Exhaust Catback · SKU ESP-0006
Stainless Steel Exhaust Pipe Catback Exhaust Muffler for Mazda Miata MX-5 Eunos 89-97 1.6/1.8L
A 2.25 inch mandrel bent stainless steel catback exhaust muffler system for the 1989-1997 Mazda Miata MX-5 and Eunos 1.6/1.8L. It replaces the factory exhaust from the catalytic converter rearward and ships as a complete system with bolts and gaskets. Fitment is specific to the first generation Miata and does not cover later models or other variants.
- MaterialT-304 Stainless Steel
- Pipe Diameter2.25 inch
- Muffler StyleN1 with removable silencer
- Tip Size4.0 inch
What You Get
Key Benefits
- 2.25 inch mandrel bent piping maintains consistent bore size for improved exhaust flow and reduced back pressure
- N1 style muffler with removable silencer allows for custom sound tuning and easier maintenance
- 4.0 inch tip increases exhaust velocity and improves engine breathing under load
- Complete kit with bolts and gaskets reduces installation time and ensures proper sealing at all joints
Why Buyers Switch
Problems It Solves
- Factory exhausts restrict flow and limit engine breathing, especially under sustained load
- Universal exhausts require cutting and welding, which increases labour cost and reduces shop margins
- Missing gaskets and bolts in aftermarket kits force buyers to source components separately
Where It Is Used
Application Scenarios
- Performance shops upgrading MK1 Miata engines for track or street use with measurable power gains
- Distributors stocking bolt-on exhaust upgrades for classic Miata owners in North America and Europe
- Online sellers needing a vehicle-specific part with a clean fitment list and high-quality visuals
- Independent tuners replacing corroded factory exhausts on high-mileage 1989-1997 Miata models
Buyers
Who It Is For
- Performance parts distributors buying classic car exhaust systems by the pallet
- Online auto parts sellers serving the Mazda Miata enthusiast market
Construction
Technical Features
- Complete catback exhaust system from catalytic converter to 4.0 inch tip
- 2.25 inch mandrel bent T-304 stainless steel piping with consistent bore
- N1 style muffler with removable silencer for sound tuning and service access
- Bolts and gaskets included for direct bolt-on installation
Data
Specifications
| Material | T-304 Stainless Steel |
|---|---|
| Pipe Diameter | 2.25 inch |
| Muffler Style | N1 with removable silencer |
| Tip Size | 4.0 inch |
| Bending | Mandrel bent |
| Package | 1x Catback Exhaust with bolts and gaskets |
| Fitment | 1989-1997 Mazda Miata MX-5 and Eunos 1.6/1.8L |
| Exclusion | Does not fit later model Miata generations or other variants |
Material
Materials
- T-304 stainless steel piping
- Removable silencer assembly
- Bolts and gaskets included
Manufacturing
How It Is Made
Piping cut to length and mandrel bent to match factory routing
Muffler assembly with removable silencer and internal baffling
Flanges machined and fitted to the piping ends
Welding of flanges and silencer to the main pipe
Checks
Quality Control
- Flange alignment and sealing face checked before welding
- Weld seams inspected for pinholes and incomplete fusion
- Piping bore verified for consistent diameter and no kinks
- Final fit check against a known good Miata exhaust pattern
Private Label
Customisation Options
- Private label packaging and barcode labels on request
- Bulk cartons available for container orders instead of individual retail boxes
Comparison
Compared With The Alternatives
| Factory exhaust system | The stock exhaust is designed for emissions compliance and noise reduction, this one increases flow and engine breathing at the cost of a louder exhaust note |
|---|---|
| Mild steel aftermarket exhaust | Mild steel is cheaper but rusts through at the muffler and flange joints within a few years; T-304 stainless holds up through long-term exposure to moisture and heat |
| Universal cut-to-fit exhaust | A universal pipe requires cutting, welding, and custom fitting, which increases labour cost and risk of leaks; this one bolts on directly |
Installation
Use Guide
- Confirm the vehicle is a 1989-1997 Mazda Miata MX-5 or Eunos with 1.6L or 1.8L engine
- Disconnect the battery before starting exhaust removal to prevent electrical issues
- Remove the factory exhaust from the catalytic converter rearward, including the muffler and tailpipe
- Install the new catback system using the included bolts and gaskets, torquing in a crisscross pattern
- Recheck all flange connections after the first heat cycle to ensure no leaks
Answers
Questions About This Part
Will this fit a 1998 Mazda Miata?
No. The part is designed for 1989-1997 Mazda Miata MX-5 and Eunos 1.6/1.8L models and does not fit 1998 and later generations.
What size is the exhaust pipe?
2.25 inch. The piping is mandrel bent to maintain consistent bore size throughout the system.
Is the muffler removable or fixed?
The muffler features a removable silencer. The internal baffle can be taken out for sound tuning or cleaning.
What is included in the package?
One complete catback exhaust system with bolts and gaskets. Installation instructions are not included.
Can we get our own brand on the box?
Yes. Private label packaging and barcode labels can be arranged, and bulk cartons are available for container orders.
Is this street legal in my country?
Emissions regulations vary by region. We do not claim emissions compliance for this part. Check your local laws before resale.
