High Speed Paper Sheeter
The HQ-H1400 and HQ-H1700 convert large rolls of paper into individual sheets at high speed, with cutting accuracy within +/-0.4mm. These machines are designed for paper converters and slitting houses that need to process kraft paper, wrapping paper, or other paper types into standard sheet sizes for packaging or printing. The process runs continuously from unwinding to cutting, allowing one operator to manage the line.
- Converts paper rolls into sheets at up to 300 cuts per minute, increasing throughput compared to manual or slower cutting methods
- Cutting accuracy of +/-0.4mm ensures consistent sheet dimensions across all output
- Handles paper up to 500 gsm and widths up to 1700 mm, suitable for heavy-duty packaging materials
- Built for continuous operation with a maximum cutting speed of 300 m/min
- Single-pass processing reduces handling and minimizes waste from misalignment
Why Buyers Choose It
- Manual or semi-automated cutting is slow and inconsistent compared to machine-based sheeting
- Inaccurate sheet dimensions lead to misfit in packaging or printing processes
- Lack of sheeting capacity forces reliance on third-party processors with long lead times
- Inability to handle high grammage paper (up to 500 gsm) limits material options
- Low throughput from older or non-automated sheeters reduces production efficiency
Who Runs This Machine
- Paper converters processing kraft paper reels into sheeted output
- Slitting houses expanding into sheeting for added value
- Packaging producers using cut sheets for inserts or protective layers
- Printing companies requiring high-speed sheeting of paper for downstream processes
Where This Machine Is Used
- Paper converters producing standard-sized sheets for corrugated box inserts or protective packaging
- Slitting houses adding sheeting capability to their existing reel processing lines
- Packaging producers preparing pre-cut sheets for folding into boxes or inserts
- Printing facilities needing high-volume sheeting of kraft or coated paper
- Manufacturers of paper-based protective packaging requiring precise sheet dimensions
Features And Specifications
Technical features
- Unwinding system with adjustable tension control for stable web handling
- Precision rotary knife cutting with automatic blade adjustment
- Automatic sheet stacking and discharge for continuous operation
- Pneumatic air pressure system operating at 0.8 MPa for reliable cutting force
- Inverter-driven main motor for speed control and smooth acceleration
- Integrated control panel with digital display for cutting length and speed settings
- Robust frame construction to support high-speed operation and heavy paper rolls
- Cutting length range from 400 to 1600 mm, suitable for standard packaging sheet sizes
Specifications
| Machine model | HQ-H1400, HQ-H1700 |
|---|---|
| Max paper width | 1400 mm (55 inch) for HQ-H1400, 1700 mm (67 inch) for HQ-H1700 |
| Max paper diameter | 1650 mm (65 inch) |
| Max paper grammage | 500 gsm |
| Cutting length range | 400 to 1600 mm |
| Cutting accuracy | +/-0.4 mm |
| Max cutting speed | 300 cuts per minute |
| Max cutting meter speed | 300 m/min |
| Power supply | AC 380 V / 220 V x 50 Hz |
| Total power | 25 kW for HQ-H1400, 28 kW for HQ-H1700 |
| Atmospheric pressure | 0.8 MPa |
| Machine dimensions | 12 m × 3.9 m × 2.35 m for HQ-H1400, 12 m × 4.2 m × 2.35 m for HQ-H1700 |
How The Machine Runs
Materials
- Kraft paper reels up to 500 gsm
- Wrapping paper and protective paper
- Coated paper and paperboard for packaging
- Other paper types within the 50–500 gsm range
Quality Control
- Cutting accuracy is verified during test runs using sample paper
- Tension control system maintains consistent web stability to prevent slippage
- Blade alignment is checked before each production run to ensure clean cuts
- Machine is tested with customer paper before shipment to confirm performance
- Control panel displays real-time feedback on cut length and speed
Customisation
- Cutting length and number of cuts can be programmed for batch runs
- Power supply can be adapted to match voltage and frequency of the destination country
- Frame and support structure can be modified for site-specific installation
- Additional stacking or conveying systems can be added for integration with downstream lines
Certifications
- ISO9001:2000 certificate obtained in 2005
- CE certificate obtained in 2006
How It Compares
| Manual or semi-automated sheeting | The machine offers higher speed, consistent accuracy, and reduced operator fatigue |
|---|---|
| Lower-speed sheeters | This machine achieves 300 cuts per minute and 300 m/min cutting speed, suitable for high-volume production |
| Sheeting machines with lower grammage limits | It handles up to 500 gsm, allowing use of heavier packaging and protective papers |
Running It On Your Floor
- Ensure the power supply matches the local voltage and frequency before connecting
- Verify the paper roll is centered on the unwinding shaft before starting
- Set the target sheet length and number of cuts on the control panel before running
- Run a test cut with a short length to confirm blade alignment and accuracy
- Keep the cutting blades clean and free of debris to maintain sharpness and cut quality
High Speed Paper Sheeter FAQ
What paper weights can the machine handle
It is designed for paper from 50 to 500 gsm, including kraft paper, wrapping paper, and protective paper.
What is the maximum sheet length it can cut
The cutting length range is 400 to 1600 mm, suitable for standard packaging sheet sizes.
How fast does it cut in production
The maximum cutting speed is 300 cuts per minute, with a maximum cutting meter speed of 300 m/min.
What power supply do you provide
Standard is AC 380 V / 220 V x 50 Hz, and we can build to the voltage and frequency of your country on request.
What are the machine dimensions and weight
The HQ-H1400 is 12 m × 3.9 m × 2.35 m and weighs 11,000 kg; the HQ-H1700 is 12 m × 4.2 m × 2.35 m and weighs 13,000 kg.
Can it cut heavy paper like 500 gsm
Yes, the machine is rated for paper up to 500 gsm, including thick kraft and protective paper.
Do you hold quality certificates
Wenzhou Snda Machinery holds an ISO9001:2000 certificate obtained in 2005 and a CE certificate obtained in 2006.
