Cargo Trucks

14ton Hook Lift Garbage Truck for Garbage Collecting and Moving

A 6x4 HOWO 14-ton hook lift garbage truck built on the Sinotruk HOWO chassis with a Weichai engine, manual transmission, and Euro 4 emission standard. The unit features a 12.00R20 tyre configuration, 4350+1350mm wheelbase, and a 20-ton loading capacity. It is designed for municipal and industrial waste collection where lifting and transporting full bins is required without manual handling.

  • Condition New
  • Truck Model HOWO
  • Drive Wheel 6x4
  • Dimensions L x W x H unloaded 10510 x 2550 x 3520 mm
  • Wheelbase 4350+1350 mm
Ask for a Price on WhatsApp Email the Specification

Stock number held for this listing: 10077

Front three-quarter view of a white HOWO 6x4 hook lift garbage truck with open lifting arm
Front three-quarter view of a white HOWO 6x4 hook lift garbage truck with open lifting arm
Key Benefits

What This Unit Does Well

  • Weichai engine is widely available in China, so filters, injectors and oil are easy to source locally
  • Manual transmission reduces maintenance cost and avoids electronic control unit failures in dusty environments
  • 6x4 drive layout provides better traction on wet or uneven ground during waste collection runs
  • 4350+1350mm wheelbase allows stable bin lifting and reduces chassis stress during repeated hook lift cycles
  • Euro 4 compliance allows registration in markets where Euro 3 is no longer accepted
Application Scenarios

Where It Is Used

  • Daily collection of municipal waste from residential zones with narrow, unpaved access roads
  • Industrial site waste transport where bins are loaded at multiple points and lifted by crane arms
  • Port or construction site waste removal where bins are full and must be lifted without manual labour
  • Long-term deployment in hot climates where air-cooled engines and durable transmissions are preferred
Fit

Who It Is For

  • Municipal waste departments replacing older hook lift units with consistent parts availability
  • Contractors managing industrial or construction site waste who need reliable bin lifting without downtime
  • Fleet managers in Africa and Southeast Asia seeking trucks that can be serviced locally with Chinese spare parts
  • Procurement teams sourcing a single model that supports both hook lift and compaction variants
Buyer Pain

Problems It Solves

  • Fleets stuck with multiple truck models requiring different clutch, transmission and engine parts
  • Downtime caused by delayed delivery of imported European or Japanese hook lift components
  • Inconsistent bin lifting performance due to underpowered or poorly configured drive systems
  • Registration issues in countries that no longer accept Euro 3 vehicles for urban use
Engineering

Technical Features

  • 6x4 drive layout with front and rear axles providing balanced load distribution
  • Weichai diesel engine with manual transmission and Euro 4 emission standard
  • 12.00R20 radial tyres on steel rims for durability on rough terrain
  • 4350+1350mm wheelbase with reinforced chassis for repeated hook lift stress
  • Hook lift mechanism with hydraulic cylinder and lifting arm for full bin handling
  • Single sleeper cab with factory air conditioning and standard controls
Specification

Specification Table for This Listing

Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.

ConditionNew
Truck ModelHOWO
Drive Wheel6x4
Dimensions L x W x H unloaded10510 x 2550 x 3520 mm
Wheelbase4350+1350 mm
Curb Weight25000 kg
Engine ModelWeichai
HorsepowerNot specified
EmissionEuro 4
Fuel TypeDiesel
TransmissionManual
Transmission TypeManual
Loading Capacity20 ton
Gross Vehicle Weight25000 kg
Chassis BrandDongFeng, FAW, Foton, Sino, JAC, Shacman
Cab TypeSingle sleeper
Tyre12.00R20
ColorCustomer Requirements
Place of OriginShandong, China (Mainland)
Brand NameSinotruk
Warranty1 Year
Certifications Stated by SupplierCCC
Emission StandardEuro 4
Model NumberHOWO
Materials

Materials and Build

  • Welded steel ladder frame chassis from Sinotruk HOWO series
  • Steel cab shell with factory paint finish, colour as per customer request
  • Cast steel front and rear axle housings with reinforced mounting points for hook lift
  • 12.00R20 radial tyres on steel rims with high load index for repeated lifting cycles
Process

How an Order Is Handled

  • You send the route profile, bin size, and frequency of collection you expect
  • We match a chassis code and axle ratio against what is available in stock or from the plant
  • You confirm the final specification sheet including colour, cab, tyre and hook lift configuration before deposit
  • Unit is prepared, photographed and video recorded before loading
  • We book RoRo or container shipment and issue the export documents your customs needs
Quality Control

Checks Before Loading

  • Chassis, engine and gearbox numbers are photographed and matched to the specification sheet you approved
  • Hook lift mechanism is tested with a full bin simulation before loading
  • Engine start, gear engagement and hydraulic system are recorded on video before loading
  • Paint, glass and cab trim are checked for transport damage at the loading port
  • Loading and lashing photos are sent before the vessel departs
Customisation

What Can Be Changed

  • Cab colour other than the default white
  • Sleeper layout, single or double bunk
  • Left hand or right hand drive as your registration requires
  • Tyre brand and spare wheel count
  • Additional tool box or fifth wheel height adjustment
Honest Comparison

How It Compares With the Alternatives

4x2 hook lift truckThe 6x4 offers better traction and axle load distribution, especially on wet or soft ground, but uses more fuel when running empty
Euro 3 emission truckEuro 4 avoids registration rejection in markets where Euro 3 is phased out, but requires more frequent diesel particulate filter maintenance
Automatic transmissionManual transmission is cheaper to buy and repair, but requires more driver skill and effort in stop-start traffic
Use Guide

Using It Well

  • Replace engine oil and filters on the interval recommended for Weichai engines, not on a generic schedule
  • Keep the air dryer cartridge stocked, especially in humid coastal regions where moisture affects the system
Photographs

More Views of This Unit

Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.

Side view showing the 4350+1350mm wheelbase and 12.00R20 tyresRear view with the hook lift mechanism raised and bin lifting arm extendedCab interior with single sleeper and air conditioning controlsWeichai engine mounted in the chassis with visible intake and exhaust linesHydraulic cylinder and lifting arm detail at the rear of the truckFront grille and headlamp detail of the HOWO cab with Sinotruk branding14ton Hook Lift Garbage Truck for Garbage Collecting and Moving - photo 814ton Hook Lift Garbage Truck for Garbage Collecting and Moving - photo 9
Source Specification

Manufacturer Text We Hold for This Listing

14ton Hook lift garbage truck for garbage collecting and moving Product Description Drive Wheel 6X4 Type Compactor Transmission Type Manual Emission Standard Euro 3 Fuel Type Diesel Size 10510*2550*3520 Gross Vehicle Weight 25000 Place of Origin China Hubei Brand Name SHACMAN Certification CCC Warranty 1 Year Video technical support, Online support Weight (KG) 25000kg Product name Compression Garbage Truck Chassis Brand DongFeng.FAW.Foton.Sino.JAC.Shacman Driving Type 4*2 Loading capacity 20ton Color Customer Requirements WHEELBASE 4350+1350 Tire 12.00R20 Transmission Manual Transmission Emission Euro3/4/5 Engine Weichai Product Images Rear flipping Application Scene

Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.

Related Listings

Other Cargo Trucks Buyers Compare With This

All 56 Cargo Trucks Full product index

Buyer Questions

Questions About This Unit

Is this unit new or used

New. All units are brand new from the factory and come with a one-year warranty.

Can you supply spare parts for this truck later

Yes. Weichai engine parts, hydraulic cylinders, hook lift arms and cab components are among the most frequently shipped items and can be consolidated with the truck order.

Do you ship by container or RoRo

Hook lift trucks are typically shipped RoRo. Container shipment is possible but requires lowering the cab and may affect clearance. We quote both options so you can compare landed cost.

What documents do I get for customs

Commercial invoice, packing list, bill of lading, certificate of origin, and CCC certificate as standard. Pre-shipment inspection certificates can be arranged if required.
