36sqm Indoor Rental LED Screen for Jalisco Travel Fest Mexico
36sqm · Model X6 P6.25 · Jalisco, Mexico · Delivered July 2017
| Product Model | X6 P6.25 |
|---|---|
| Screen Size | 36sqm |
| Location | Jalisco, Mexico |
| Venue | Jalisco Travel Fest |
| Delivered | July 2017 |
| Product Supplied | Rental LED Screen X Series |
| Sector | Exhibitions and Conferences |
Client Background
The buyer is not named in our project records. What is documented is the screen itself: a 36sqm indoor rental LED wall supplied on X6 P6.25 cabinets for the Jalisco Travel Fest in Jalisco, Mexico, delivered in July 2017. A wall of this size on rental cabinets is bought by a rental and staging operation rather than by a venue.
The Project Challenge
Build a 36sqm indoor LED wall for a travel festival that must be installed and struck quickly, with no rear access, and must maintain visual continuity across a curved or shaped layout without visible seams.
Customer Pain Points
- 36sqm is a large wall to install and strike within a tight event schedule
- Cabinets that require tools or shimming will delay setup and increase labour cost
- Front maintenance is required because the screen is mounted against a wall with no rear access
- A curved or shaped screen must maintain consistent pixel pitch and alignment across all cabinets
- The screen must be lightweight enough to be hung from truss or supported on the ground without structural strain
Our Solution
The wall was supplied on X6 P6.25 rental cabinets with a slim and lightweight die-cast aluminium cabinet at 26kg per square metre, available in 500x500mm and 500x1000mm formats. The cabinets feature a fast lock system with high precision positioning, angle adjustment for curved builds, truss hanging and ground support options, and front and rear access for module replacement. The design allows tool-free installation and supports both concave and convex floor screen configurations.
Manufacturing Process
- SMT placement and reflow soldering of the LED modules
- Soldering inspection and module ageing test before assembly
- Cabinet assembly with flatness alignment on the assembling line
- Screen installation test with the cabinets built up as a wall
- Screen ageing test before the wall was dismantled and packed
Supply Chain Coordination
Cabinets were packed together with spare modules, receiving cards, and power supplies so the crew had field spares from the first event rather than waiting on a second shipment.
Quality Control
Modules passed soldering inspection and an ageing test, and the cabinets were built up as a wall in the factory for a screen installation test and a screen ageing test, which is what matches brightness and colour across cabinets before they ship.
Final Result
Documented delivery: 36sqm of X6 P6.25 indoor rental LED screen, supplied for Jalisco Travel Fest in Jalisco, Mexico, in July 2017.
Customer Benefit
Tool-free fast lock rigging enables rapid installation and strike, and factory-matched cabinets ensure consistent brightness and colour across the entire wall, even when modules are replaced during the event.
