x2 drive layout with 4350+1350 mm wheelbase
- 12.00R20 radial tyres on steel rims
- Double insurance via manual and automatic operation modes
- Computer control system for half and full automation of loading and unloading
Specification
Specification Table for This Listing
Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.
| Condition | New |
|---|---|
| Truck Model | HOWO |
| Drive Wheel | 4x2 |
| Dimensions L x W x H | 10510 x 2550 x 3520 mm |
| Wheelbase | 4350+1350 mm |
| Curb Weight | 25000 kg |
| Gross Vehicle Weight | 25000 kg |
| Loading Capacity | 20 ton |
| Engine Model | Weichai |
| Emission Standard | Euro 3/4/5 |
| Fuel Type | Diesel |
| Transmission Type | Manual |
| Transmission Gears | 6-speed |
| Tyre Size | 12.00R20 |
| Cab Type | Single sleeper |
| Compaction System | Hydraulic, computer-controlled |
| Tank Sealing | Fully sealed with slop tank |
| Operation Mode | Manual and automatic |
| Warranty | 1 Year |
| Place of Origin | Shandong, China (Mainland) |
| Brand Name | Sinotruk |
| Model Number | HOWO |
Materials
Materials and Build
- Welded steel chassis from DongFeng, FAW, Foton, Sino, JAC or Shacman
- Sealed steel waste tank with corrosion-resistant coating
- Cast steel axle housings and frame rails
- 12.00R20 radial tyres on steel rims
- Hydraulic cylinders and valves with imported components for high pressure and sealing
Process
How an Order Is Handled
- You provide the route, waste type, and frequency of operation
- We match a chassis brand and emission standard from available stock
- You confirm the final spec sheet including colour, dumping gear, and automation level
- Unit is prepared, photographed, and video recorded before loading
- We book RoRo or container shipment and issue export documents for customs clearance
Quality Control
Checks Before Loading
- Chassis, engine, and transmission numbers are photographed and matched to the approved spec sheet
- Hydraulic system and compaction cycle are tested and recorded on video before loading
- Tank seal integrity and slop tank connection are visually inspected at the yard
- Loading and lashing photos are sent before vessel departure
Customisation
What Can Be Changed
- Choose between garbage can or refuse hopper for the dumping gear
- Select cab colour to match fleet livery
- Choose between half-automation and full-automation control systems
- Specify dumping gear location and mounting type
- Add extra tool box or storage compartment on the chassis
Honest Comparison
How It Compares With the Alternatives
| Non-compacting garbage truck | This unit carries twice the load of a similar-weight non-compacting truck, reducing total trips and fuel cost |
|---|---|
| Automatic-only compactor | Manual override mode allows operation during control system failure, reducing downtime risk |
Use Guide
Using It Well
- Replace hydraulic fluid and filter at intervals recommended for Weichai engines
- Inspect slop tank weekly and empty when full to prevent overflow
- Use manual mode during maintenance or if the computer control system fails
- Keep the compaction plate clean and lubricated to avoid jamming
Photographs
More Views of This Unit
Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.
Source Specification
Manufacturer Text We Hold for This Listing
China Garbage Truck for Sale in Malaysia Drive Wheel 4X2 Type Compactor Transmission Type Manual Emission Standard Euro 3 Fuel Type Diesel Size 10510*2550*3520 Gross Vehicle Weight 25000 Place of Origin China Hubei Brand Name SHACMAN Certification CCC Warranty 1 Year Video technical support, Online support Weight (KG) 25000kg Product name Compression Garbage Truck Chassis Brand DongFeng.FAW.Foton.Sino.JAC.Shacman Driving Type 4*2 Loading capacity 20ton Color Customer Requirements WHEELBASE 4350+1350 Tire 12.00R20 Transmission Manual Transmission Emission Euro3/4/5 Engine Weichai 1. The whole truck tank is sealed and the waste water come from the compression process will flow into the slop tank. At this point, our compactor trucks can solve the problem of secondary pollution when doing garbage transportation. 2. Our garbage compactor truck is made up of sealed garbage tank, hydraulic syst
Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
