Dump Trucks
70ton Mining Dump Truck 6*4 Tipper Truck
- ConditionNew
- SteeringZF8098
- Tire14.00-25
Dump Trucks
Brand New Dump Truck Loading Capacity with High Quality
The ZZ3257N3447A chassis features a 3175+1400mm wheelbase, 295/80R22.5 tyres, and a 12160kg curb weight, with a 32500kg GVW and a 31-40 tonne payload capacity. It is built to Euro 2 emission standards and is currently available in stock for immediate shipment from Shandong, China.
- Condition New
- Cab HW76
- Color white,yellow,red,black
- Transmission HW19712
- Tire 295/80R22.5
Stock number held for this listing: 10133
Key Benefits
What This Unit Does Well
- HW19712 ten-speed gearbox provides strong low-end torque for loaded hauls and efficient cruising on return runs
- 3175+1400mm wheelbase balances stability on rough terrain with manoeuvrability in tight construction yards
- 295/80R22.5 tyres are standard for heavy-duty dump operations and offer good load support and tread life
- 32500kg GVW allows full payload capacity without exceeding common regional weight limits
- Cab model HW76 provides a durable, factory-fitted interior with standard air conditioning and driver visibility
Application Scenarios
Where It Is Used
- Dumping aggregate at a quarry with uneven access roads and frequent loading cycles
- Transporting coal from a mine to a rail transfer point on unpaved, high-slope routes
- Urban construction site work where the truck must navigate tight turns and frequent stops
- Long-haul dump runs between a material depot and a remote infrastructure project with limited service points
Fit
Who It Is For
- Fleet owners replacing older dump trucks and seeking a reliable, high-load capacity unit with parts availability
- Contractors operating in mining or civil engineering projects where consistent payload and durability are critical
- Machinery dealers stocking dump trucks for resale in markets with limited access to OEM parts
- Government procurement teams sourcing heavy-duty vehicles for public infrastructure projects
Buyer Pain
Problems It Solves
- Downtime caused by engine parts that are not available locally due to fragmented spare parts supply
- Underpowered trucks that struggle on loaded gradients and burn excessive fuel to compensate
- Inconsistent chassis codes and axle configurations that delay import licensing and customs clearance
- Lack of available stock for urgent project timelines, leading to project delays
Engineering
Technical Features
- Direct injection fuel system rated to EURO 2 emission standard
- HW19712 manual transmission with ten forward gears and two reverse gears
- Front axle and rear axle in 6x4 drive layout with 3175+1400mm wheelbase
- Single sleeper cab with factory air conditioning and standard instrument panel
- Dump box with hydraulic lift system and tailgate for controlled unloading
Specification
Specification Table for This Listing
Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.
| Condition | New |
|---|---|
| Cab | HW76 |
| Color | white,yellow,red,black |
| Transmission | HW19712 |
| Tire | 295/80R22.5 |
| Brand | SIONTRUK |
| Type | DumpingTruck |
| Horsepower | 251-350hp |
| Engine | WD615/336HP |
| Truck Model | ZZ3257N3447A |
| Drive Wheel | 6x4 |
| Dimensions L x W x H unloaded | 7835 x 2496 x 3170 mm |
| Wheelbase | 3175+1400 mm |
| Curb Weight | 12160 kg |
| Engine Model | WD615/336HP |
| Emission | EURO 2 |
| Fuel Type | Diesel |
| Front Axle | Standard 6x4 |
| Rear Axle | Standard 6x4 |
| Tyre | 295/80R22.5 |
| Gross Vehicle Weight | 32500 kg |
| Payload Capacity | 31-40 tonnes |
| Max Speed | 76 km/h |
| Min Turning Circle | 15 m |
| Min Ground Clearance | 314 mm |
| Engine Capacity | >8L |
Materials
Materials and Build
- Welded steel ladder frame chassis in the ZZ3257 series
- Steel cab shell with factory paint finish in white, yellow, red or black
- Cast steel front and rear axle housings
- 295/80R22.5 radial tyres on steel rims
- Hydraulic lift system with steel frame and pivot joints for dump box
Process
How an Order Is Handled
- You send the route profile, payload type and site access conditions you will operate in
- We confirm the available stock of ZZ3257N3447A units with the current chassis number and engine hours
- You choose the cab colour, tyre size and optional dump box customisation before deposit
- Unit is prepared, photographed and video recorded with engine start and gear engagement
- We book RoRo shipment and issue the export documents your customs needs
Quality Control
Checks Before Loading
- Chassis, engine and transmission numbers are photographed and matched to the specification sheet you approved
- Engine start, gear engagement and hydraulic lift function are recorded on video before loading
- Paint, glass and cab trim are checked for transport damage at the loading port
- Loading and lashing photos are sent before the vessel departs
Customisation
What Can Be Changed
- Dump box dimensions and thickness as per customer's design or standard sizes
- Cab colour: white, yellow, red or black
- Tyre size: 295/80R22.5 standard, or optional 12.00R20/11.00R20/12.00-20/12R22.5
- Additional tool box, fifth wheel height or lighting package
- OEM branding or customer logo on cab or chassis
Honest Comparison
How It Compares With the Alternatives
| 4x2 dump truck | The 6x4 has better traction and load capacity on soft or uneven ground but uses more fuel when running empty |
|---|---|
| 8x4 dump truck | The 6x4 is lighter and more fuel-efficient for medium-duty hauls, but lacks the axle support for extreme off-road or heavy load scenarios |
Use Guide
Using It Well
- Replace fuel and oil filters on the interval recommended for WD615 engines, not on a generic schedule
- Keep the hydraulic system reservoir topped with the correct fluid type to prevent pump wear
- Order the clutch plate, injector set and axle seals with the truck to avoid service delays
Photographs
More Views of This Unit
Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.
Source Specification
Manufacturer Text We Hold for This Listing
Dump Truck Loading Capacity With High Quality Product Description Now we have 10 units 6x4 dump truck ready for shipment, which were produced in 2014, price is very good. Model Shacman Dump Truck Dirving Type 6x4, 8x4, 4x2 Complete kerb mass(kg) 12160 GVW(kg) 32500 LxWxH(mm) 8250*3450*2500mm Front/rear overhang(chassis) 1525/1450 Wheel base (mm) 3175+1400 Track width (mm) 2036/1850 Engine brand Weichai Engine Power(kw/hp) 247/336 Emission standard Euro 2 Max. speed ( km/h) 76 Min. turning circle (m) 15 Min. ground clearance (mm) 314 Type(standard) 11.00-20 Optional 12.00R20/11.00R20/12.00-20/12R22.5 Note: Box of dump truck can be customized as customer's request. Packaging & Shipping Packaging: nude or polish with wax Shipping: RORO transport Our Services 1.Reply your inquiry in 12 working hours; 2.Experienced staffs answer all your questions; 3.Custormer's design is available for certai
Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
Related Listings
Other Dump Trucks Buyers Compare With This
Dump Trucks
2023 NEW 371 Hp 6x4 Mining Dump Truck 70 Ton Tipper Truck
- ConditionNew
- CabHOWO7D,withAirconditioner
- Tire14.00-25
Dump Trucks
China Wholesale Dump Truck 6*4 for Sands/coal Minerals
- ConditionNew
- CabHOWO70(nobed),withAircondi
- Tire12.00R20(Radial)
Dump Trucks
Chinese Low Fuel Consumption Dump Truck Factory Price
- ConditionNew
- CabL2000,withAirconditioner
- Tire11.00R20(Radial)
Dump Trucks
China 336hp 6x4 Construction Sand and Gravel Loading Dump Truck
- ConditionNew
- Horsepower336HP
- Truck ModelSX3256DV384C
Dump Trucks
China 8*4 New and Used Dump Truck 50t for Afirica
- ConditionNew
- ColorRed
- Horsepower351-450hp
Buyer Questions
Questions About This Unit
Is this unit new or used
All units are new. The model was produced in 2014, but they are stored in a dry warehouse and have not been operated. We confirm the chassis number and engine hours before shipment.
What is the lead time
Units in stock can be prepared and loaded within 7 working days. If you require a custom configuration, lead time depends on the plant schedule and is confirmed in writing with the proforma invoice.
Can you supply spare parts for this truck later
Yes. WD615 filters, injectors, clutch parts, axle components and hydraulic seals are available and can be shipped separately or consolidated with the truck order.
Do you ship by container or RoRo
We ship by RoRo for dump trucks. Container shipment is possible but requires cab lowering and is not standard. We quote both options so you can compare landed cost.
What documents do I get for customs
Commercial invoice, packing list, bill of lading, certificate of origin, and a pre-shipment inspection certificate if required by your country.
Price This Unit Against Your Port
Send the destination and quantity. A written specification, landed cost and shipping option comes back.
