Flat Bed Trailers

Nice Price High Quality 20ft 40ft 45ft 48ft Container Trailer Skeleton Semi Trailer

A 20ft to 48ft container trailer skeleton semi-trailer with a 12500*2500*1550mm frame, built from Q345B steel and fitted with two or three 13-ton Fuwa-brand axles, leaf spring suspension, ABS braking, and 1200R20 or 12R22.5 tyres. It is designed for container transport with a maximum payload of 60 tons and carries ISO CCC certification. This configuration is commonly used by logistics operators in Africa, the Middle East and Southeast Asia who need a durable, low-maintenance trailer for long-haul freight on mixed road surfaces.

Use TruckTrailer
Size 12500*2500*1550mm
Color Option
Suspension LeafSpringSuspension
Dimensions 12500*2500*1550mm

Ask for a Price on WhatsApp Email the Specification

Stock number held for this listing: 10323

Side view of a 40ft Shengxing container trailer skeleton with 13-ton Fuwa axles and leaf spring suspension

Key Benefits

What This Unit Does Well

Q345B steel frame provides high strength and load capacity for heavy container payloads
Two or three 13-ton Fuwa axles offer balanced load distribution and longer axle life
Leaf spring suspension is reliable and easy to service in remote locations
ABS braking system improves stopping safety on wet or uneven roads
1200R20 or 12R22.5 tyres are widely available in export markets and match common truck wheel sets
ISO CCC certification supports customs clearance in many international markets

Application Scenarios

Where It Is Used

Container transport between inland depots and coastal ports on gravel and asphalt roads
Long-haul freight across African and Middle Eastern routes with limited roadside repair access
Flatbed hauling of machinery and equipment where trailer frame strength is critical
Fleet expansion where spare parts and maintenance must be sourced locally

Fit

Who It Is For

Fleet owners replacing older trailers with a standardised, high-load-capacity model
Contractors needing a trailer that matches existing 13-ton axles and tyre sizes in their fleet
Logistics companies importing trailers for resale in African and Southeast Asian markets
Government procurement teams sourcing trailers for infrastructure or military transport

Buyer Pain

Problems It Solves

Inconsistent trailer frame strength leading to early fatigue and failure on heavy loads
Lack of spare axle or suspension parts in remote regions due to non-standard brands
Trailer frame misalignment or poor suspension causing uneven tyre wear and higher fuel use
Customs delays due to missing or invalid certification for trailer imports
Uncertainty over axle count and load rating when applying for import permits

Engineering

Technical Features

Semi-trailer type with 12500*2500*1550mm overall dimensions
Q345B steel frame construction with high tensile strength
Two or three 13-ton Fuwa-brand axles with 1200R20 or 12R22.5 tyres
Leaf spring suspension system for durability and low maintenance
ABS braking system for improved stopping performance
ISO CCC certification for compliance with export markets

Specification

Specification Table for This Listing

Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.

Specification of Nice Price High Quality 20ft 40ft 45ft 48ft Container Trailer Skeleton Semi Trailer
Use	TruckTrailer
Size	1250025001550mm
Color	Option
Suspension	LeafSpringSuspension
Dimensions	1250025001550mm
Material	Steel
Certification	ISOCCC
Axle	13TonFuwaBrand
Tyre	1200R20or12R22.5
Function	ContainerTransportation
Type	Semi-Trailer
Trailer Type	Semi-Trailer
Dimensions L x W x H	12500 x 2500 x 1550 mm
Max Payload	60 Tons
Axle Type	13 Ton Fuwa Brand
Axle Number	2 or 3 Axles
Brake System	ABS
Tyre Size	1200R20 or 12R22.5
Place of Origin	Shandong, China
Brand Name	Shengxing
Loading Capacity	40-60 Tons
Tons Place of Origin	Shandong, China (Mainland)
Semi Trailer Axle	13
Ton Fuwa Brand Function	Container
Transportation Suspension	Leaf Spring
Suspension Axle Number	2 or 3

Materials

Materials and Build

Q345B steel for the main frame and structural components
Steel axles with cast housing and forged shafts from Fuwa brand
Leaf spring suspension with galvanised steel springs
1200R20 or 12R22.5 radial tyres on steel rims
ABS control module and brake lines made to standard industrial grade

Process

How an Order Is Handled

You provide the trailer length (20ft, 40ft, 45ft, 48ft), axle count (2 or 3), and tyre size preference
We confirm availability of the Shengxing model with the specified configuration
You approve the final specification sheet, including colour and axle layout, before deposit
Unit is prepared, inspected, and photographed before loading
We book bulk shipment or container load and issue export documents for customs

Quality Control

Checks Before Loading

Axle and suspension components are inspected before assembly against the supplier's technical sheet
Frame dimensions and weld integrity are checked with measuring tools before final inspection
ABS system is tested for signal response and brake engagement before loading
Tyres are checked for tread depth, pressure and mounting torque
Photos of the assembled trailer and loading process are sent before shipment

Customisation

What Can Be Changed

Trailer length: 20ft, 40ft, 45ft, or 48ft as per container size
Axle count: 2 or 3 axles based on load and road conditions
Tyre size: 1200R20 or 12R22.5 as required by local truck fleet
Colour: Custom paint colour available upon request
Fifth wheel plate position: adjustable for different tractor heads

Honest Comparison

How It Compares With the Alternatives

2-axle trailer	The 3-axle version carries more weight safely on long hauls but uses more fuel on empty runs
Air suspension trailer	Leaf spring is cheaper to buy and maintain, but air suspension offers better ride quality on rough roads
Non-ISO CCC trailer	This model clears customs faster in markets requiring CCC, but non-certified units may be cheaper upfront

Use Guide

Using It Well

Replace brake pads and check ABS sensor clearance annually or after wet season use
Keep spare tyres and wheel nuts on hand for roadside repairs in remote areas
Use only 1200R20 or 12R22.5 tyres to avoid mismatched fitment and bearing stress

Photographs

More Views of This Unit

Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.

Front view of the trailer showing the fifth wheel plate and 1200R20 tyres

Rear view of the trailer with ABS brake lines and mud flaps

Undercarriage view showing the 13-ton axles, leaf springs, and frame structure

Trailer frame with Q345B steel construction and welded joints

Source Specification

Manufacturer Text We Hold for This Listing

Nice Price High Quality 20ft 40ft 45ft 48ft Container Trailer Skeleton Semi Trailer Nice Price High Quality 40ft Container Trailer Skeleton Semi Trailer Product Information Product Name Nice Price High Quality 40ft Container Trailer Skeleton Semi Trailer Type Semi-Trailer Material Steel Q345 B Certificate ISO CCC Size 12500*2500*1550mm Max Loading Capacity 60 Tons Brand Shengxing Function Container Transportation Axle 13 Ton Fuwa Brand Axle Number 2/3 Axles Brake System ABS Tyre 1200R20 or 12R22.5 Origin Shandong, China Suspension Leaf Spring Suspension Product Display Accessories Show More Choice Packing & Delivery About Us our company established in 2005, and in 2006 it was approved as the announcement directory management enterprise by National Development and Reform Commission. Shengxing Auto totally invested 20 million RMB, the factory covers an area of 14,500 square meters, includi

Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
