Dump Trucks

China 8x4 Dump Truck 40 Tons Loading Capacity

An 8x4 HOWO T5G dump truck with a 40-ton loading capacity, powered by an MC07 engine offering 280-336HP in Euro 3, 4 or 5 configurations. It features a HW13710 10-speed manual gearbox, a 300-litre fuel tank and a 14800-14950kg kerb weight. This configuration suits demanding construction and mining applications where payload is critical.

Condition New
Horsepower 251-350hp
Engine Euro3-Euro6
Truck Model T5G 8x4 Dump Truck
Drive Wheel 8x4

Ask for a Price on WhatsApp Email the Specification

Stock number held for this listing: 10026

White HOWO T5G 8x4 dump truck parked on a yard, side view

Key Benefits

What This Unit Does Well

40-ton loading capacity maximizes transport efficiency per trip
MC07 engine with Euro 3-5 options balances power with emissions compliance
HW13710 gearbox provides a wide range of ratios for varied terrain
300-litre fuel tank supports extended operation between refuelling stops
Forged I-beam axles and robust suspension handle heavy loads reliably
Comprehensive braking system ensures safe operation even when fully loaded

Application Scenarios

Where It Is Used

Hauling aggregates from a quarry to a construction site over rough access roads
Transporting excavated material from a large-scale civil engineering project
Moving bulk materials around a mining operation with steep gradients
Delivering concrete to building sites in urban and suburban areas
Removal of demolition debris from a construction or demolition site

Fit

Who It Is For

Construction companies needing a reliable and high-capacity dump truck
Mining operations requiring robust vehicles for material transport
Quarry operators seeking efficient vehicles for aggregate removal
Infrastructure projects demanding heavy-duty dump truck solutions
Rental companies supplying dump trucks to construction and mining clients

Buyer Pain

Problems It Solves

Under-capacity dump trucks requiring more trips to move the same volume
High fuel consumption from underpowered or poorly geared trucks
Frequent breakdowns due to inadequate suspension or axle strength
Difficulty complying with local emissions regulations
Uncertainty over the true loading capacity of imported vehicles

Engineering

Technical Features

HOWO T5G series 8x4 dump truck chassis
MC07 engine compliant with Euro 3, 4 or 5 emission standards
HW13710 ten-speed manual transmission with multiple gear ratios
Forged I-beam front axles with drum brakes
457 central single reduction rear axles with drum brakes
Semi-elliptical leaf spring suspension with shock absorbers

Specification

Specification Table for This Listing

Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.

Specification of China 8x4 Dump Truck 40 Tons Loading Capacity
Condition	New
Horsepower	251-350hp
Engine	Euro3-Euro6
Truck Model	T5G 8x4 Dump Truck
Drive Wheel	8x4
Loading Capacity	40 tons
Engine Model	MC07
Emission	Euro 3/4/5
Transmission	HW13710, 10-speed manual
Fuel Tank Capacity	300 L
Front Axle	153, forging I-beam
Rear Axle	457, central single reduction
Wheelbase	2500~3000 mm
Overall Length	8480~9230 mm
Overall Width	2496 mm
Overall Height	3035 mm
Kerb Weight	14800~14950 kg
Gross Vehicle Weight	35000 kg
Capacity (Load)	31 - 40t
Transmission Type	Manual
Fuel Type	Diesel
Engine Capacity	6 - 8L
L X W X H) (mm)	(8480~9230) x 2496 x 3035

Materials

Materials and Build

High tensile steel frame with 3000 x 80 x (8+5) mm section
Forged I-beam steel front and rear axles
Leaf spring suspension components
Steel cab with lockable rectangular 300L fuel tank
11.00-20 radial tyres on 8.00-20 steel wheels

Process

How an Order Is Handled

You specify the required Euro emission standard and axle ratio
We confirm availability and provide a detailed specification sheet
You approve the final specification and place a deposit
The truck is prepared, inspected and photographed before loading
We arrange RoRo or container shipment and provide export documentation

Quality Control

Checks Before Loading

Chassis and engine numbers are verified against your order
Engine start and gearbox operation are tested before shipment
Paintwork and body panels are inspected for damage
Third-party inspection is welcome at your cost and arrangement
Loading photos are provided before the vessel departs

Customisation

What Can Be Changed

Euro 3, 4 or 5 engine emission standard
Axle ratio to suit specific terrain and load requirements
Tyre brand and tread pattern
Fuel tank capacity (within limits)
Cab colour and interior trim options

Honest Comparison

How It Compares With the Alternatives

6x4 dump truck	8x4 provides superior weight distribution and traction for heavier loads but has a higher purchase cost
Smaller 30-ton dump truck	40-ton capacity reduces the number of trips needed, improving efficiency but requires a higher initial investment
Euro 6 emission dump trucks	Euro 3/4/5 options may be more suitable for regions without strict emission controls, reducing complexity and cost

Use Guide

Using It Well

Follow the recommended maintenance schedule for the MC07 engine
Inspect leaf springs and shock absorbers regularly for wear
Use appropriate tyre pressure for the load and terrain
Ensure the exhaust valve brake is functioning correctly

Photographs

More Views of This Unit

Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.

Close-up of the HOWO dump truck's cab and front end

Rear view of the HOWO dump truck showing the dump bed

Front view of the HOWO dump truck with the engine visible

Close-up of the HOWO dump truck's wheels and tyres

Side view of the HOWO dump truck showing the chassis

Source Specification

Manufacturer Text We Hold for This Listing

China 8x4 dump truck 40 tons loading capacity Detailed parameters Vehicle series T5G 8x4 Dump Truck Cab T5G-M Engine Model MC07 Power(Ps/rpm) Euro 3/4/5 (280-336)/2300 Maximum torque(Nm/rpm) Euro 3/4/5 (1100-1250)/1200-1800 Displacement(L) 6.87 Transmission HW13710 10-speed manual control gearbox Ratio:1 14.08,2 10.47,3 7.82,4 5.82,5 4.35,6 3.24,7 2.41,8 1.80,9 1.34,10 1.00,R1 12.67,R2 2.91 Clutch Φ430 diaphragm spring clutch,Single plate Front axle 153, forging I-beam front axle,Drum brake/HF7, forging I-beam front axle,Drum brake Rear axle 457, central single reduction,Drum brake i=5.833, optionali=5.286 Suspension Steer Axle Semi-elliptical leaf springs with shock absorbers and stabilizer Drive Axle Bogie leaf springs with integrated balance shaft and stabilizer Braking system Type Air brake system Service brake Dual-circuit air brake Parking Brake Spring energy, compressed air operat

Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
