Flat Bed Trailers

Low Price 3 Axles 40 Tons Stake Trailer Fence Trailer Animal Trailer

A 3-axle stake semi-trailer with a 40-ton payload capacity, built on a steel Q345B frame, measuring 13000 x 2550 x 1800mm. It features three 13-ton Fuwa-brand axles with leaf spring suspension, ABS braking, and tyre options of 1200R20 or 12R22.5. The trailer is designed for heavy-duty transport of livestock, construction materials, and general cargo across regions with limited road infrastructure.

Use TruckTrailer
Size 13000*2550*1800mm
Color Option
Suspension LeafSpringSuspension
Dimensions 13000*2550*1800mm

Ask for a Price on WhatsApp Email the Specification

Stock number held for this listing: 10454

White 3-axle stake semi-trailer parked on a yard, front three-quarter view with side stakes visible

Key Benefits

What This Unit Does Well

3 x 13-ton Fuwa axles provide stable load distribution across uneven terrain and high payload capacity
Leaf spring suspension offers durability and low maintenance in off-road and gravel conditions
ABS braking system improves stopping safety under heavy load and on wet or loose surfaces
1200R20 or 12R22.5 tyre options allow flexibility for local tyre availability and cost
Steel Q345B frame ensures structural strength and resistance to deformation under dynamic loads
ISO CCC certification supports compliance with import regulations in many emerging markets

Application Scenarios

Where It Is Used

Transport of livestock between rural farms and processing hubs in Africa and Southeast Asia
Hauling construction materials such as steel beams, pipes, and fencing on unpaved access roads
Moving bulk agricultural goods like grain or feed across long distances with minimal road access
Supporting mining or quarry operations where trailers must carry heavy, uneven loads over rough terrain

Fit

Who It Is For

Fleet owners sourcing low-cost, high-capacity trailers for regional hauls in developing markets
Contractors needing reliable trailers for construction or mining projects with limited maintenance support
Livestock transport operators in regions where trailer durability and axle strength are critical
Distributors importing trailers for resale in markets where local manufacturing is not available

Buyer Pain

Problems It Solves

High freight costs due to underpowered or undersized trailers that require multiple trips
Frequent axle or suspension failure on rough roads due to poor component quality
Lack of local spare parts for trailers with non-standard or generic axles
Import delays caused by missing or non-compliant certification documents
Uncertainty over trailer dimensions and load capacity when applying for import permits

Engineering

Technical Features

Steel Q345B chassis frame with welded construction for load-bearing integrity
Three 13-ton Fuwa-brand axles in tandem layout with 1200R20 or 12R22.5 tyres
Leaf spring suspension system with shock absorption for uneven terrain
ABS braking system for improved stopping performance under full load
Stake semi-trailer design with vertical side stakes for securing loose or tall cargo
13000 x 2550 x 1800mm external dimensions with 40-ton maximum payload capacity

Specification

Specification Table for This Listing

Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.

Specification of Low Price 3 Axles 40 Tons Stake Trailer Fence Trailer Animal Trailer
Use	TruckTrailer
Size	1300025501800mm
Color	Option
Suspension	LeafSpringSuspension
Dimensions	1300025501800mm
Material	Steel
Certification	ISOCCC
Axle	13TonFuwaBrand
Tyre	1200R20or12R22.5
Function	StakeSemiTrailer
Type	Semi-Trailer
Trailer Model	3 Axles 40 Tons Stake Semi Trailer
Dimensions L x W x H	13000 x 2550 x 1800 mm
Max Loading Capacity	40 Tons
Axle Number	3
Axle Type	13 Ton Fuwa Brand
Brake System	ABS
Tyre Size	1200R20 or 12R22.5
Place of Origin	Shandong, China (Mainland)
Brand Name	Shengxing
OEM Number	2018101001
Trailer Type	Semi-Trailer
Max Payload	40
Tons Place of Origin	Shandong, China (Mainland)
Product Name	3 Axles 40 Tons Stake Semi Trailer
Fence Semi Trailer Axle	13

Materials

Materials and Build

Steel Q345B frame and side stakes for high tensile strength and load resistance
Cast steel 13-ton Fuwa axles with forged components for durability
Leaf spring suspension with galvanised steel springs and rubber bushings
1200R20 or 12R22.5 radial tyres with steel rims
Welded steel side stakes and cross members for cargo containment

Process

How an Order Is Handled

You provide the cargo type, route conditions, and required payload to determine fit
We confirm availability of the 13000 x 2550 x 1800mm stake trailer with 3 x 13-ton Fuwa axles
You select colour, tyre size, and confirm the final specification before deposit
Unit is built, inspected, and photographed with chassis and axle numbers recorded
We arrange bulk or container shipment with a shipping agent and provide export documents

Quality Control

Checks Before Loading

Axles, suspension, and tyres are sourced centrally and inspected before assembly
Welding joints are checked using visual and non-destructive methods during production
Final trailer is tested for brake function, axle alignment, and structural integrity
Photos and video of the trailer before loading are sent to you for approval

Customisation

What Can Be Changed

Custom colour other than standard white or grey
Choice between 1200R20 or 12R22.5 tyres
Adjustment of stake height or number of side stakes
Addition of side fencing or cargo netting
Optional fifth wheel plate or coupling upgrade

Honest Comparison

How It Compares With the Alternatives

Air suspension trailer	Leaf spring suspension is cheaper to maintain and more robust in dusty or muddy conditions
Trailer with non-branded axles	Fuwa-brand axles are traceable and supported by the manufacturer, reducing risk of failure in remote areas

Use Guide

Using It Well

Check tyre pressure weekly, especially when carrying near-maximum load
Use only approved brake pads and linings to maintain ABS system performance
Keep side stakes and cross members free of debris to prevent corrosion and structural weakening

Photographs

More Views of This Unit

Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.

Side view of the stake trailer showing 13000mm length, leaf spring suspension, and 1200R20 tyres

Rear view of the trailer with ABS brake lines, fifth wheel plate, and side fencing detail

Source Specification

Manufacturer Text We Hold for This Listing

Low Price 3 Axles 40 Tons Stake Trailer Fence Trailer Animal Trailer 3 Axles 40 Tons Stake Semi Trailer Fence Semi Trailer Product Information Product Name 3 Axles 40 Tons Stake Semi Trailer Fence Semi Trailer Type Semi-Trailer Material Steel Q345 B Certificate ISO CCC Size 13000*2550*1800mm Max Loading Capacity 40 Tons Brand Shengxing Function Stake Semi Trailer Axle 13 Ton Fuwa Brand Axle Number 3 Axles Brake System ABS Tyre 1200R20 or 12R22.5 Origin Shandong, China Suspension Leaf Spring Suspension Accessories Show More Choice Packing & Delivery About Us the factory covers an area of 14,500 square meters, including the plant area of 11,300 square meters, the warehouse area of 900 square meters, and the supporting construction area of 1,200 square meters. We have 160 units advanced large scale equipment, and more than 50 units testing machines. With strong technical force and advanced

Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
