Truck Cranes

New 30 Ton Hydraulic Truck Crane Price QY30V532

A new 25-ton hydraulic truck crane model QY25K-II with a 4-section telescopic boom, built on a SHANGCHAI SC8DK280Q3WD615.329 engine rated at 206/213 kW, delivering 1112 N.m of torque at 1400 rpm. It is designed for construction site mobility and lifting in regions where spare parts and technical support must be available locally.

  • Condition New
  • Warranty 1Year
  • Feature TruckCrane
  • Span 8m
  • Certification ISO
Ask for a Price on WhatsApp Email the Specification

Stock number held for this listing: 11532

White QY25K-II hydraulic truck crane parked on a yard, front three-quarter view with boom extended
White QY25K-II hydraulic truck crane parked on a yard, front three-quarter view with boom extended
Key Benefits

What This Unit Does Well

  • SHANGCHAI SC8DK280Q3WD615.329 engine is widely used across Chinese crane fleets, so filters, injectors and oil are easy to source
  • 25-ton rated capacity and 961 kN.m lifting moment handle standard construction loads without over-specifying
  • 39.2 m main boom and 47.2 m extended boom with jib cover most site lifting tasks without needing a second crane
  • ISO certification supports customs clearance and procurement compliance in regulated markets
  • 1-year warranty includes field installation, commissioning and training, reducing first-time setup risk
Application Scenarios

Where It Is Used

  • Lifting steel beams and precast panels at a mid-rise construction site with limited access roads
  • Installing heavy machinery in industrial plants where crane mobility and boom reach are critical
Fit

Who It Is For

  • Construction contractors needing a mobile crane that matches existing Chinese crane parts supply chains
  • Fleet managers replacing older cranes and seeking a model with proven engine and hydraulic reliability
  • Engineering procurement teams sourcing equipment for projects in Southeast Asia, Africa or the Middle East
  • Machinery dealers stocking cranes for resale in markets where ISO certification is required
Buyer Pain

Problems It Solves

  • Lack of local spare parts for foreign crane models that require proprietary filters or hydraulic seals
  • Downtime caused by waiting for engineers or parts to arrive from Europe or North America
  • Crane units that cannot reach required lifting heights due to short boom lengths or weak lifting moment
  • Uncertainty over export documentation and certification when importing from China
  • Inconsistent engine performance due to mismatched or unverified powertrain components
Engineering

Technical Features

  • SHANGCHAI SC8DK280Q3WD615.329 turbocharged six-cylinder diesel engine with dual power ratings
  • Hirschmann PAT hydraulic system for precise boom control and load stability
  • 4-section telescopic boom with base length of 10.5 m and fully extended reach of 39.2 m
  • Maximum lifting height of 52 m with optional jib extension to 47.2 m
  • 1112 N.m rated torque at 1400 rpm for strong lifting performance under load
  • Heater installed for cold-weather operation in northern climates
Specification

Specification Table for This Listing

Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.

ConditionNew
Warranty1Year
FeatureTruckCrane
Span8m
CertificationISO
ModelGtruckcraneQY25K-II
ApplicationConstructionIndustry
Rated Lifting Capacity25 T
Max. Lifting Height52 m
Base Boom Length10.5 m
Fully Extended Boom39.2 m
Fully Extended Boom + Jib47.2 m
Max. Lifting Torque961 kN.m
Engine ModelSC8DK280Q3WD615.329
Engine Rated Power206/213 kW at 2200 rpm
Engine Rated Torque1112 N.m at 1400 rpm
Max. Travel Speed75 km/h
Approach Angle16° / 13°
Departure Angle13°
Max. Grade Ability30% / 40%
Fuel Consumption for 100km39 L
Place of OriginJiangsu, China (Mainland)
Crane ConditionNew
Rated Loading Capacity25000kg
Rated Lifting Moment961kn.m Max.
Lifting Height52m
Materials

Materials and Build

  • Welded steel chassis frame with high-strength steel components
  • Steel boom sections with anti-corrosion coating
  • Hirschmann PAT hydraulic system with steel and rubber hoses
  • Heater unit for cab and engine compartment in cold climates
  • Rubber suspension mounts for engine and transmission
Process

How an Order Is Handled

  • You provide the site access conditions, lifting height, and load weight you need
  • We confirm the QY25K-II configuration is available in stock or can be built to order
  • You review the final spec sheet, including engine, boom length, and cab heater
  • We prepare the unit, photograph and video record the engine and boom operation
  • We book RoRo or container shipment and provide export documents for customs
Quality Control

Checks Before Loading

  • Engine and chassis numbers are photographed and matched to the approved specification
  • Boom extension and hydraulic pressure are tested and recorded on video before loading
  • Cab heater, lights, and safety warning systems are checked for function at the yard
  • Loading and lashing photos are sent before the vessel departs
Customisation

What Can Be Changed

  • Add or remove cab heater based on climate needs
  • Change boom extension length within the standard 10.5 m to 39.2 m range
  • Install additional jib for extended reach beyond 47.2 m
  • Change cab colour from standard white to another RAL code
  • Add extra tool box or storage compartment on the chassis sides
Honest Comparison

How It Compares With the Alternatives

Crane with imported engine (e.g. Cummins)SHANGCHAI engine parts are stocked locally in Africa and Southeast Asia, reducing downtime
Crane with 5-section boomThe 4-section boom is lighter and easier to transport, but offers less reach than a 5-section model
Use Guide

Using It Well

  • Run the first 100 hours at reduced load and check hydraulic fluid levels and boom pin torque
  • Replace hydraulic oil and filters at the interval recommended for SHANGCHAI engines
  • Keep the heater operational during cold weather to prevent engine and hydraulic system freeze-up
  • Order spare hydraulic seals and boom pins with the crane to avoid delays in first maintenance
Photographs

More Views of This Unit

Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.

Rear view of the crane with fifth wheel coupling, rear axle, and hydraulic system access panelCab interior with heater control, air conditioning, and driver seatEngine compartment of the SHANGCHAI SC8DK280Q3WD615.329 engine with radiator and hosesBoom section detail showing the 4-section telescopic mechanism and pin connectionsWire rope and sheave system at the top of the boom with load hook and safety latch
Source Specification

Manufacturer Text We Hold for This Listing

New 30 ton hydraulic Truck Crane price QY30V532 QY25K-II 4-Section Boom 25t Hydraulic Truck Crane Price Main parameters: Max. rated total lifting capacity: 25 T Fully extended boom: 39.2 M Fully extended boom+ jib: 47.2 M Main configuration: * SHANGCHAI engine, SC8DK280Q3WD615.329 ( 206/213 k w) * Wire rope * Hirschmann PAT * Heater Dimension Unit QY 25K5-I Overall length mm 12 300 Overall width mm 2500 Overall height mm 32 9 0 /3380 Weight Total weight in travel kg 31750 Front axle load kg 6 55 0 Rear axle load kg 252 00 Power Engine model SC8DK280Q3WD615.329 Engine rated power kW/(r/min) 206 /2200 213 /2200 Engine rated torque N.m/(r/min) 1112 /1400 1160/1100-1600 Travel Max. travel speed km/h 75 /80 Min. turning diameter mm 2 15 00 Min. ground clearance mm 27 2 Approach angle ° 16/13 Departure angle ° 13 Max. grade ability % 30/40 Fuel consumption for 100km L 39 Main performance Max.

Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.

Related Listings

Other Truck Cranes Buyers Compare With This

All 21 Truck Cranes Full product index

Buyer Questions

Questions About This Unit

Is this unit new or used

The unit is new. We confirm the chassis number and engine hours before shipment.

Can you supply spare parts for this crane later

Yes. SHANGCHAI engine filters, hydraulic seals, boom pins and wire rope are among the most frequently shipped parts.

Do you ship by container or RoRo

The crane is typically shipped RoRo. Container shipment is possible but requires lowering the cab and may affect boom clearance.

What documents do I get for customs

Commercial invoice, packing list, bill of lading, certificate of origin, and ISO certification are included. Pre-shipment inspection certificates are available upon request.
