0~300ml/min Fully Automatic Laboratory Hydrogen Generator
The automatic high-purity laboratory hydrogen generator demonstrates outstanding performance and practicality. It incorporates cutting-edge proprietary technology, meeting the requirements for compatibility with any model of gas chromatograph and hydrogen reduction furnace produced by domestic or international...
Introduction
The automatic high-purity laboratory hydrogen generator demonstrates outstanding performance and practicality. It incorporates cutting-edge proprietary technology, meeting the requirements for compatibility with any model of gas chromatograph and hydrogen reduction furnace produced by domestic or international manufacturers. It stands as the ideal assistant for experimental research.
Features
- Pressure and flow are automatically displayed, with automatic pressure and flow control. Hydrogen flow can be adjusted automatically based on usage.
- Equipped with dual stainless steel filters containing a trace oxygen scavenger (no activation required), ensuring higher hydrogen purity. The instrument’s interior utilizes low-sulfur silicon rubber rings, effectively enhancing gas quality and ensuring a stable baseline for chromatography.
- Provides two operating modes, high and low pressure, for flexible use in different conditions.
- Equipped with safety features for reliable and sensitive operation, including automatic alkali backflow prevention.
Specifications
Figures below are the manufacturer data for this model. Anything not listed is confirmed in writing with the quotation rather than estimated here.
| Model | H300 | |
|---|---|---|
| Hydrogen Purity | 99.999% | |
| Hydrogen Flow Rate | 0-300ml/min | |
| Output Pressure | 0-0.4Mpa (Adjustable) | |
| 0-0.6Mpa (Adjustable) | ||
| Pressure Stability | ＜0.001Mpa | |
| Voltage | AC220V | |
| Power | 150W | |
| Dimension | 370*330*180mm | |
| Weight | 11kg |
0~300ml/min Fully Automatic Laboratory Hydrogen Generator In Detail
Processes This Unit Supports
These are the applications ZYLAB lists this model under. Each link opens the full equipment set for that process, which is useful when a project needs more than one machine.
Who Orders It
Fields this model already works in, plus what ZYLAB puts behind it: a 2-year warranty on most products, glass excluded, spare parts in stock and free application support by WhatsApp or email.
Related Projects
Related Guides
Related Equipment
Models from the same family and the same processes, in case a different chamber size or temperature range fits better.
Quick Clamp Vacuum Sealing Assembly for Tube Furnace
Laboratory Ceramic Crucible
Fused Silica Quartz Ceramic Crucible
Protective Gas Box for Biochar Pyrolysis in Box Furnaces
Desktop Single-Channel MFC Gas Delivery System with Touchscreen Control
Weakly Corrosive Gas Preheater
Handheld K-Type Armored Thermocouple and Digital Thermometer
Recirculating Chillers – Cooling Solutions for Lab High-Temp Furnaces
Ordering 0~300ml/min Fully Automatic Laboratory Hydrogen Generator
What is 0~300ml/min Fully Automatic Laboratory Hydrogen Generator typically used for?
The automatic high-purity laboratory hydrogen generator demonstrates outstanding performance and practicality. It incorporates cutting-edge proprietary technology, meeting the requirements for compatibility with any model of gas chromatograph and hydrogen redu
Can 0~300ml/min Fully Automatic Laboratory Hydrogen Generator be customised for our process?
Yes. Chamber or tube size, temperature profile, atmosphere, gas path, control system and data recording can all be adapted. Send us your process conditions and sample details and our engineers work out a configuration with you.
How quickly can 0~300ml/min Fully Automatic Laboratory Hydrogen Generator be shipped?
Most standard ZYLAB models are held in stock. After testing and packing we normally ship 0~300ml/min Fully Automatic Laboratory Hydrogen Generator within 3 to 7 days. Customised builds are scheduled after the drawing is confirmed, and we give you the date in writing before the order is placed.
How is 0~300ml/min Fully Automatic Laboratory Hydrogen Generator packed for export?
Packing is chosen for the safety of the machine against freight cost, typically a plywood or wooden crate with internal padding and vacuum-sealed accessories. Export documents such as Form A, Form E and Form F can be issued to help you save duty.
Can you supply items that are not on this page?
Yes. We have access to the complete lines of most of our suppliers and build custom equipment in our own factory, so tell us what the experiment needs and we will source or make it.
Quote For 0~300ml/min Fully Automatic Laboratory Hydrogen Generator
Tell us the sample, the temperature and the atmosphere. You get the configuration, the price and the despatch date in one reply.
