Flat Bed Trailers

40ft Container Semi Trailer 3 Axle Flatbed Semi Trailer 12pcs Twist Lock for One 40ft 0r Two 20ft

Built on a heavy-duty I-beam chassis using high-tensile Q345 steel, it features three Fuwa-brand axles, 12R22.5 Chengshan tyres, and 12 twist locks. The Germany-type leaf spring suspension and JOST brand landing gear support long-haul container transport across rough terrain and unpaved routes common in Africa, the Middle East and Southeast Asia.

  • Use OtherTrailers
  • Size 1250*2500*1500mm
  • Color Optional
  • Suspension MechanicalSuspension
  • Material steel
Ask for a Price on WhatsApp Email the Specification

Stock number held for this listing: 10490

Side view of a 40ft flatbed semi trailer with three axles, 12 twist locks, and 12R22.5 tyres
Side view of a 40ft flatbed semi trailer with three axles, 12 twist locks, and 12R22.5 tyres
Key Benefits

What This Unit Does Well

  • I-beam chassis with Q345 high-tensile steel ensures durability under heavy container loads
  • Three Fuwa-brand axles provide balanced weight distribution across 3-axle layout
  • 12 twist locks allow secure dual 20ft or single 40ft container locking without extra fittings
  • Germany-type leaf spring suspension handles uneven roads and repeated loading cycles
  • JOST brand two-speed manual landing gear supports stable coupling and easy setup
  • 12R22.5 Chengshan tyres offer proven performance on gravel, dirt and asphalt routes
Application Scenarios

Where It Is Used

  • Container transport between inland depots and seaports on unpaved access roads
  • Two 20ft container haulage on routes with frequent stops and tight turning radii
  • Long-haul flatbed transport of construction equipment across desert or mountainous regions
  • Fleet expansion where spare parts and service support are limited to local suppliers
Fit

Who It Is For

  • Fleet owners replacing older trailers with a standardised 3-axle flatbed design
  • Contractors needing a trailer that carries two 20ft containers without repositioning
  • Machinery dealers stocking trailers for resale in African and Middle Eastern markets
  • Logistics operators importing trailers with known axle and suspension specs for customs clearance
Buyer Pain

Problems It Solves

  • Trailer frames that warp under repeated container loading due to low-grade steel
  • Twist lock systems that fail under high lateral stress during cornering
  • Axle failure on 3-axle trailers due to poor load distribution or weak axle brands
  • Landing gear that jams or slips during coupling in dusty or off-road conditions
  • Lack of consistent spare parts availability for non-standard trailer components
Engineering

Technical Features

  • I-beam chassis with Q345 high-tensile steel, welded by automatic submerged-arc process
  • Main beam: 14mm top flange, 8mm middle flange, 16mm bottom flange; 500mm height
  • Side beams: 16# channel steel (Q235), cross members: 10# channel steel (Q235)
  • Floor: 3mm checkered plate or no floor as option
  • Three Fuwa-brand axles, 13T capacity each, 3-axle layout
  • Germany-type leaf spring suspension, 10pcs x 13mm x 90mm springs
  • 12R22.5 Chengshan brand tyres, 12pcs total
  • Wheel rims: 9.0-22.5 China brand, 12pcs
  • Kingpin: 3.5" (90mm) bolt-in, China brand
  • Twist locks: 12pcs, standard container fitment
  • Braking system: WABCO RE6 relay valve, T30/30 spring brake chamber, 40L air tanks
  • ABS: Not equipped
  • Lighting: LED 8 side lights, 2 rear lights, 2 width lamps
  • Paint: Chassis sandblasted, 1 coat anti-rust primer, 2 coats final paint
Specification

Specification Table for This Listing

Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.

UseOtherTrailers
Size1250*2500*1500mm
ColorOptional
SuspensionMechanicalSuspension
Materialsteel
AxleFuwaBrand
Tire12R22.5doublestarbrand
Typesemitrailer
CertificateCCCISO9001BV
Trailer ModelLHY9401
Max Payload50 T
Tyre12R22.5 Chengshan brand
Wheel Rim9.0-22.5 China brand
Kingpin3.5" (90mm) bolt-in, China brand
Landing GearJOST brand, two-speed, manual
Twist Locks12 pcs
Braking SystemWABCO RE6 relay valve, T30/30 spring brake chamber, 40L air tanks
ABSNo
LightingLED 8 side lights, 2 rear lights, 2 width lamps
PaintSandblasted, 1 primer coat, 2 final paint coats
Floor3mm checkered plate or no floor
Place of OriginShandong, China (Mainland)
Model NumberLHY9401
BV AxleFuwa
Brand Brake SystemWEBCO
Country of OriginChina
Materials

Materials and Build

  • Q345 high-tensile steel for main I-beam chassis
  • Q235 channel steel for side beams and cross members
  • 3mm checkered steel plate for floor (optional)
  • Chengshan brand 12R22.5 tyres on China brand 9.0-22.5 rims
  • Fuwa-brand axles with bolt-in 3.5" kingpin
  • JOST brand two-speed landing gear with manual operation
Process

How an Order Is Handled

  • You confirm the container size (one 40ft or two 20ft) and intended route
  • We match the trailer spec to current stock or production schedule
  • You approve the final specification sheet including colour, floor option, and tyre brand
  • Unit is prepared, photographed, and video recorded before loading
  • We book container shipment and issue export documents required by your customs
Quality Control

Checks Before Loading

  • Chassis, axle, and kingpin numbers are photographed and matched to the approved spec sheet
  • Suspension, twist locks, and landing gear are tested for full movement and load capacity
  • Paint, glass, and lighting are checked for damage before loading
  • Loading and lashing photos are sent before vessel departure
Customisation

What Can Be Changed

  • Optional colour for the chassis paint
  • Floor: 3mm checkered plate or no floor
  • Tyre brand: Chengshan or alternative (if available)
  • Kingpin size: 3.5" (90mm) or 2" (50mm) as per coupling requirement
  • Additional tool box or spare tire carrier if needed
Honest Comparison

How It Compares With the Alternatives

2-axle flatbed trailerThe 3-axle layout supports higher payload and better weight distribution on uneven roads, but adds cost and complexity
Hydraulic suspension trailerMechanical leaf springs are simpler to maintain and more reliable in dusty or remote areas without service access
Trailer with ABSNo ABS reduces initial cost and complexity, but increases risk on wet or slippery surfaces where braking control is critical
Use Guide

Using It Well

  • Inspect twist locks and kingpin before each coupling to ensure no wear or misalignment
  • Check air brake system pressure and brake chamber function before each trip
  • Replace brake linings when thickness drops below 5mm to avoid drum damage
  • Keep the landing gear lubricated and test its locking mechanism monthly
Photographs

More Views of This Unit

Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.

Front view of the trailer showing the JOST landing gear, kingpin, and front lightingRear view of the trailer with air brake lines, 40L tanks, and LED rear lights
Source Specification

Manufacturer Text We Hold for This Listing

40ft Container semi trailer 3 axle flatbed semi trailer 12pcs twist lock for one 40ft 0r two 20ft Product Description 40ft Container semi trailer 3 axle flatbed semi trailer 12pcs twist lock for one 40ft 0r two 20ft DIMENSIONS Tare weight 7 000kg Size 1 25 00mm *2500mm* 15 00mm Payload 50T Main beam Heavy duty and extra durability designed I beam; opting for high tensile steel Q345, welded by automatic submerged-Arc processes. Top flange 14mm,width140mm;Middle Flange 8mm height 500mm;bottom flange16mm,width 140mm Side beam 16# channel steel(Q235) Cross member 10# channel steel(Q235) Floor 3mm checkered plate or no floor Side wall No Front board No Axle 3 axle FUWA brand 1 3 T Suspension Germany type suspension Leaf spring 10pcs*13mm*90mm Tire 12R2 2.5 chengshan brand 12pcs Wheel rim 9.0-22.5 china brand 12pcs Kingpin CHINA brand 3.5 " bolt-in king pin Landing gear JOST brand two-speed, m

Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.

Related Listings

Other Flat Bed Trailers Buyers Compare With This

All 61 Flat Bed Trailers Full product index

Buyer Questions

Questions About This Unit

Is this trailer new or used

All units are new. We supply only new trailers built to the specification listed. Photos and chassis numbers are provided before payment.

What is the lead time

20 workdays after receipt of 30% down payment. We confirm the exact delivery date in writing with the proforma invoice.

Can you supply spare parts later

Yes. We supply Fuwa axles, Chengshan tyres, JOST landing gear, twist locks, and brake components as spares. They can be shipped separately or with the trailer.

Do you ship by container or RoRo

This trailer is shipped by container. It fits within a 40ft container with the cab lowered. RoRo is not available for this model.

What documents do I get for customs

Commercial invoice, packing list, bill of lading, certificate of origin, and CCC/ISO9001/BV certificates as standard.
