Flat Bed Trailers

3 Axle 40ft Flatbed Container Semi Trailer Flatbed Semi Trailer for Transportation

A 3-axle 40ft flatbed semi trailer designed for container and bulk cargo transport, built with a 13000*3000*1250mm steel frame using Q345B material, equipped with three 13-ton Fuwa-brand axles, leaf spring suspension, ABS braking, and tyre options of 1200R20 or 12R22.5. It has a maximum payload capacity of 60 tons and is certified under ISO CCC. This configuration is used by logistics operators in Africa, the Middle East and Southeast Asia for long-haul freight where road conditions vary and spare parts must be locally available.

Use TruckTrailer
Size 13000*3000*1250mm
Color Option
Suspension LeafSpringSuspension
Dimensions 13000*3000*1250mm

Ask for a Price on WhatsApp Email the Specification

Stock number held for this listing: 10288

3-axle flatbed semi trailer parked on a yard, front three-quarter view showing 1200R20 tyres and front axle

Key Benefits

What This Unit Does Well

Three 13-ton Fuwa axles provide stable load distribution across uneven terrain and heavy container loads
Leaf spring suspension offers durability and low maintenance in high-vibration, off-road conditions
ABS braking system improves stopping performance on wet or loose surfaces common in tropical and desert zones
1200R20 or 12R22.5 tyre options allow local sourcing in markets where these sizes are standard
ISO CCC certification supports customs clearance in regulated markets including Russia and the Middle East
60-ton payload rating matches the capacity of standard 40ft shipping containers with minimal overloading risk

Application Scenarios

Where It Is Used

Container transport between inland depots and seaports on unpaved or poorly maintained access roads
Bulk material haulage such as aggregates, steel coils, or construction equipment across African and Southeast Asian routes
Long-haul freight where trailer downtime must be minimised due to limited repair infrastructure
Fleet expansion for contractors needing a standardised trailer model that shares parts with existing units

Fit

Who It Is For

Fleet owners importing trailers to operate in markets with limited access to European or North American spare parts
Contractors managing construction or mining logistics where trailer reliability is critical on remote sites
Logistics companies standardising on a single trailer model to reduce spare parts inventory and training complexity
Machinery dealers stocking trailers for resale in African and Middle Eastern markets with high demand for container transport

Buyer Pain

Problems It Solves

Trailer breakdowns caused by axle or suspension failure due to mismatched load capacity or poor material quality
Delays in customs clearance due to missing or non-compliant certification documents
High maintenance costs from using non-standard or incompatible parts not available locally
Inconsistent trailer performance when using different axle brands or suspension types across a mixed fleet
Uncertainty over exact dimensions and weight ratings when applying for import permits or port access

Engineering

Technical Features

3-axle configuration with 13-ton Fuwa-brand axles for even load distribution
Leaf spring suspension system for durability in rough terrain and high-vibration environments
ABS anti-lock braking system to prevent wheel lock-up during emergency stops
Steel Q345B frame material with welded construction for structural rigidity
13000*3000*1250mm external dimensions suitable for standard 40ft container transport
Tyre options of 1200R20 or 12R22.5 to match regional availability and wheel rim standards

Specification

Specification Table for This Listing

Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.

Specification of 3 Axle 40ft Flatbed Container Semi Trailer Flatbed Semi Trailer for Transportation
Use	TruckTrailer
Size	1300030001250mm
Color	Option
Suspension	LeafSpringSuspension
Dimensions	1300030001250mm
Material	Steel
Certification	ISOCCC
Axle	13TonFuwaBrand
Tyre	1200R20or12R22.5
Function	ContainerFlatbedTransportation
Type	Semi-Trailer
Trailer Model	3 Axle 40ft Flatbed Container Semi Trailer
Dimensions L x W x H	13000 x 3000 x 1250 mm
Axle Number	3
Axle Capacity	13 Ton per Axle
Axle Brand	Fuwa
Brake System	ABS
Tyre Size	1200R20 or 12R22.5
Max Payload Capacity	60 Tons
Loading Capacity Range	60-80 Tons
Certifications	ISO CCC
Origin	Shandong, China
Brand Name	Shengxing
OEM Number	2018092802
Trailer Type	Semi-Trailer
Max Payload	60

Materials

Materials and Build

Q345B steel frame with welded construction for high tensile strength
Cast steel axle housings from Fuwa brand with standard mounting points
Leaf springs made from high-carbon steel with galvanised finish for corrosion resistance
1200R20 or 12R22.5 radial tyres on steel rims with standard tread patterns
Galvanised steel brackets and fasteners used in suspension and frame assembly

Process

How an Order Is Handled

You provide the route, load type, and any local registration or road access requirements
We confirm the available stock or build-to-order schedule based on current production
You approve the final specification including colour, tyre size, and axle configuration before deposit
Unit is assembled, tested for brake and suspension function, and photographed before loading
We book bulk shipment or container transport and issue the export documents required by your customs

Quality Control

Checks Before Loading

Axles, suspension components, and tyres are inspected upon receipt from supplier
Welding joints are checked with visual and non-destructive methods before final assembly
Brake system is tested under load to confirm ABS activation and stopping distance
Final trailer is driven on a test track to verify alignment, suspension response, and brake function
Photos and video of the trailer before loading are sent to you for approval

Customisation

What Can Be Changed

Choice of trailer colour other than standard grey or white
Selection between 1200R20 or 12R22.5 tyre size based on local availability
Adjustment of fifth wheel position for compatibility with specific tractor heads
Addition of side rails, tie-down points, or cargo nets for specific load types
Optional extra lighting or reflector packages for night or low-visibility operations

Honest Comparison

How It Compares With the Alternatives

2-axle 40ft flatbed trailer	The 3-axle model supports heavier loads and better weight distribution on poor roads but has higher purchase and maintenance cost
Air suspension trailer	Leaf spring suspension is more robust and cheaper to maintain in dusty, off-road environments but offers less ride comfort

Use Guide

Using It Well

Use only 1200R20 or 12R22.5 tyres as specified to avoid rim and bearing damage
Keep the trailer frame clean and dry to prevent rust in coastal or high-humidity areas
Order spare leaf springs and axle seals with the initial order to avoid delays during repairs

Photographs

More Views of This Unit

Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.

Side view of the 40ft trailer showing the 13000mm length and leaf spring suspension on all three axles

Rear view of the trailer with fifth wheel coupling, brake lines, and mud flaps

Flatbed deck with tie-down points and side rails, showing steel Q345B frame construction

Source Specification

Manufacturer Text We Hold for This Listing

3 Axle 40ft Flatbed Container Semi Trailer Flatbed Semi Trailer For Transportation Product Information Product Name 3 Axle 40ft Flatbed Container Semi Trailer Flatbed Semi Trailer For Transportation Type Semi-Trailer Material Steel Q345 B Certificate ISO CCC Size 13000*3000*1250mm Max Loading Capacity 60 Tons Brand Shengxing Function Container Transportation Axle 13 Ton Fuwa Brand Axle Number 3 Axles Brake System ABS Tyre 1200R20 or 12R22.5 Origin Shandong, China Suspension Leaf Spring Suspension Accessories Show More Choice Packing & Delivery About Us The factory covers an area of 14,500 square meters, including the plant area of 11,300 square meters, the warehouse area of 900 square meters, and the supporting construction area of 1,200 square meters. We have 160 units advanced large scale equipment, and more than 50 units testing machines. With strong technical force and advanced manuf

Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
