China Manufacturer 8x4 371hp A7 Dump Truck
The ZZ1317N3867A chassis features HF9 front and HC16 rear axles, 12R22.5 tubeless tyres with one spare, and a 300L fuel tank. It has a 8000x2300x1600mm cargo body and a 31-ton GVW. The unit is configured for heavy-duty off-road and quarry operations with a luxury cab and air suspension.
- Condition New
- Transmission HW19710
- Displacement 9.726L
- Type 12R22.5
- Horsepower 351-450hp
Stock number held for this listing: 10120
Key Benefits
What This Unit Does Well
- HW19710 ten-speed gearbox provides usable ratios for loaded climbs and empty return runs
- HF9 front and HC16 rear axles support 9000kg and 16000kg per axle respectively, ideal for 51-60 ton payloads
- 12R22.5 tubeless tyres reduce downtime from punctures on rough terrain
- 300L fuel tank supports long hauls between refuelling points in remote mining or construction zones
- Air-suspended cab with four-point mounting reduces driver fatigue on extended off-road shifts
Application Scenarios
Where It Is Used
- Coal transport from mine to rail transfer point on uneven, dusty terrain
- Construction site material delivery where road conditions are poor and maintenance access is limited
- Long-distance haulage between remote mining camps and processing plants with infrequent fuel stops
Fit
Who It Is For
- Fleet owners replacing older dump trucks with a standardised engine and transmission across multiple units
- Contractors needing a dump truck that shares parts with other HOWO A7 models already in use
- Machinery dealers stocking dump trucks for resale in African and Middle Eastern markets
- Government procurement teams sourcing heavy-duty vehicles for infrastructure projects with limited local support
Buyer Pain
Problems It Solves
- Mixed fleets where every truck requires different clutch, axle, or filter part numbers
- Downtime caused by parts that take weeks to arrive from Europe or North America
- Trucks that lack sufficient axle capacity for heavy payloads, leading to overloading and safety risks
- Cab vibration and driver fatigue on rough terrain due to rigid suspension systems
- Fuel shortages on remote sites due to small tank capacity and inefficient engine performance
Engineering
Technical Features
- Direct injection fuel system rated to EURO 2 emission standard
- HW19710 manual transmission with ten forward gears and two reverse gears
- HF9 front axle and HC16 rear axle in 8x4 drive layout with differential locks
- U-profile parallel ladder frame with 300x80x8mm section and cold riveted cross members
- 10 semi-elliptic leaf springs with hydraulic shock absorbers and stabilizer on front
- 12 leaf semi-elliptic springs with bogie spring and stabilizer on rear
- Dual circuit compressed air service brake with spring energy parking brake
- Engine exhaust brake as auxiliary braking system
- 24V electrical system with 2 x 12V 165Ah batteries, 5.4kW starter and 1500W alternator
- 12R22.5 tubeless tyres with one spare tyre
- Luxury A7 cab with four-point suspension, airbag, horizontal stabilizer, and sleeper with air conditioning
- Electrically adjustable rear-view mirror with heating function and electrically lifted glass
Specification
Specification Table for This Listing
Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.
| Condition | New |
|---|---|
| Transmission | HW19710 |
| Displacement | 9.726L |
| Type | 12R22.5 |
| Horsepower | 351-450hp |
| Truck Model | ZZ1317N3867A |
| Drive Wheel | 8x4 |
| Dimensions L x W x H unloaded | 10000 x 2500 x 3400 mm |
| Curb Weight | 10000 kg |
| Emission | EURO 2 |
| Fuel Type | Diesel |
| Fuel Tank Capacity | 300 L |
| Front Axle | HF9, 9000 kg per axle |
| Rear Axle | HC16, 16000 kg per axle |
| Tyre | 12R22.5 tubeless |
| Cab | A7 luxury cab with sleeper and air conditioning |
| Gross Vehicle Weight | 31 T |
| Cargo Body Size | 8000 x 2300 x 1600 mm |
| Spare Tyre | One included |
| Driving Type | LHD (RHD optional) |
| Capacity (Load) | 51 - 60t |
| Transmission Type | Manual |
| Emission Standard | Euro 2 |
| Engine Capacity | > 8L |
| Place of Origin | China (Mainland) Dimensions (L x |
| W X H) (mm) | 10000x2500x3400mm |
Materials
Materials and Build
- Welded steel ladder frame chassis in the ZZ1317N series with 300x80x8mm section
- Steel cab shell with factory paint finish, white by default
- Cast steel HF9 front and HC16 rear axle housings
- 12R22.5 tubeless radial tyres on steel rims
- Vermicular cast iron engine block with high rigidity and thermal resistance
Process
How an Order Is Handled
- You send the payload, terrain type, and operational route profile
- We match a chassis code and axle ratio against current stock or plant availability
- You confirm the final specification sheet including cab colour, drive type, and tyre brand before deposit
- Unit is prepared, photographed, and video recorded before loading
- We book RoRo or container shipment and issue export documents required by your customs
Quality Control
Checks Before Loading
- Chassis, engine, and gearbox numbers are photographed and matched to the specification sheet you approved
- Engine start, gear engagement, and air brake function are recorded on video before loading
- Paint, glass, and cab trim are checked for transport damage at the loading port
- Loading and lashing photos are sent before the vessel departs
Customisation
What Can Be Changed
- Left-hand or right-hand drive as required by your registration country
- Cab colour other than the default white
- Sleeper layout, single or double bunk
- Tyre brand and spare wheel count
- Additional fuel tank or tool box installation
Honest Comparison
How It Compares With the Alternatives
| 6x4 dump truck | The 8x4 provides better traction and load distribution on soft or uneven terrain but consumes more fuel when running empty |
|---|---|
| Smaller 300L fuel tank model | 300L tank supports longer hauls between refuelling points in remote operations, reducing downtime |
Use Guide
Using It Well
- Replace fuel and oil filters on the interval set for WD615 engines, not on a generic schedule
- Keep the air dryer cartridge stocked, humid environments shorten its life
- Order the clutch plate, injector set, and axle seals with the truck so the first service does not wait on shipping
Photographs
More Views of This Unit
Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.
Source Specification
Manufacturer Text We Hold for This Listing
China Manufacturer 8X4 371HP A7 Dump truck Product Description Chassis Model ZZ1317 N 3867 A Driving Type LHD (RHD is optional) Cabin Characteristics of A7-W Luxury Driving Cab: Four-point suspension plus airbag and horizontal stabilizer; one sleeper with air conditioning; air suspension seat with armrest; encircled curtains and MP5 entertainment systems; electrically adjusted rear-view mirror with the function of heating; electrically lifted glass; manually and electrically raised driving cab. Engine Diesel 4-stroke direct injection diesel engine Engine model: WD615. 47, Euro 2, 371 HP 6-cylinder in-line with water cooling, turbo-charging and intercooling Displacement: 9.726 L Transmission HW1 9 710, 10F & 2R Ratio: 14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2) Steering ZF power steering, mod e l ZF8 11 8, hydraulic steering with power assi s tance Fr
Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
Related Listings
Other Dump Trucks Buyers Compare With This
Dump Trucks
2023 NEW 371 Hp 6x4 Mining Dump Truck 70 Ton Tipper Truck
- ConditionNew
- CabHOWO7D,withAirconditioner
- Tire14.00-25
Dump Trucks
China Wholesale Dump Truck 6*4 for Sands/coal Minerals
- ConditionNew
- CabHOWO70(nobed),withAircondi
- Tire12.00R20(Radial)
Dump Trucks
Chinese Low Fuel Consumption Dump Truck Factory Price
- ConditionNew
- CabL2000,withAirconditioner
- Tire11.00R20(Radial)
Dump Trucks
China 336hp 6x4 Construction Sand and Gravel Loading Dump Truck
- ConditionNew
- Horsepower336HP
- Truck ModelSX3256DV384C
Dump Trucks
China 8*4 New and Used Dump Truck 50t for Afirica
- ConditionNew
- ColorRed
- Horsepower351-450hp
Buyer Questions
Questions About This Unit
Is this unit new or used
New. All units are factory-new with zero hours and full warranty from the plant.
What is the lead time
Units in stock can be prepared and loaded within 10 days. A build to your specification depends on the plant schedule, so we confirm a date in writing with the proforma invoice.
Can you supply spare parts for this truck later
Yes. WD615 filters, injectors, clutch parts, axle components, and brake linings are the parts we ship most often and can be consolidated with the truck order.
Do you ship by container or RoRo
Dump trucks normally go RoRo. Container shipment is possible with the cab lowered, but RoRo is more cost-effective and safer for this model.
What documents do I get for customs
Commercial invoice, packing list, bill of lading, certificate of origin, and any pre-shipment inspection certificate your country requires.
Price This Unit Against Your Port
Send the destination and quantity. A written specification, landed cost and shipping option comes back.
