Honeycomb Paper Cutting Machine-2 roll
The HQ 600-2 rolls cuts finished honeycomb paper rolls into individual sheets with consistent dimensions. Designed for high capacity, it handles rolls fed from Snda's honeycomb forming and die cutting machines. The dual roll feeding system allows continuous processing, so a packaging producer can convert finished honeycomb rolls into sheets for use in automated or manual packing lines.
- Converts finished honeycomb paper rolls into sheets for direct use in packaging lines
- Dual roll feeding enables continuous operation and higher throughput than single roll models
- Produces sheets up to 999 mm in length and 550 mm in width with consistent edge quality
- Built for integration with downstream packaging equipment like kraft paper wrappers
- Reduces manual handling and cutting time compared to hand-trimming finished rolls
Why Buyers Choose It
- Manual cutting of honeycomb rolls is slow and inconsistent in sheet size
- Inconsistent sheet lengths cause misalignment in automated packaging lines
- Finished honeycomb rolls are difficult to handle and feed into small packaging machines
- Lack of sheeting capacity forces packers to buy pre-cut pads at a premium
- Single roll feeding limits throughput when processing high volume orders
Who Runs This Machine
- Packaging converters that already produce honeycomb paper and want to add sheeting capability
- E-commerce fulfilment operators using automated bagging lines that require pre-cut pads
- Paper slitting houses adding value to honeycomb rolls by converting them to sheets
- Furniture and appliance packers needing consistent-sized protective pads
Where This Machine Is Used
- Protective packaging producers converting honeycomb rolls into sheets for e-commerce fulfilment
- Fulfilment centres using pre-cut honeycomb pads to wrap fragile electronics and glassware
- Paper converters adding a finishing step to their honeycomb production line
- Packers replacing plastic inserts with pre-cut paper pads for retail-ready packaging
- Small to mid-sized manufacturers needing a compact solution for sheeting honeycomb rolls
Features And Specifications
Technical features
- Dual roll feeding system for continuous processing of two honeycomb paper rolls
- Max cutting width of 550 mm allows for large sheet formats suitable for bulk packaging
- Max cutting length of 999 mm supports full sheet production without repositioning
- Production capacity of 30 to 60 m/min adjusts to match downstream line speed
- 2.5 kW power supply supports stable operation under continuous load
- Conveyor system included to move finished sheets forward and collect them in batches
- Robust frame with 3800 x 1200 x 1200 mm dimensions ensures stable operation
- Machine weight of 900 kg provides stability during high-speed cutting
Specifications
| Machine model | HQ 600-2 rolls |
|---|---|
| Max cutting width | 550 mm |
| Max cutting length | 999 mm |
| Production capacity | 30-60 m/min |
| Power | 2.5 kW |
| Machine dimension | 3800 x 1200 x 1200 mm (L x W x H) |
| Machine weight | 900 kg |
How The Machine Runs
Materials
- Finished honeycomb paper rolls from Snda's honeycomb forming or die cutting machines
- Optional tissue paper backing for laminated honeycomb sheets
- Cardboard dispensers for finished sheets (if integrated with wrapper)
Quality Control
- Adjustable feed rollers maintain consistent tension to prevent web distortion
- Die-cutting blades are calibrated to produce clean edges without fraying
- Conveyor belt alignment ensures sheets are collected without skewing
- Machine is test run with customer’s honeycomb paper before shipment
- All moving parts are checked for smooth operation and alignment
Customisation
- Cutting length can be adjusted to match specific packaging line requirements
- Conveyor system can be extended or modified for different output collection methods
- Roll feed stands can be adapted for different roll core sizes
- Optional integration with Snda’s kraft paper packaging machine or wrapper
- Power supply can be built to match the voltage and frequency of the destination country
Certifications
- ISO9001:2000 certificate obtained in 2005
- CE certificate obtained in 2006
How It Compares
| Manual cutting of honeycomb rolls | This machine produces consistent sheet sizes faster and with less operator fatigue |
|---|---|
| Single roll feeding machine | Dual roll feeding increases throughput and reduces downtime between roll changes |
| Buying pre-cut honeycomb pads | Converting in house removes the supplier margin but requires investment in the machine and roll inventory |
Running It On Your Floor
- Ensure both honeycomb rolls are properly loaded and aligned on the feed stands
- Set the target sheet length on the control panel before starting the run
- Start at low speed and increase gradually while monitoring web tracking
- Check the first few sheets for clean cuts and correct dimensions
- Keep the die-cutting blades clean and free of paper residue to maintain edge quality
Honeycomb Paper Cutting Machine-2 roll FAQ
What is the maximum sheet size it can cut
It can cut sheets up to 550 mm in width and 999 mm in length.
How fast does it run in production
The machine operates at 30 to 60 m/min, depending on paper thickness and feed stability.
Can it handle two different roll sizes at once
Yes, it supports dual roll feeding, but both rolls must be compatible with the machine’s feed system.
What power supply do you build it for
Standard is 2.5 kW, and we build to the voltage and frequency of your country on request.
Is the conveyor included in the machine
Yes, the conveyor system is included to move finished sheets forward and collect them in batches.
Do you hold quality certificates
Wenzhou Snda Machinery holds an ISO9001:2000 certificate obtained in 2005 and a CE certificate obtained in 2006.
