Chain Alignment Tools
Laser or bar type alignment gauge for setting rear sprocket alignment
A chain alignment tool mounts on the rear sprocket and projects a reference line forward, so a mechanic can see whether the front and rear sprockets are in the same plane. Misalignment is the most common reason a chain and sprocket set wears out early.
Who Buys This
- Motorcycle workshops and race teams
- Rental and delivery fleets on a chain replacement cycle
- Tool retailers and dealer parts counters
- Mobile mechanics
Problems It Solves
- Chains and sprockets wearing out well before their expected life
- Adjuster marks on the swingarm that do not match reality
- Aligning by eye and getting it wrong
Key Features
- Mounts to the rear sprocket
- Projects a reference line to the front sprocket
- Machined body in several colours
- Compact enough for a mobile tool roll
Products
1 Chain Alignment Tools Product
Each product page carries the manufacturer's own photographs of that exact pattern.
Specification
Technical Data
Figures published by the manufacturer. Anything not confirmed is marked so, rather than estimated.
- Type
- Chain and sprocket alignment gauge
- Mounting
- Rear sprocket
- Body
- Machined alloy
- Use
- Motorcycle chain drive alignment
Customisation
Options We Can Change
- Colour
- Retail or bulk packaging
- Logo marking
Related
Other Motorcycle Repair Tools Collections
Wheel Balancers
Static bench wheel balancer stands for motorcycle wheels
2 Products →
Cable Lubers
Clamp on cable oiler that pushes lubricant down the inner cable
1 Product →
Chain Breaker Tools
420 to 530 chain removal tool with interchangeable handles and pins
1 Product →
Steel Tyre Bead Breakers and Levers
Chrome finished steel tyre levers for breaking and seating a bead
1 Product →
Tyre Pressure Gauges
Braided hose dial gauges with a bleed valve for motorcycle tyres
1 Product →
Tyre Stone Removal Hooks
Hooked pick for lifting stones and debris out of a tyre tread
1 Product →Knowledge
Guides Related To This Collection
FAQ
Chain Alignment Tools FAQ
Is it better than the swingarm marks?
Yes. Swingarm marks are stamped during production and are often not accurate. An alignment gauge measures the actual sprocket plane.
Does it fit any sprocket size?
Send us the sprocket range you need to cover and we will confirm the pattern.
Do I still need to set chain slack?
Yes. Alignment and slack are two separate adjustments and both matter.
Next Step
Request A Quote For Chain Alignment Tools
Tell us the quantity, the colours or sizes you need and your destination market, and we will quote against a written specification.
