Fixed and variable vacuum capacitors for RF matching networks and high power tuning circuits, quoted against the CKT series designation you specify.
A matching network only works if the capacitor holds off the voltage at the frequency you run. Replacing one with the nearest thing in a distributor catalogue changes the tuning and the losses.
Rebuilding a matching network on an RF power supply
Replacing a tuning capacitor in a transmitter or industrial generator
Holding a spare for a plasma process tool
Specifying capacitors for a new high power tuning circuit
Power grid tubes sockets and tank circuit components for AM FM shortwave and TV transmitter stages.
RF amplifier tubes vacuum capacitors and switching tubes for accelerator groups plasma laboratories and university RF benches.
RF tubes and high voltage components for linear accelerators diathermy equipment and medical RF power supplies.
How tank circuit capacitors are specified, why reactive power matters as much as capacitance and voltage, and what to send when yo
Design GuideWhere fixed and variable vacuum capacitors are used, what limits them in service, and how to specify a replacement without changin
Both styles are listed. Tell us the series designation and the capacitance range you need and we will quote what is available.
The data we hold for the series together with price and availability, so the part can be checked against your circuit.
Yes. They are packed so that the terminals and the bellows are protected, and the packing is chosen for the freight method.
Send a photograph and the dimensions with the equipment type. That is usually enough to identify the series.
Send the numbers exactly as they are printed on your equipment. Price, availability and the data we hold come back by email.
