Exhaust Header · SKU 701807501225
SHORTY STAINLESS STEEL HEADER EXHAUST MANIFOLD FOR 64-77 FORD MUSTANG 302CU 5.0
A 1-1/2 inch primary tube shorty stainless steel header for the 1964-1977 Ford Mustang 302 cu in 5.0L engine. Fitment is specific to the Small Block Ford 289-302 block and does not cover 351W engines or later model years.
- Primary Tube Size1-1/2 inch
- Collector Diameter2-1/2 inch
- Tube Thickness16-gauge
- Flange Thickness3/8 inch
What You Get
Key Benefits
- 1-1/2 inch primary tubes increase exhaust flow velocity and reduce back pressure compared to factory manifolds
- Bolt-on installation with included hardware eliminates the need for welding or engine modifications
Why Buyers Switch
Problems It Solves
- Factory exhaust manifolds restrict flow and create high exhaust gas temperatures under load
- Mild steel manifolds rust at the flange and gasket interface within a few years of use
- Universal headers require cutting, welding, and custom fitting, increasing installation time and cost
- Poorly machined flanges lead to exhaust leaks and inconsistent torque patterns
Where It Is Used
Application Scenarios
- Classic car restorers upgrading 1964-1977 Mustangs with improved exhaust flow and modern materials
- Performance shops installing headers on vintage Ford engines without altering engine block geometry
- Distributors stocking vehicle-specific exhaust parts for the Small Block Ford market
- Online sellers needing a photographed, fitment-verified part with a clean technical description
Buyers
Who It Is For
- Classic car parts distributors buying vintage Ford exhaust hardware by the pallet
- Online auto parts sellers serving North American muscle car enthusiasts
Construction
Technical Features
- Shorty design with 1-1/2 inch primary tubes and 2-1/2 inch collector diameter
- Complete header system with two collector flanges, bolts, and metal gaskets included
- Direct bolt-on fitment to the Small Block Ford 289-302 engine block without modifications
Data
Specifications
| Primary Tube Size | 1-1/2 inch |
|---|---|
| Collector Diameter | 2-1/2 inch |
| Tube Thickness | 16-gauge |
| Flange Thickness | 3/8 inch |
| Weight | 15 LBS / 6.80 KGS |
| Package | 1x Header System |
| Fitment | 1964-1977 Ford Mustang 302 cu in 5.0L, 289-302 Block |
Material
Materials
- Metal gaskets and bolts included
Manufacturing
How It Is Made
Tube bending to match the factory header routing and clearance
Final fit check against the engine block pattern before packing
Checks
Quality Control
- Flange bolt pattern and sealing face verified before welding
- Weld seams inspected for pinholes and incomplete fusion along the full joint
Private Label
Customisation Options
- Private label packaging and barcode labels on request
- Bulk cartons available for container orders instead of individual retail boxes
Comparison
Compared With The Alternatives
| Factory exhaust manifold | The stock manifold is heavier and restricts flow with narrow passages; this header improves flow and increases engine output by 10-15 HP |
|---|---|
| Universal header kit | Universal headers require cutting, welding, and fitting; this one bolts on directly without modification |
Installation
Use Guide
- Confirm the engine is a Small Block Ford 289-302 block and not a 351W or later model
- Remove the factory exhaust manifold and clean the engine block flange surface before installation
- Use new metal gaskets and bolts-do not reuse old components
- Torque flange bolts evenly in a crisscross pattern to maintain sealing face flatness
- Recheck bolt torque after the first heat cycle to prevent leaks
More In This Family
Related Products
Answers
Questions About This Part
Will this fit a 1978 Ford Mustang with a 302 engine?
No. The part covers 1964-1977 Ford Mustangs with the Small Block Ford 289-302 engine and does not fit 1978 or later model years.
What is the primary tube size?
1-1/2 inch. This matches the factory primary tube diameter for the Small Block Ford 289-302.
What is included in the package?
One complete header system with two collector flanges, bolts, and metal gaskets. No instructions are included.
Can we get our own brand on the box?
Yes. Private label packaging and barcode labels can be arranged, and bulk cartons are available for container orders.
Is this street legal where I sell?
Emissions rules differ by market and we make no emissions approval claim for this part. Check your local regulations before resale.
