The Sinotruk HOWO 5000L sewage exhauster truck is a 4x2 right hand drive vacuum tanker built on a Sinotruk HOWO chassis for municipal and industrial waste collection in urban and rural environments. It is designed for suction, transport, and discharge of sludge, sewage, and sediment from manholes, water wells, and septic tanks. The truck operates in regions with limited access infrastructure and requires reliable, low-maintenance performance over long service cycles.
| Chassis | Sinotruk HOWO 4x2 right hand drive |
|---|---|
| Engine | Yunnei 4102QBZL, 4-stroke, 4-cylinder, turbocharged, inter-cooled |
| Horse Power | 116 HP |
| Emission Standard | Euro Ⅲ |
| Gearbox | WLY646, 6 forwards, 1 reverse |
| Transmission | Manual |
| Overall Dimensions | 5995 x 2150 x 2450 mm |
| Wheelbase | 3360 mm |
| Wheel Track | 1605/1540 mm |
| Approach Angle | 20 degrees |
| Departure Angle | 25 degrees |
| Tare Weight | 3300 kg |
| Recommended Payload | 4500 kg |
| Front Axle Capacity | 2400 kg |
| Rear Axle Capacity | 4200 kg |
| Max Speed | 90 km/h |
| Tank Capacity | 5000 L |
| Tank Material | Carbon steel Q345 or stainless steel 304 |
| Tank Thickness | Body 5 mm, Head 6 mm, Partition 4 mm |
| Suction Depth | Up to 9 metres |
| Suction Distance | Up to 80 metres |
| Fill Time | 10 minutes |
| Blowdown Time | 8 minutes |
| Pump Type | Small Veyron single pump or large Veyron double pump |
| Operation Method | Manual + pneumatic + hydraulic |
| Leak-proof System | Rubber strip + hydraulic lock + manual lock |
| Tire Model | 7.50R16, 6 pieces with one spare |
| Brakes | Full air brake with ABS, disc brakes front and rear |
| Suspension | Rigid axle type front and rear |
| Electrical System | 24 volt, traffic compliant |
| Production Time | 20 days |
| Lead Time | 7 to 30 days after deposit |
| 3000L vacuum truck | Smaller capacity but better maneuverability in narrow urban alleys |
|---|---|
| 30000L sewage tanker | Higher capacity but requires more space and longer fill time |
| Used imported vacuum truck | Lower initial cost but higher long-term maintenance and parts delay risk |
Production takes 20 days. Delivery time varies from 7 to 30 days based on shipping mode and chassis availability.
Yes. The standard tank is Q345 carbon steel. Stainless steel 304 is available on request for corrosive or hygiene-sensitive applications.
T/T with 30 percent deposit and 70 percent before delivery. Photos and videos of the finished truck are sent before the balance payment.
Yes. The chassis is ordered as right hand drive to match local traffic rules. Confirm this at the time of order.
By Ro-ro or bulk ship from a China main port. Trade terms are EXW, FOB, CFR, or CIF.
The whole vehicle is guaranteed for one year. Core components are supported for 15 years with spare parts and technical assistance.
Yes. The truck can be built with a single Veyron pump for light duty or a double Veyron pump for faster suction and higher capacity.
Send us your destination port and we will quote price, lead time and freight.
