Gesture Dimming Explained and Where It Is Worth Using
Two families in this catalogue dim from the fixture itself rather than from the wall. This is what that changes on site, and where it is not worth paying for.
Two families in this catalogue dim from the fixture itself rather than from the wall. This is what that changes on site, and where it is not worth paying for.
What Dimming From the Fixture Means
In a conventional installation the dimmer sits on the wall and needs its own wiring back to the fixture. In the SD2126 pendant and the SL2312 floor lights the control is inside the fixture, so the circuit only has to be a plain switched live.
See Up and Down Pendant Light With Gesture Dimming SD2126-RS RM RL
Where It Saves Real Money
Retrofit work. When a finished ceiling or a finished wall would have to be opened to run dimming cable, the cost of opening and making good is usually higher than the difference in fixture price. That is the case to check first.
Where It Is Not Worth It
Corridors, back of house and any space on a lighting control system already. If a control system is being installed anyway, a standard dimmable driver on that system is the simpler answer.
The SL2312 Floor Lights Use a Top Button
On the SL2312 uprights the control is a single button on the top of the head: press for on and off, hold to dim. In a hotel room that removes the cord switch a guest has to find in the dark.
See Gesture Dimming Floor Light SL2312-1C
Specify It Correctly
State on the purchase order that the fixture is the dimming-enabled version and confirm that the circuit is a plain switched live. Do not put a wall dimmer in front of it.
Related Products
Chandeliers and Pendant LightsUp and Down Pendant Light With Gesture Dimming SD2126-RS RM RLUp and down pendant in three sizes with gesture dimming, 25 W to 55 WView specification
Floor LightsGesture Dimming Floor Light SL2312-2C1365 mm upright floor light with top button dimming, Cree COB 10 W, 5 kgView specification
Floor LightsGesture Dimming Floor Light SL2312-1C1300 mm upright floor light with top button dimming, Cree COB 5 W, 3.1 kgView specificationProjects Where This Mattered
Sectors This Applies To
IndustryOffices and WorkspacesOffice fit-outs increasingly replace recessed troffers with decorative fixtures, which means a decorative fixture now has to do a working job: light a meeting table properly, dim for a presentation, and not glare on a screen.Read more
IndustryHotels and HospitalityHotel lighting is bought by the floor, not by the piece. A guest room needs a ceiling light, a bedside table light, a floor light and a bathroom wall light that all read as one scheme, and the lobby needs a fixture large enough to hold a double-height space.Read moreHow We Handle It On An Order
Questions On This Topic
Does the fixture need a special driver?
No dimmer module or control wiring is needed on the circuit. The control is built into the fixture.
Can I put a wall dimmer in front of it as well?
No. The circuit should be a plain switched live.
Which models have it?
The SD2126 up and down pendant in all three sizes, and the SL2312-1C and SL2312-2C floor lights.
