Truck Cranes
50 Ton Telescopic Boom Truck Mounted Crane QY50KA in Algeria Truck Crane
- ConditionNew
- Warranty2000HOURS
- FeatureTruckCrane
Truck Cranes
8ton Mobile Hydraulic Truck Crane Price
A 25-ton mobile hydraulic truck crane model QY25K-II built on a ST5-I chassis with a D6114ZLQ5B engine rated at 158kW, featuring a 4-section telescopic boom with a base length of 10.5m and a maximum lifting height of 52m. It has a rated lifting moment of 961kN.m and a maximum rated total lifting capacity of 25 tonnes, with outriggers spanning 4.0x3.0m. Designed for construction site use, it operates with a lifting speed of 26(52)m/min and a maximum travel speed of 75km/h. The unit is new, comes with a one-year warranty, and is certified to ISO standards.
- Condition New
- Warranty 1Year
- Feature TruckCrane
- Span 8m
- Certification ISO
Stock number held for this listing: 11532
Key Benefits
What This Unit Does Well
- 25-ton rated lifting capacity supports heavy lifting in construction and infrastructure projects
- 52m maximum lifting height allows access to high-level structural work without repositioning
- 4-section telescopic boom provides extended reach and flexibility on tight sites
- Outriggers span 4.0x3.0m for stable operation on uneven ground and soft soil
- 158kW engine delivers strong power for continuous crane operation and travel
- ISO certification ensures compliance with international export standards and documentation needs
Application Scenarios
Where It Is Used
- Lifting steel beams and precast panels at mid-rise construction sites with limited access
- Installing heavy machinery and equipment in industrial plant expansions where space is constrained
- Supporting bridge and overpass construction with long boom reach and high lifting height
- Moving large components in remote or rural infrastructure projects where crane transport is limited
Fit
Who It Is For
- Construction contractors managing medium to large-scale building and civil works
- Engineering firms sourcing reliable, certified cranes for overseas project deployments
- Machinery dealers stocking mobile cranes for resale in Southeast Asia, Africa and the Middle East
- Government procurement teams requiring ISO-certified equipment for public infrastructure projects
Buyer Pain
Problems It Solves
- Lack of certified crane documentation for customs clearance in import markets
- Unreliable lifting performance due to underpowered or outdated crane models
- Limited reach and height in cranes that cannot access upper structural levels without repositioning
- Inconsistent spare parts availability for foreign crane brands not supported locally
- Uncertainty over crane stability on soft or uneven ground without proper outrigger support
Engineering
Technical Features
- Model QY25K-II mobile hydraulic truck crane with 4-section telescopic boom
- ST5-I chassis with 4.0x3.0m outrigger span for stability
- Maximum lifting height of 52m with base boom length of 10.5m
- Rated lifting moment of 961kN.m at maximum outreach
- Maximum rated total lifting capacity of 25 tonnes
- Lifting speed of 26m/min (main boom) and 52m/min (auxiliary) with hydraulic system
- Turning speed of 28m/min with full rotation capability
- Maximum travel speed of 75km/h for site mobility
- ISO certification for export compliance and documentation
- One-year warranty covering major components and performance
Specification
Specification Table for This Listing
Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.
| Condition | New |
|---|---|
| Warranty | 1Year |
| Feature | TruckCrane |
| Span | 8m |
| Certification | ISO |
| Model | GtruckcraneQY25K-II |
| Application | ConstructionIndustry |
| Rated Lifting Capacity | 25 T |
| Maximum Lifting Height | 52 m |
| Base Boom Length | 10.5 m |
| Boom Type | 4-section telescopic |
| Outrigger Span | 4.0 x 3.0 m |
| Engine Model | D6114ZLQ5B |
| Engine Rated Power | 158 kW |
| Lifting Speed | 26(52) m/min |
| Turning Speed | 28 m/min |
| Max Travel Speed | ≤75 km/h |
| Chassis Type | ST5-I |
| Fuel Type | Diesel |
| Dimensions L x W x H | 7.7 x 2.0 x 2.65 m |
| Weight | Not specified |
| Lifting Moment | 961 kN.m |
| Crane Condition | New |
| Rated Loading Capacity | 25000kg |
| Rated Lifting Moment | 961kn.m Max. |
| Lifting Height | 52m |
Materials
Materials and Build
- Steel chassis frame with welded joints for structural rigidity
- Telescopic boom sections made of high-strength alloy steel
- Hydraulic cylinders and hoses rated for high-pressure operation
- Steel outrigger legs with adjustable foot pads for ground stability
- Cab shell with factory paint finish, designed for operator visibility and safety
Process
How an Order Is Handled
- You provide the project site location, lifting load, and required height
- We confirm availability of the QY25K-II crane with current stock or production schedule
- You review the specification sheet, photos, and export documents before deposit
- Unit is prepared, tested, and photographed with engine start and boom extension recorded
- We book RoRo or container shipment based on your port and delivery schedule
Quality Control
Checks Before Loading
- Engine, chassis, and boom serial numbers are verified against the specification sheet
- Hydraulic system pressure and boom extension speed are tested before loading
- Outriggers, safety locks, and cab glass are inspected for damage before shipment
- Loading and lashing photos are sent before vessel departure
Customisation
What Can Be Changed
- Cab colour other than standard white
- Additional safety lights or warning beacons
- Custom paint scheme or company logo application
- Extra tool box or storage compartment on the chassis
- Adjustment of fifth wheel height for trailer coupling
Honest Comparison
How It Compares With the Alternatives
| Truck crane with 3-section boom | The 4-section boom offers greater reach and flexibility on tight sites but is more complex to maintain |
|---|---|
| Crane with no ISO certification | ISO certification ensures export documentation is accepted in most markets, avoiding customs delays |
Use Guide
Using It Well
- Perform a full hydraulic system check before first operation and top up fluid levels
- Inspect outrigger pads and ground condition before each lift to prevent sinking
- Do not exceed the rated lifting capacity at maximum outreach; use load moment indicator
- Replace hydraulic oil and filters according to the manufacturer's schedule, not a fixed interval
- Store the crane with boom fully retracted and outriggers locked when not in use
Photographs
More Views of This Unit
Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.
Source Specification
Manufacturer Text We Hold for This Listing
8ton mobile hydraulic truck crane price 6Ton selfmade-GNQY-Z6 crane Model GNQY-Z6 Max. lifting weight 6000Kg Max. lifting height 22m Lifting speed 26(52)m/min Turning speed 28m/min Max travel speed ≤75km/h Power 34Kw Chassis TYPE ST5-I OUTRIGGER span(Horizontal & vertical) 4.0x3.0m Engine 4DW93-84E3 Size 7.7x2.0x2.65m
Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
Related Listings
Other Truck Cranes Buyers Compare With This
Truck Cranes
QY25 INFRONT BRAND 25ton Ton Crane Mobile Crane Truck Crane Factory Direct Sal
- ConditionNew
- Warranty12months,12Months
- Weight31750kg
Truck Cranes
New 30 Ton Hydraulic Truck Crane Price QY30V532
- ConditionNew
- Warranty1Year
- FeatureTruckCrane
Truck Cranes
50 Ton Truck Crane Model Qy50ka Hydraulic (lhd Is Optional)
- ConditionNew
- Warranty1year
- FeatureTruckCrane
Truck Cranes
New 8 Ton 10 Ton 12 Ton 16 Ton Hydraulic Truck Crane with Outrigger
- ConditionNew
- Warranty1Year
- FeatureTruckCrane
Truck Cranes
Chinese Brand QY50KA 50 Ton Truck Crane Price for Sale
- ConditionNew
- Warranty2000HOURS
- FeatureTruckCrane
Buyer Questions
Questions About This Unit
Is this crane new or used
The crane is new. We confirm the chassis and engine numbers before shipment and provide photos of the unit in working condition.
What is the lead time
Units in stock can be prepared and loaded within 7 days. Custom builds depend on the plant schedule; we confirm a delivery date in writing with the proforma invoice.
Can you supply spare parts for this crane later
Yes. We supply common parts such as hydraulic hoses, filters, boom pins, and outrigger components. They can be shipped separately or consolidated with the crane order.
Do you ship by container or RoRo
The crane is typically shipped RoRo for easier unloading. Container shipment is possible but requires lowering the boom and may affect transport cost and time.
What documents do I get for customs
Standard documents include commercial invoice, packing list, bill of lading, certificate of origin, and ISO certification. Pre-shipment inspection certificates are available upon request.
Price This Unit Against Your Port
Send the destination and quantity. A written specification, landed cost and shipping option comes back.
