Graphene Nanoplates (3-10nm)
Graphene nanoplates are nanoscale thin sheets composed of graphene layers. Graphene consists of single layers of carbon atoms arranged in a two-dimensional crystal structure, possessing excellent electrical conductivity, thermal conductivity, and mechanical properties. Nanoplates refer to their dimensions being in the...
Introduction
Graphene nanoplates are nanoscale thin sheets composed of graphene layers. Graphene consists of single layers of carbon atoms arranged in a two-dimensional crystal structure, possessing excellent electrical conductivity, thermal conductivity, and mechanical properties. Nanoplates refer to their dimensions being in the nanometer range, typically with a thickness of only a few carbon atoms.
Graphene nanoplates can be prepared through methods such as chemical exfoliation, chemical vapor deposition (CVD), or mechanical exfoliation.
These materials exhibit high surface area, outstanding electrical and thermal conductivity, mechanical strength, and chemical stability, thus holding great promise for applications in electronics, energy storage, composite materials, sensors, and biomedical devices.
Applications
Added as a reinforcing agent into polymer-based composite materials, graphene nanoplates enhance the tensile strength, stiffness, corrosion resistance, wear resistance, as well as properties like anti-static and lubrication, improving the mechanical and conductive performance of the composite materials.
Specification
Our standard packaging sizes include 1g, 10g and 100g.
Specifications
Figures below are the manufacturer data for this model. Anything not listed is confirmed in writing with the quotation rather than estimated here.
| Diameter | 5-10 μm |
|---|---|
| Thickness | 3-10 nm |
| Conductivity | 500-1000 S/cm |
| Purity | 99.50% |
| Surface area | 31.657 m²/g |
| Tap density | 0.075 g/cm³ |
| Apparent density | 0.050 g/cm³ |
Graphene Nanoplates (3-10nm) In Detail
Processes This Unit Supports
These are the applications ZYLAB lists this model under. Each link opens the full equipment set for that process, which is useful when a project needs more than one machine.
- General laboratory sample preparation
Who Orders It
Fields this model already works in, plus what ZYLAB puts behind it: a 2-year warranty on most products, glass excluded, spare parts in stock and free application support by WhatsApp or email.
- University and institute research laboratories
Related Equipment
Models from the same family and the same processes, in case a different chamber size or temperature range fits better.
Ordering Graphene Nanoplates (3-10nm)
What is Graphene Nanoplates (3-10nm) typically used for?
Graphene nanoplates are nanoscale thin sheets composed of graphene layers. Graphene consists of single layers of carbon atoms arranged in a two-dimensional crystal structure, possessing excellent electrical conductivity, thermal conductivity, and mechanical pr
What warranty comes with Graphene Nanoplates (3-10nm)?
Most ZYLAB products carry a 2-year warranty, glass components excluded; the exact term for this model is the one printed in its specification table and repeated on the quotation. Within the warranty period any part that fails through no misuse of your own is replaced free of charge.
Can we get technical help before ordering Graphene Nanoplates (3-10nm)?
Yes, and it is free. Our technical staff help with model selection, troubleshooting, manuals and application questions whether or not you have ordered from us before. Write to [email protected] or message us on WhatsApp.
Which shipping methods do you use?
Sea freight for consignments over about 60 kg (11-30 days to North America, 25-33 days to Europe, 7-20 days to Southeast Asia), air freight to airport in roughly 7-10 days, and DHL, FedEx or UPS door to door in about 5-7 days for small urgent items.
How can we pay for Graphene Nanoplates (3-10nm)?
Bank (wire) transfer, letter of credit for larger orders, major credit and debit cards, and PayPal. Bank details are printed on the invoice; send us the transfer confirmation and we start processing straight away.
Quote For Graphene Nanoplates (3-10nm)
Tell us the sample, the temperature and the atmosphere. You get the configuration, the price and the despatch date in one reply.
