VT390 Advanced Fleet GPS Tracker with Speed Limiter & RS232 Camera
VT309: Advanced Fleet Management GPS Tracker with Speed Limiter & Camera Support
Product Overview
The VT390 is a premier, high-tier GPS tracking terminal engineered for sophisticated fleet management, multi-border transit logistics, and high-security enterprise passenger transport. Offering unparalleled processing power and rich peripheral interfaces, it is the ultimate tracking solution for school buses, logistics fleets, taxi companies, public buses, car rentals, and corporate vehicle dispatching. Equipped with dual-core capabilities supporting a speed limiter system and an RS232 photo-taking camera, the VT390 brings studio-grade monitoring to everyday fleet operations.
Key Features & Benefits
- RS232 Camera & Photo Log Integration: Supports 1 wired RS232 camera to capture photos based on dispatch events or alerts. Images are logged with real-time location and driving information, then seamlessly saved onto an onboard 4G SD card and uploaded to your tracking platform.
- Integrated Speed Limiter Control: Built-in speed monitoring works directly with a dedicated speed limiter module to display speeds on-screen and automatically restrict the vehicle's maximum speed, ensuring strict compliance with local safety laws.
- Extensive Multi-Sensor Fuel & Temp Monitoring: Features advanced analog ports supporting up to 4 independent fuel sensors simultaneously, providing robust protection against fuel leaking and fuel theft with instant refuel and drainage alerts.
- Multi-SIM International Logistics Support: Accommodates a 1 to 5 SIM card expansion layout, specifically engineered to eliminate roaming friction and secure uninterrupted global asset tracking for cross-border transport.
- Comprehensive Driver ID Recognition: Fully compatible with a vast array of authentication kits to log driver profiles and manage automatic arming/disarming states:
- Biometric Fingerprint Scanner: Stores and manages 50 to 100 unique driver fingerprints.
- Bluetooth Beacon & Mobile Phone RFID: Hands-free smart lock control using beacons or personal mobile devices.
- iButton & Passive RFID Kits: Handles up to 100+ physical iButton tags or 500+ passive RFID employee card numbers.
- Unmatched I/O Processing Power: Built with 5 Digital Inputs, 5 Digital Outputs, and 4 high-resolution 10-bit Analog Inputs to coordinate highly complex vehicle automation workflows.
- Industrial Safety & Communication Alarms: Features an integrated microphone and speaker port for real-time two-way talking communication and discrete remote wiretapping. Delivers proactive alerts for vehicle crashes, harsh braking, heavy acceleration, towing, geo-fencing, power failure, and SOS emergency panic triggers.
- Resilient Data Logging: Houses an onboard 4MB backup flash memory storing up to 26,000+ precise waypoints to safeguard vehicle history logs even when cellular GPRS coverage completely drops.
| Parameter | Specification |
|---|---|
| Model | VT390 |
| Main Application | School Bus, Logistics, Corporate Fleets, Taxis, Heavy Asset Security |
| Working Voltage | 9-50 VDC / 1.0A (Input range 9V-36V, 12V recommended) |
| Backup Battery | High-capacity 950mAh / 900mAh Lithium Battery |
| Memory Flash | 4MB internal (stores 26,000+ waypoints) + 4G SD Card Slot for photos |
| Interface Port Capacity | 5 Digital Inputs, 5 Digital Outputs, 4 Analog Inputs, 1 RS232 Port |
| Analog Input Resolution | 10 bits Resolution (0-6V DC Detection range) |
| International Transit | Supports 1-5 SIM cards for cross-border network switching |
| Voice & Audio | Independent Speaker Port + Microphone (MIC) Port (Two-Way Talking) |
| Firmware Upgrades | Supports Over-The-Air (OTA) wireless updates |
Specifications on this page are the ones published by GOTOP for this model. Ask us before ordering if you need a band, battery or protocol that is not listed.
Related Products
Other Models In This Range
Vehicle GPS Tracker
4G Car GPS tracker G01-4G
Vehicle GPS Tracker
Vehicle GPS tracker C790-Y
Vehicle GPS Tracker
VT302 RS232 Serial Port & Driver ID Recognition Fleet GPS Tracker
Order Or Modify This Model
Small orders are welcome, and our engineers can change firmware, protocol or housing to match your platform.
FAQ
VT390 Advanced Fleet GPS Tracker with Speed Limiter & RS232 Camera FAQ
How does the camera integration function during standard operation?
The VT390 connects to a specialized wired camera via its 4-pin RS232 serial interface. Fleet managers can configure the camera to automatically capture snapshots based on specific triggers—such as when a vehicle door opens, an ignition alert fires, or an SOS panic button is pressed. Every photo captured includes an embedded location, time, and telemetry log, caching safely onto the onboard 4G SD card and transmitting back to the cloud platform.
What are the distinct benefits of the 10-bit Analog Inputs (AD1-AD4)?
Unlike standard trackers that limit you to one telemetry reader, the VT390 boasts four high-precision analog inputs with 0-6V DC detection. This allows corporate clients to monitor multiple data points simultaneously on a single vehicle—such as tracking dual fuel tanks with high accuracy while keeping tabs on cold-chain cargo compartment temperatures.
Why is the VT390 ideal for school bus and public transit management?
The VT390 incorporates a strict Speed Limiter workflow alongside Driver Identity Management. It effectively enforces a maximum speed threshold on the vehicle while preventing unauthorized operation via biometric fingerprint scanners or RFID tags. Dispatchers can review exactly who is driving, confirm the passenger environment using the two-way voice speaker, and immediately enforce remote engine cut-offs in unsafe scenarios.
