Concrete Mixer Trucks

Fast Delivery Small Concrete Mixer Truck for Sale

The unit has a 7870x2500x3600mm dimension, 25000kg gross vehicle weight, and is built on a chassis with HF9 front and HC16 rear axles. It is available for fast shipment from Shandong, China, with a 12-month warranty and spare parts support.

Condition New
Warranty 12Months
Cab HW76(onebed)withAircon
Color White,red
Transmission HW15710

Ask for a Price on WhatsApp Email the Specification

Stock number held for this listing: 10242

Side view of the concrete mixer truck showing the 7870mm length and 12.00R20 tyres

Key Benefits

What This Unit Does Well

290HP WD615.87 engine is widely available in Chinese fleets, so filters, injectors and oil are easy to source locally
HW15710 nine-speed gearbox provides usable ratios for both loaded and empty runs on construction sites
6m3 alloy steel drum with HG700 blade and T510 cylinder material resists wear in high-volume mixing
12.00R20 steel tires are standard in heavy-duty construction zones and reduce downtime from punctures
Air-conditioned HW76 one-bed cab supports driver comfort during long shifts on site
12-month warranty covers engine, transmission and hydraulic system, reducing first-year risk

Application Scenarios

Where It Is Used

Short-haul concrete delivery within a construction site with uneven, gravel-covered access roads
Urban infrastructure projects where the truck must navigate tight turns and frequent stops
High-volume batching operations requiring consistent discharge speed and low residual rate

Fit

Who It Is For

Contractors running small to medium-scale construction projects needing immediate delivery
Machinery dealers stocking ready-to-ship mixers for resale in Africa and Southeast Asia
Fleet managers replacing older mixers with a proven engine and transmission combination
Government procurement teams needing a compliant, certified unit with local service support

Buyer Pain

Problems It Solves

Long lead times for custom-built mixers when a project starts immediately
Uncertainty over spare parts availability for imported components like the Bonfiglioli reducer
Downtime caused by hydraulic system failures when no local technician can access the Eaton or Rexroth components
Mismatched axle load ratings causing overloading fines on public roads
Lack of air conditioning in the cab leading to driver fatigue on hot days

Engineering

Technical Features

WD615.87 water-cooled six-cylinder diesel engine with turbocharging and intercooling
Direct injection fuel system with rated 290HP output
HW15710 manual transmission with nine forward gears and two reverse
HF9 front axle and HC16 rear axle in 6x4 drive layout
6m3 mixing drum made from T510 6mm alloy steel with HG700 blade material
High-strength 8mm alloy steel drum head with 180° discharge range and height adjustment
Italy Bonfiglioli or Germany ZF reducer for drum rotation
American Sao or Germany Rexroth hydraulic system with 500L water tank
Air brake system with directional assistance and 12+1 tire configuration
Cab: HW76 one-bed with factory air conditioning

Specification

Specification Table for This Listing

Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.

Specification of Fast Delivery Small Concrete Mixer Truck for Sale
Condition	New
Warranty	12Months
Cab	HW76(onebed)withAircondition
Color	White,red
Transmission	HW15710
Dimension(LWH)	7870x2500x3600
Weight	25000kg
Certification	ISO9001,ISO/TS16949,CCC,
Tire	12.00R20
Power(W)	290HP
Engine	WD615.87
Drive Wheel	6x4
Dimensions L x W x H	7870 x 2500 x 3600 mm
Curb Weight	25000 kg
Engine Model	WD615.87
Horsepower	290 HP
Emission	Not specified
Fuel Type	Diesel
Front Axle	HF9
Rear Axle	HC16
Tyre	12.00R20
Mixer Volume	6 m3
Max Loading Capacity	16000 kg
Maximum Speed	90 km/h
Certifications Stated by Supplier	ISO9001, ISO/TS16949, CCC
Place of Origin	Shandong,

Materials

Materials and Build

Steel cab shell with factory paint finish, white or red by default
Cast steel HF9 front and HC16 rear axle housings
12.00R20 steel radial tyres on steel rims
T510 6mm alloy steel for drum cylinder, HG700 blade, 8mm high-strength alloy steel drum head

Process

How an Order Is Handled

You send the project location, site access conditions and delivery timeline
We confirm if the unit is in stock or needs to be sourced from the plant
You approve the final specification sheet including colour, cab, tyre and drum configuration
Unit is prepared, photographed and video recorded before loading
We book RoRo shipment and issue the export documents your customs needs

Quality Control

Checks Before Loading

Chassis, engine and gearbox numbers are photographed and matched to the specification sheet you approved
Engine start, gear engagement and hydraulic system function are recorded on video before loading
Drum rotation, discharge range and water supply are tested before loading
Paint, glass and cab trim are checked for transport damage at the loading port
Loading and lashing photos are sent before the vessel departs

Customisation

What Can Be Changed

Cab colour other than white or red
Sleeper layout, single or double bunk
Left hand or right hand drive as your registration requires
Tyre brand and spare wheel count
Additional water tank or tool box
Drum coating or internal liner upgrade

Honest Comparison

How It Compares With the Alternatives

4x2 concrete mixer	The 6x4 carries more on the drive axles for loaded runs but costs more fuel when running empty
Higher capacity 14m3 mixer	6m3 is easier to load and unload on tight urban sites, with less residual material

Use Guide

Using It Well

Check the hydraulic system pressure weekly during high-volume batching
Keep the water tank clean and free of debris to prevent clogging in the pressure system
Order the drum blade and reducer oil with the truck so the first service does not wait on shipping

Photographs

More Views of This Unit

Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.

Rear view of the mixer truck with drum discharge mechanism and mud flaps

Cab interior with one-bed sleeper and air conditioning controls

Fast Delivery Small Concrete Mixer Truck for Sale - photo 4

Source Specification

Manufacturer Text We Hold for This Listing

Fast delivery small concrete mixer truck for sale Now we have 10 units 6x4 tractor truck and dump truck ready for shipment, which were produced in 2015, price is very good. Fast delivery small concrete mixer truck for sale Product Description Product specification: Chassis parameters Name: 14-18 m3 mixer Truck model: Concrete mixer truck Engine: Cummins 360 horsepower Size: 1100x2495x3990mm gearbox Fast 9-speed gearbox Volume: 14m3 mixer Truck Front and rear bridges: 7.5Ton/16ton Total mass: 25000(KG) drive: (6x4) brake: Air brake Wheelbase: 1800+3000+1400 Turn to: Directional assistance axes: 3 Speed: 85(km/h) Number of tires: 12+1 Tires: 12.00-20(Steel tire) Tank parameter Tank body Alloy steel Cylinder material: T510; 6mm Alloy steel Blade material: HG700 Head material: High strength 8mm alloy steel Reducer: Italy Bonfiglioli / PMP, Germany ZF (pure import) Hydraulic system American S

Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
