Car GPS Tracker TK-206
TK-206 is simple GPS tracking devices which is the smallest GSM/GPRS/GPS car tracker with high performance. It is a simple tracker with basic function. It is easy install and use. The most important feature of it is the small dimension and easy hidden. It is just like a part of the car. The one who stole the car will don't know it is a tracker. You can track the car by mobile phone or GPS tracking website and find the car easily.
- Working voltage: 9-75V
- Inbuilt GPS/GSM antenna
- Tracking via SMS or GPRS
- Engine cut remotely
- SOS button for emergency rescue
- Voice monitoring
- Geo-fencing alarm
- Low battery alarm
- Vibration alarm
- Movement alarm
- Online tracking software,Android/IOS app
- Main pow cut alarm
- Sleeping mode
| GSM module | GSM 850/950//18000/1900MHz |
|---|---|
| GPS sensitivity | -159dBm |
| GPS center frequency | L1, 1575.42MHz |
| GPS positioning accuracy | 5 m |
| Speed accuracy | 0.1 m/s |
| Time accuracy | In sync with GPS |
| GPS Chip | UBLOX |
| Hot start | 1 s |
| Cold start | 38 s |
| Maximum altitude | 18000 m |
| Maximum speed | 515 m/s |
| Acceleration of gravity | ﹤4g |
| Operating temperature | -20---65 ℃ |
| Humidity | 5%---95% |
| Dimensions (mm) | 95x55x15 mm |
| Voltage | 9V - 75V |
| Average standby current | Less than 80MA |
| LED | Power supply, work status indication |
| External alarm switch | SOS |
- Standard Accessories
- 1 Power wire
- 1 Relay
- 1 SOS button
- 1 Microphone
- 1 User manual
Specifications on this page are the ones published by GOTOP for this model. Ask us before ordering if you need a band, battery or protocol that is not listed.
Related Products
Other Models In This Range
Car GPS Tracker
4G Car GPS Tracker GV3
Car GPS Tracker
Car GPS tracker G01
Car GPS Tracker
VT-360 Solar Powered Asset GPS Tracker
Order Or Modify This Model
Small orders are welcome, and our engineers can change firmware, protocol or housing to match your platform.
FAQ
General GPS Tracking Questions
Answers published by GOTOP for all tracking devices.
How do set up the GPRS?
Make sure the command you set according to the below frequent issue. The SIM card of the Tracker supports the GPRS function. Send the APN set command SMS to configure the application and send SMS to tracker to trigger it reply back information. Set The GPRS signal interval the port number you set for the tracker have its program. If your router is dynamic IP addressing, don not forget to resend APN set command SMS when the IP address is changed. check out the IP address for PC server When you login your router, you will get your IP address in the login box. Also there is some website or software could help you to check your own IP address. setup the port number Port number is a random number which is setup by the end user, please make sure this port is not occupied by other software otherwise the PC server software will shut down automatically. In order to avoid the conflict, we suggest you setup the port number bigger than 6000. check out the APN name of your local telecommunication provider If the GPRS configuration has been wrongly set, the device will spend long time to repeatedly engage at connecting with IP address, this will cause the outing SMS delayed.
Who does tracker use for maps and map data?
Currently, GPS tracker Systems is using the Google mapping interface for maps, and partners for the street level data that is displayed on the maps. It is able to use any mapping interface and can customize mapping solutions based on the specific requests or needs.
What is GPRS?
GPRS (General Packet Radio Service) is a digital, IP-based wireless packet data service offered by GSM-based cellular carriers, there is not a new technology out there on the market. GPS Tracker & GPRS or General Packet Radio Services has been around for quite some time. Established in the early 2000’s, GPRS is an extension of the Global System for Mobile Communications.
