VT301 RFID Driver ID Recognition
VT301: Advanced Driver ID Recognition & Fleet Management GPS Tracker
Product Overview
The VT301 is an advanced car GPS tracking terminal designed to deliver high-performance driver identity recognition and vehicle security solutions for fleet management and anti-theft systems. It offers a highly cost-effective, concealed RFID solution that allows fleet managers to seamlessly track driver assignments without needing expensive, bulky external RFID kits. The system ensures ultimate security by only allowing authorized operators to start the engine, significantly mitigating vehicle theft risks.
Key Features & Benefits
- Comprehensive Driver Identity Management: Supports multiple authentication methods to log driver IDs onto the tracking platform:
- Bluetooth Beacon RFID: Automatically ARMS when the driver walks 10 meters away and DISARMS upon return. Ideal for anti-theft applications.
- Passive RFID & iButton: Seamless auto-arm on engine OFF and auto-disarm via authorized tags (supports 100+ to 500+ ID tags).
- Driver Fingerprint Identify: Biometric support for identifying 50 to 100 unique driver fingerprints.
- Anti-Hijack & Smart Immobilization: If a hijack occurs, once the driver with the Bluetooth beacon leaves the vehicle, the tracker automatically immobilizes the vehicle safely when the speed drops below 30km/h.
- Anti-GSM Jamming Protection: Immediately immobilizes the vehicle upon detecting GSM interference until the blocker signal vanishes or an authorized RFID tag approaches.
- Advanced Fuel & Mileage Tracking: Supports precise fuel level monitoring with automatic alarms for sudden fuel theft and notifications for refueling events. Provides comprehensive mileage calculation and viewing via SMS or the web portal.
- Robust Security Alerts: Equipped with instant alarms for illegal ACC ON, illegal door opening, tampering, vehicle crashes, excessive idling, and vibration.
- Global Transport Readiness: Features an optional Dual SIM card slot, making it the perfect tracking choice for cross-border international transport.
- Voice Capabilities: Supports voice monitoring and two-way talking communication for enhanced operator safety.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | VT301 |
| Dimensions (L*W*H) | 80 * 57 * 21 mm |
| Weight | 80g |
| Working Voltage | 9-35 VDC / 1.0A (Optional 90V) |
| GSM Frequencies | 2G Quad-band: 850/900/1800/1900MHz |
| 4G LTE FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28/B66 | |
| Positioning Accuracy | ≤ 10m (Wide-open area) |
| Backup Battery | 500mAh Lithium Battery |
| Memory Flash | 64MB Capacity (Stores up to 30,000 offline records) |
| Working Temperature | -20 to 85 °C |
| I/O Interfaces | 2 Digital Inputs, 1 Digital Output, 1 Analog Input |
| Protocols Supported | TCP / UDP / HTTP / MQTT |
Specifications on this page are the ones published by GOTOP for this model. Ask us before ordering if you need a band, battery or protocol that is not listed.
Related Products
Other Models In This Range
Vehicle GPS Tracker
4G Car GPS tracker G01-4G
Vehicle GPS Tracker
Vehicle GPS tracker C790-Y
Vehicle GPS Tracker
VT302 RS232 Serial Port & Driver ID Recognition Fleet GPS Tracker
Order Or Modify This Model
Small orders are welcome, and our engineers can change firmware, protocol or housing to match your platform.
FAQ
VT301 RFID Driver ID Recognition FAQ
How does the driver identification feature work on the tracking platform?
When a driver scans their RFID tag, uses the fingerprint reader, or approaches with an authorized Bluetooth beacon, the VT301 transmits the unique Driver ID to the tracking software. This allows dispatch teams to view exactly who is operating which vehicle, alongside precise timestamps.
What happens if an unauthorized driver attempts to start the vehicle?
In its armed state, if an illegal driver tries to turn the ACC ON or open the door, the VT301 instantly sends an alarm message to the platform and restricts the vehicle from starting by activating the immobilization relay.
How does the tracker save cellular data costs during international transit?
The VT301 utilizes smart Dual Time Interval Settings. You can configure a faster data upload rate when the engine is ON and a significantly slower, data-saving interval when the engine is OFF. Additionally, its massive 64MB memory caches up to 30,000 logs offline if cellular network coverage is temporarily unavailable.
