Sinotruk HOWO 5 ton sewage removal truck in urban environment with suction hose connected to a manhole

Side view of the HOWO sewage truck showing the fully open tailgate and hydraulic lift system

Rear view of the vacuum pump and discharge nozzle on the HOWO sewage removal truck

Sinotruk Howo 5 ton sewage removal truck Indonesia

Name: Sinotruk Howo 5 ton sewage removal truck Indonesia
Brand: Sinotruk HOWO

The Sinotruk HOWO 5 ton sewage removal truck is a 5000 litre vacuum tanker built on a 4x2 HOWO chassis with a 115 HP YUCHAI diesel engine and a 7.00R16 tire configuration. It is designed for municipal sanitation departments and waste contractors that need to collect and transport sludge, mud, and debris from sewer manholes, water wells, and sediment pits in urban and rural environments. The truck uses a high-efficiency vacuum pump with a 93% vacuum rate and a 6 metre suction lift to fill the tank in under 10 minutes, making it suitable for frequent operations in dense city networks and remote areas with limited access.

Request A Quote Email Specification

Key Benefits

5000 litre carbon steel tank with 6-8 mm body thickness and 8 mm head for long-term durability
Vacuum pump achieves 93% vacuum rate and fills the tank in 10 minutes with a 6 metre suction lift
Suction depth reaches up to 9 metres and horizontal reach up to 80 metres for deep and distant access
Blowdown completed in 8 minutes using hydraulic lift dumping and air blowdown methods
Dual control system allows operation from cab or side of the truck for flexible positioning
Tailgate opens fully for complete access and gravity-assisted discharge with anti-overflow valve
Leak-proof design with rubber strip, hydraulic lock, and manual lock on the tank door

Buyer Profile

Who It Is for

Municipal sanitation and public works departments in developing countries
Private waste and sewage contractors with fleets operating in low infrastructure zones
Construction companies managing on-site sludge and mud during earthworks
Industrial park operators maintaining internal drainage and waste collection
Contractors supplying turnkey waste removal services to local governments
Water utility operators managing sediment and debris in aging sewer networks

Operating Problems

Problems It Solves

Sewer manholes that are inaccessible to larger trucks due to narrow streets or poor road conditions
Slow suction and long refill times that reduce daily operational capacity
Tank leaks or poor sealing that lead to contamination and environmental risk
Lack of vacuum power that prevents deep or long-distance suction from pits
No remote control or side access that limits safe operation in tight spaces
Short service life of tanks due to thin material or lack of corrosion protection

Where It Works

Application Scenarios

Municipal sanitation teams cleaning blocked sewer manholes in high-density urban areas
Rural water and waste contractors servicing remote villages with no central sewage system
Construction sites managing sludge and sediment from excavation and foundation work
Industrial parks handling waste from water treatment and drainage systems
Emergency response units clearing blocked drains after heavy rainfall or flooding
Waste contractors operating on tight schedules with multiple daily pickups

Engineering

Technical Features

5000 litre carbon steel tank with Q345 material and 6-8 mm body thickness
Vacuum pump with 93% vacuum rate, 6 metre suction lift, and quick fill in 10 minutes
Suction horizontal reach up to 80 metres and vertical depth up to 9 metres
Blowdown completed in 8 minutes using hydraulic lift and air blowdown
Dual control system: manual, pneumatic, and hydraulic operation from cab or side
Tailgate opens fully with gravity valve and anti-overflow protection
Leak-proof tank door with rubber strip, hydraulic lock, and manual lock
Standard accessories include 8 metre suction pipe, discharge nozzle, pneumatic control box, and basic tool kit
Sight liquid window, hydraulic gauge, negative pressure meter, and anti-overflow valve installed

Specifications

Technical Data


Chassis	Sinotruk HOWO 4x2, 5 ton
Engine	YUCHAI diesel, 115 HP, Euro 3
Tank Material	Q345 carbon steel
Vacuum Pump	Italy BP / Weilong / Domestic
Suction Lift	6 metres
Suction Depth	Up to 9 metres
Suction Distance	Up to 80 metres
Fill Time	Under 10 minutes
Blowdown Time	Single 8 minutes
Tank Thickness	Body 6-8 mm, Head 8 mm, Partition 5 mm
Tire Specification	7.00R16
Tire Quantity	6+1
Wheelbase	3360 mm
Cab Capacity	2/3 persons
Production Time	20 days
Delivery Time	Based on shipping mode
Overall Size	5950 x 2100 x 2600 mm
Operation Method	Manual + Pneumatic + Hydraulic
Tailgate Form	Fully open, fully open tail

Build Materials

Materials

Q345 carbon steel tank body with 6-8 mm thickness and 8 mm head
Stainless steel 304 available on request for corrosive waste
Carbon steel frame and chassis with Sinotruk HOWO 4x2 configuration
Wire-reinforced suction hose with high durability
Rubber strip and hydraulic lock for tank door sealing
Aluminium alloy components on pump and control box for corrosion resistance

How It Is Built

Manufacturing Process

Chassis is received from Sinotruk and wheelbase is verified against the tank drawing
Tank shell is cut, rolled, and welded with internal clapboards to reduce surge
Tank is pressure tested and leak tested before leaving the welding shop
Vacuum pump and piping are installed and aligned with the driveline
Suction hose, discharge nozzle, control box, and tool kit are fitted
Leak-proof door system with rubber strip, hydraulic lock, and manual lock is assembled
Cab and side control panels are installed with pneumatic and hydraulic lines
Body is shot blasted, primed, and finished in customer colour with logo
Final test includes vacuum performance, suction fill time, and blowdown cycle

Testing

Quality Control

Every truck is 100 percent tested before delivery
Tank pressure and leak tests conducted in-house
Vacuum pump performance verified at 93% rate and 6 metre lift
Suction and blowdown times measured under standard conditions
Photos and videos of the finished truck sent before balance payment
All components comply with GB standards for sewage and waste transport vehicles

Build to Order

Customization Options

Tank capacity from 3000 L to 30000 L available on request
Tank material can be changed from carbon steel to stainless steel 304
Tank colour and logo applied free of charge
Left or right hand drive chassis available to match local regulations
Optional: liquid full alarm self-stop, water ring vacuum pump, anti-corrosion treatment
Manufacture to customer supplied technical drawings and specifications

Comparison

How It Compares With the Alternatives

3 ton sewage truck with 2000 L tank	Lower capacity and more frequent refills but better for narrow urban streets
30,000 L large vacuum tanker	Higher capacity but less maneuverable and requires more space for operation
Used truck with unknown maintenance history	New build with 15 years spare parts support and full warranty, no hidden wear

Operating Notes

Use Guide

Confirm the chassis drive configuration and hand of drive before ordering to match local traffic rules
Use only the 8 metre suction pipe and ensure the inlet is clear before starting suction
Do not exceed 9 metres vertical suction depth or 80 metres horizontal reach to avoid pump strain
Engage the vacuum pump only after the suction hose is fully inserted and sealed
Use the hydraulic lift and air blowdown system together for fastest discharge
Drain the tank and flush the system after use in corrosive environments to prevent buildup

Buyer Questions About This Truck

What is the lead time for this sewage truck?

Production takes 20 days after the advance payment is received. Delivery time depends on the shipping mode chosen.

Can the tank be made from stainless steel?

Yes. The standard tank is Q345 carbon steel. Stainless steel 304 is available on request. Specify the waste type and storage duration for material confirmation.

What are your payment terms?

T/T with 30 percent deposit and 70 percent before delivery. Photos and videos of the finished truck are sent before the balance payment.

Do you supply right hand drive?

Yes. The chassis can be ordered in left or right hand drive to match local traffic regulations. Confirm at order stage as it cannot be changed later.

How is the truck shipped?

By Ro-ro or bulk ship from a China main port. Trade terms can be EXW, FOB, CFR, or CIF.

What warranty and after sales support do you provide?

The whole vehicle is guaranteed for one year. Core parts are covered for two years. We provide 15 years of spare parts and technical support, including overseas engineer visits and training.

Can the vacuum pump be upgraded?

Yes. Options include water ring vacuum pump, liquid full alarm self-stop, and anti-corrosion treatment inside the tank. Specify your requirements at order stage.
