The Sinotruk Steyr 10 tons sludge vacuum truck is a 10000 litre sewage collection vehicle built on a 4x2 HOWO chassis with a 290 HP diesel engine and 10 speed manual gearbox. It is designed for municipal sanitation departments, waste contractors and public works operators that need to collect and transport sludge, fecal matter, crude oil and solid debris from septic tanks, cesspits and blocked drains in urban and rural areas. The double Weilong vacuum pump achieves full tank extraction in under 5 minutes and can suction vertically up to 8 metres and horizontally up to 60 metres, allowing access to deep or hard to reach underground systems.
| Chassis | HOWO 4x2 left or right hand drive |
|---|---|
| Engine | 290 HP diesel, WD615.97, 6 cylinders, turbo-charged, inter-cooling, high common rail |
| Gearbox | HW19710, 10 forward speeds with 2 reverse |
| Overall Size | 8480 x 2500 x 3250 mm |
| Loading Capacity | 10000 kg |
| Gross Vehicle Weight | 16000 kg |
| Tank Capacity | 10000 L |
| Tank Material | 5mm carbon steel |
| Tank Shape | Cylindrical |
| Vacuum Pump | Double Weilong pump |
| Suction Depth | ≥6 m |
| Horizontal Suction | 40–60 m |
| Vertical Suction | ≤8 m |
| Extraction Time | Single full pumping ≤5 min |
| Sewage Efficiency | After a single row ≤4 min |
| Control Method | Electric control + manual control |
| Operating Position | Cab + front of tank |
| Tire Specification | 295/80R22.5 tubeless |
| Wheelbase | 4600 mm |
| Brake System | Air brake |
| Steering | Left or right hand drive with power-assisted |
| Air Conditioning | Suitable for tropical climate |
| Production Time | 20 days |
| Delivery Time | Based on shipping mode chosen |
| 6x4 sludge truck with 8000 L tank | Higher capacity and better ground clearance but harder to maneuver in narrow streets |
|---|---|
| Used imported vacuum truck | Lower upfront cost but higher long term maintenance and parts delays |
| Standard sewage tanker with single pump | Slower extraction and less suction depth but simpler maintenance and lower cost |
Production time is 20 days after the advance payment. Delivery time depends on the shipping mode chosen.
Yes. The standard tank is 5mm carbon steel. Stainless steel is available on request. Specify water quality and storage duration for material confirmation.
T/T with 30 percent deposit and 70 percent before delivery. Photos and videos of the finished truck are sent before the balance is paid.
Yes. The chassis is ordered in left or right hand drive to match your local traffic regulations. Confirm this at order stage.
By Ro-ro or bulk ship from a China main port. Trade terms can be EXW, FOB, CFR or CIF.
The whole vehicle is guaranteed for one year. Core parts are covered for two years. We provide 15 years of spare parts and technical support.
Yes. The control system can be adapted for remote operation or automated functions. Provide your requirements at order stage.
Send us your destination port and we will quote price, lead time and freight.
