Key Benefits
- Forms and seals inner and outer bags simultaneously to double output compared to sequential machines
- Stepper motor control ensures consistent bag length and stable positioning across every bag
- Volumetric cup filling delivers repeatable 5 to 15 g per bag with minimal variation
- Ultrasonic sealing avoids heat damage to coffee aroma and maintains a clean, narrow seal edge
- Built-in connector for nitrogen flushing extends shelf life by reducing oxidation
- SUS304 stainless steel parts in direct contact with coffee meet food safety standards
- PLC control with human machine interface simplifies operation and reduces training time
Application Scenarios
- Coffee roasters packaging single-origin Arabica beans in retail-ready drip bags with a visible inner filter
- Contract packers handling multiple coffee brands with short batch runs and quick format changeover
- Export-focused producers meeting international packaging standards with nitrogen-flush capability
- Small to mid-sized roasteries replacing hand packing with a fully automatic line that fits a compact footprint
Who It Is For
- Coffee roasters transitioning from outsourced packing to in-house drip bag production
- Contract packers serving multiple coffee brands with varying bag sizes and fill weights
- Producers requiring nitrogen flushing to extend shelf life of roasted coffee
- Brands that need consistent bag length and seal quality for retail shelf presentation
Problems It Solves
- Hand packing of inner and outer bags is slow and inconsistent in fill weight and seal alignment
- Sequential machines that pack inner then outer bags reduce throughput by up to 50%
- Heat sealing damages delicate coffee aromatics and causes film degradation at the seam
- Inconsistent bag length leads to poor stacking and visual mismatch on retail shelves
- Lack of nitrogen flushing shortens shelf life and increases risk of stale or oxidized coffee
- Non-food-grade materials or parts in contact with coffee risk contamination and audit failure
Technical Features
- Ultrasonic sealing for clean, narrow, heat-free closure of inner and outer bags
- Stepper motor control for precise outer bag length positioning and stable sealing
- Volumetric cup filling system for consistent 5 to 15 g per bag across batches
- PLC control with human machine interface for easy operation and parameter setting
- All food contact parts made of SUS304 stainless steel for compliance with food safety standards
- Integrated connector for nitrogen flushing to extend coffee shelf life
- Optional flat cut, date printer, and easy tear device for added functionality
Specifications
| Machine model | C19H |
|---|---|
| Machine type | Drip Coffee Packaging Machine Series |
| Bag type | Ultrasonic sealing |
| Packing material | PLA, Paper, Plastic, Plastic/Aluminum/Plastic, Paper/Aluminum/Plastic, Filter paper |
| Feeding system | Volumetric cup filler |
| Package range | 5-15 g per bag |
| Inner bag size | L: 50-75 mm, W: 50-90 mm |
| Outer bag size | L: 85-120 mm, W: 75-100 mm |
| Inner bag film width | 180 mm |
| Outer bag film width | 200 mm |
| Packing speed | 40-60 bags/min |
| Power supply | Single phase, 220V, 50Hz, 3.7 kW |
| Machine weight | 700 kg |
| Machine dimension | 1200 x 900 x 1900 mm (L x W x H) |
Packing Materials It Runs
- PLA film for 100% biodegradable coffee bags
- Filter paper for natural, compostable inner bags
- Plastic/Aluminum/Plastic composite film for moisture and light barrier
- Paper/Aluminum/Plastic composite film for premium shelf appeal and protection
- Plastic film for cost-effective, moisture-resistant packaging
How the Machine Works
- 1Film unwinding and inner bag formation
- 2Volumetric cup filling with 5 to 15 g per bag
- 3Inner bag sealing by ultrasonic method
- 4Outer bag forming and positioning via stepper motor
- 5Outer bag sealing by ultrasonic method
- 6Bag discharge and optional date printing or easy tear feature
Quality Control Before Shipment
- F
- i
- l
- l
- i
- n
- g
- w
- e
- i
- g
- h
- t
- v
- e
- r
- i
- f
- i
- e
- d
- a
- g
- a
- i
- n
- s
- t
- 5
- t
- o
- 1
- 5
- g
- t
- a
- r
- g
- e
- t
- d
- u
- r
- i
- n
- g
- t
- e
- s
- t
- r
- u
- n
- s
- S
- e
- a
- l
- i
- n
- t
- e
- g
- r
- i
- t
- y
- c
- h
- e
- c
- k
- e
- d
- o
- n
- b
- o
- t
- h
- i
- n
- n
- e
- r
- a
- n
- d
- o
- u
- t
- e
- r
- b
- a
- g
- s
- b
- e
- f
- o
- r
- e
- s
- h
- i
- p
- m
- e
- n
- t
- F
- o
- o
- d
- c
- o
- n
- t
- a
- c
- t
- p
- a
- r
- t
- s
- c
- o
- n
- f
- i
- r
- m
- e
- d
- a
- s
- S
- U
- S
- 3
- 0
- 4
- s
- t
- a
- i
- n
- l
- e
- s
- s
- s
- t
- e
- e
- l
- a
- n
- d
- n
- o
- n
- -
- t
- o
- x
- i
- c
- M
- a
- c
- h
- i
- n
- e
- t
- e
- s
- t
- e
- d
- w
- i
- t
- h
- c
- u
- s
- t
- o
- m
- e
- r
- '
- s
- c
- o
- f
- f
- e
- e
- t
- y
- p
- e
- a
- n
- d
- f
- i
- l
- m
- b
- e
- f
- o
- r
- e
- d
- i
- s
- p
- a
- t
- c
- h
- o
- n
- r
- e
- q
- u
- e
- s
- t
- S
- t
- e
- p
- p
- e
- r
- m
- o
- t
- o
- r
- p
- o
- s
- i
- t
- i
- o
- n
- i
- n
- g
- a
- c
- c
- u
- r
- a
- c
- y
- v
- e
- r
- i
- f
- i
- e
- d
- a
- c
- r
- o
- s
- s
- 1
- 0
- 0
- c
- o
- n
- s
- e
- c
- u
- t
- i
- v
- e
- b
- a
- g
- s
Certifications
- ISO
- CE
Customization Options
- Choice of inner and outer bag size within the 50-75 mm and 85-120 mm length range
- Selection of film type: PLA, filter paper, plastic, or aluminum composite
- Add-on options: flat cut device, date printer, easy tear feature
- Nitrogen flushing connector included; nitrogen machine can be linked on-site
- Power supply configured for destination market voltage on request
How It Compares
| Sequential inner and outer bag machine | The C19H forms and seals both bags at once, increasing output by up to 100% compared to machines that pack one layer at a time |
|---|---|
| Heat-sealed drip bag machine | Ultrasonic sealing avoids heat damage to coffee aroma and maintains a narrower seal edge, but requires an air supply |
| Manual bagging with hand sealing | The C19H replaces a hand-filling team and ensures consistent fill weight and seal quality, but requires a fixed 1200 x 900 mm footprint |
Use Guide
- 1Connect a clean dry air supply and single phase 220V 50Hz power outlet
- 2Load the selected film roll (180 mm inner, 200 mm outer) and thread through the forming guides
- 3Set the desired bag length using the stepper motor control and confirm positioning
- 4Enter fill weight between 5 and 15 g and calibrate the volumetric cup with your coffee
- 5Run 10 test bags and check fill weight, seal integrity, and bag length before batch start
- 6Use the reserved connector to link with a nitrogen machine if shelf life extension is required
C19H Drip Arabica Coffee Bag Packing Machine FAQ
What is the fill weight range?
5 to 15 g per bag, with consistent output using the volumetric cup filler.
How fast does it run?
40 to 60 bags per minute, depending on bag size, fill weight, and coffee flow rate.
Can it run biodegradable film?
Yes. It runs PLA film and filter paper as well as plastic, aluminum composite, and other standard materials.
Does it support nitrogen flushing?
Yes. It has a reserved connector to link with a nitrogen making machine for flushing into the bag.
What power supply does it need?
Single phase 220V 50Hz, 3.7 kW. We can adjust the voltage and plug type for your market.
What floor space and lifting capacity are needed?
The machine measures 1200 x 900 x 1900 mm and weighs 700 kg. Plan for forklift access and doorway clearance.
Is it certified?
Sengong is certified to ISO and CE. Certificates are available upon request via email or WhatsApp.
