Key Benefits
- Produces inner and outer bags simultaneously, reducing cycle time and increasing throughput
- Ultrasonic sealing creates a narrow, clean seal without heat or adhesive, preserving coffee aroma
- Volumetric cup filling ensures consistent 5 to 15 g per bag with minimal giveaway
- Supports nitrogen flushing via reserved connector to extend shelf life of roasted coffee
- Stainless steel food contact parts ensure compliance with food safety standards
- Stepper motor controlled outer bag sealing provides accurate positioning and stable operation
Application Scenarios
- Coffee roasters packaging cold brew and drip coffee for direct-to-consumer e-commerce
- Contract packers handling short runs of multiple coffee blends with quick format changeover
- Brands launching single-origin coffee in a premium dual-layer bag with visible inner content
- Packaging facilities replacing manual bagging or slow semi-automatic lines for higher volume
Who It Is For
- Coffee roasters moving from hand packing to in-house automatic dual-bag packaging
- Contract packers serving multiple coffee brands with different bag sizes and formats
- Brands that need nitrogen flushing to extend shelf life of roasted coffee
- Packaging lines requiring a sealed inner bag with a protective outer layer for retail display
Problems It Solves
- Manual inner and outer bag assembly slows output and increases labor cost
- Heat sealing damages delicate coffee oils and can create a wide waste edge on film
- Inconsistent fill weight leads to customer complaints and higher giveaway
- Lack of nitrogen flushing causes coffee to degrade faster in the bag
- Poor outer bag positioning leads to misaligned labels and poor shelf appearance
Technical Features
- Ultrasonic sealing for inner and outer bags with a narrow, clean seam
- Volumetric cup filler for consistent 5 to 15 g per bag with no overfill
- Stepper motor controlled outer bag sealing for accurate length positioning
- PID temperature controller for stable heat sealing performance
- PLC control system with human machine interface for easy operation
- All food contact parts made of SUS304 stainless steel for hygiene and durability
- Reserved connector for nitrogen flushing to extend shelf life
- Optional flat cut, date printer, and easy tear device for retail packaging
Specifications
| Machine model | C19H-2 |
|---|---|
| Machine type | Drip Coffee Packaging Machine Series |
| Bag type | Ultrasonic sealing |
| Packing material | PLA/Paper/Plastic, Plastic/Aluminum/Plastic, Paper/Aluminum/Plastic, Filter paper |
| Feeding system | Volumetric cup filler |
| Package range | 5-15 g per bag |
| Inner bag size | L: 50-75 mm, W: 50-90 mm |
| Outer bag size | L: 85-120 mm, W: 75-100 mm |
| Inner bag film width | 180 mm |
| Outer bag film width | 200 mm |
| Packing speed | 40-60 bags/min |
| Power supply | Single phase, 220V, 50Hz, 3.7 kW |
| Machine weight | 700 kg |
| Machine dimension | 1200 x 900 x 1900 mm (L x W x H) |
Packing Materials It Runs
- PLA/Paper/Plastic film for compostable dual-layer coffee bags
- Plastic/Aluminum/Plastic film for moisture and light barrier packaging
- Paper/Aluminum/Plastic film for premium retail appearance and shelf life
- Filter paper for inner bags in direct contact with coffee grounds
How the Machine Works
- 1Film unwinding and inner bag forming
- 2Volumetric cup filling with 5 to 15 g per bag
- 3Inner bag ultrasonic sealing and cutting
- 4Outer bag forming and ultrasonic sealing
- 5Outer bag length positioning via stepper motor
- 6Optional nitrogen flushing, date coding, or flat cutting
Quality Control Before Shipment
- F
- i
- l
- l
- i
- n
- g
- w
- e
- i
- g
- h
- t
- v
- e
- r
- i
- f
- i
- e
- d
- a
- g
- a
- i
- n
- s
- t
- 5
- t
- o
- 1
- 5
- g
- t
- a
- r
- g
- e
- t
- d
- u
- r
- i
- n
- g
- t
- e
- s
- t
- r
- u
- n
- s
- S
- e
- a
- l
- i
- n
- t
- e
- g
- r
- i
- t
- y
- i
- n
- s
- p
- e
- c
- t
- e
- d
- o
- n
- u
- l
- t
- r
- a
- s
- o
- n
- i
- c
- s
- e
- a
- m
- b
- e
- f
- o
- r
- e
- s
- h
- i
- p
- m
- e
- n
- t
- F
- o
- o
- d
- c
- o
- n
- t
- a
- c
- t
- p
- a
- r
- t
- s
- c
- o
- n
- f
- i
- r
- m
- e
- d
- a
- s
- S
- U
- S
- 3
- 0
- 4
- s
- t
- a
- i
- n
- l
- e
- s
- s
- s
- t
- e
- e
- l
- a
- n
- d
- n
- o
- n
- -
- t
- o
- x
- i
- c
- M
- a
- c
- h
- i
- n
- e
- t
- e
- s
- t
- e
- d
- w
- i
- t
- h
- c
- u
- s
- t
- o
- m
- e
- r
- '
- s
- c
- o
- f
- f
- e
- e
- b
- l
- e
- n
- d
- b
- e
- f
- o
- r
- e
- d
- i
- s
- p
- a
- t
- c
- h
- o
- n
- r
- e
- q
- u
- e
- s
- t
Certifications
- ISO
- CE
Customization Options
- Choice of inner and outer bag film type to match brand and compostability goals
- Adjustable inner bag size from 50 to 75 mm in length and 50 to 90 mm in width
- Adjustable outer bag size from 85 to 120 mm in length and 75 to 100 mm in width
- Optional flat cut, date printer, or easy tear device added at factory
- Reserved connector for nitrogen flushing system integration
- Power supply configured for destination market voltage on request
How It Compares
| Manual inner and outer bag assembly | The C19H automates both bag stages and runs 40 to 60 bags per minute, but requires a fixed footprint of 1200 x 900 mm and trained operator |
|---|---|
| Heat sealed dual-bag machine | Ultrasonic sealing avoids scorching and waste edge, but requires an air supply and is not suitable for all film types |
| Single-layer filter bag machine | The C19H provides a protective outer layer and nitrogen flushing capability, but uses more film and requires more setup time |
Use Guide
- 1Connect a clean dry air supply and single phase 220V 50Hz power outlet
- 2Load the inner and outer film rolls matched to your chosen bag size and film type
- 3Set inner bag size to 50-75 mm and outer bag size to 85-120 mm on the control panel
- 4Enter target fill weight between 5 and 15 g and calibrate the volumetric cup with your coffee
- 5Run ten sample bags and check fill weight, seal integrity, and outer bag positioning
- 6Use the reserved connector to link with a nitrogen generator if shelf life extension is required
C19H Cold Brew Liberia Coffee Filter Bag Packing Machine FAQ
What is the fill weight range?
5 to 15 grams per bag, with consistent volume control via the volumetric cup filler.
How fast does it run?
40 to 60 bags per minute, depending on bag size, film type, and coffee flow rate.
Can it run nitrogen flushing?
Yes. The machine has a reserved connector to link with a nitrogen making machine for flushing.
What film types can it use?
PLA/Paper/Plastic, Plastic/Aluminum/Plastic, Paper/Aluminum/Plastic, and filter paper.
What power supply does it need?
Single phase 220V 50Hz, 3.7 kW. We can adjust voltage for your market on request.
How much space and lifting capacity do I need?
The machine measures 1200 x 900 x 1900 mm and weighs 700 kg. Plan for forklift access and doorway clearance.
Is it certified?
Sengong is certified to ISO and CE. Certificates are available by email or WhatsApp.
