Various Series Orbital Hydraulic Motor Made in China for Sale of Factory Price

An orbital hydraulic motor from the BzzSeries 2K range, designed for medium-duty applications in construction and industrial machinery. Available in displacement sizes from 50 to 395 cc/r, with rated pressure up to 13.8 MPa and maximum speed up to 850 RPM. The unit features a compact design with spool valving, gerotor sealing, and multiple mounting options for flexible integration. It is built for use in excavators, wheel loaders, lift trucks, and other hydraulic systems requiring reliable, efficient torque output.

Brand BzzSeries
Model 2K
Place of Origin Shandong, China (Mainl
Displacement 50 to 395 cc/r
Rated Pressure 13.8 MPa (up to 15.5 M

Ask for a Price on WhatsApp Email the Specification

Stock number held for this listing: 10256

BzzSeries 2K orbital hydraulic motor mounted on a steel plate, front view showing shaft and ports

Key Benefits

What This Unit Does Well

Displacement range from 50 to 395 cc/r allows matching to various hydraulic circuit demands
Rated pressure up to 13.8 MPa supports consistent performance in demanding industrial environments
Spool valving and gerotor sealing reduce internal leakage and improve long-term reliability
Multiple mounting flanges, shafts and ports simplify integration into existing machinery
Compact design reduces space requirements in tight engine compartments
Direction and speed control are smooth and precise, suitable for repetitive cycle operations

Application Scenarios

Where It Is Used

Excavator swing and boom control where consistent torque and responsive speed are required
Wheel loader bucket lift and tilt functions under variable load conditions
Lift truck mast operation with stable speed and minimal pressure drop
Fishing winch systems needing controlled reverse rotation and high starting torque
Plastic injection machines requiring precise, repeatable hydraulic motion

Fit

Who It Is For

Machinery repair shops sourcing replacement motors for excavators and loaders
Contractors maintaining fleets of construction equipment with limited spare parts availability
Parts distributors stocking hydraulic motors for regional distribution in Africa and Southeast Asia
Engineering teams integrating hydraulic motors into custom-built machinery or retrofit projects

Buyer Pain

Problems It Solves

Mismatched motor displacement causing poor system response or excessive energy use
Frequent seal failure due to low-pressure shaft seals in high-load applications
Lack of mounting compatibility forcing custom brackets or redesigns
Unpredictable speed control in variable load scenarios due to poor motor design
Long lead times for OEM motors when original equipment is discontinued

Engineering

Technical Features

Orbital hydraulic motor with spool valving and gerotor-type shaft seal
Compact design with multiple flange, shaft and port configurations
Rated pressure up to 13.8 MPa, with maximum pressure up to 15.5 MPa
Speed range from 680 RPM (rated) to 850 RPM (maximum) depending on displacement
Torque output from 92 Nm (rated) to 485 Nm (maximum) across the series
Displacement options: 50, 63, 80, 100, 160, 200, 250, 305, 370, 395 cc/r
Flow capacity from 38 LPM (rated) to 57 LPM (maximum) depending on size
Direction of rotation and speed can be controlled via hydraulic circuit design

Specification

Specification Table for This Listing

Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.

Specification of Various Series Orbital Hydraulic Motor Made in China for Sale of Factory Price
Brand	BzzSeries
Model	2K
Place of Origin	Shandong, China (Mainland)
Displacement	50 to 395 cc/r
Rated Pressure	13.8 MPa (up to 15.5 MPa max)
Rated Speed	680 to 128 RPM
Maximum Speed	850 to 140 RPM
Rated Flow	38 to 53 LPM
Maximum Flow	45 to 57 LPM
Rated Torque	92 to 435 Nm
Maximum Torque	105 to 485 Nm
Weight	6.3 to 9.6 kg
Mounting Options	Multiple flanges, shafts, and ports available
Shaft Rotation	Bidirectional control via hydraulic circuit
Seal Type	Gerotor high-pressure shaft seal
Application Type	Medium-duty hydraulic systems
Brand Name	Bzz
Series Model Number	2K

Materials

Materials and Build

Cast iron or steel housing for structural rigidity and wear resistance
Hardened steel shaft with precision-machined surface for seal integrity
Gerotor-type internal sealing mechanism with high-pressure resistance
Spool valve assembly for precise flow and pressure control
Rubber or metal gasket seals at flange joints for leak prevention

Process

How an Order Is Handled

You provide the machine model, hydraulic circuit pressure, flow rate and mounting requirements
We match the BzzSeries 2K motor with the correct displacement, porting and flange
You confirm the specification sheet and receive a sample or photo before ordering
We prepare the motor, test run it under rated pressure and record the output
Unit is packed in carton, palletized with plastic wrap, and shipped within 3-7 days after payment

Quality Control

Checks Before Loading

Each motor is tested under rated pressure and speed before packing
Shaft seal and spool valve function are verified during test run
External finish, flange alignment and port threading are inspected visually
Random samples are tested for torque output and leakage at the warehouse

Customisation

What Can Be Changed

Custom displacement within the 50-395 cc/r range to match specific hydraulic demand
Custom shaft length, diameter or keyway for direct integration
Custom port size, location or thread type to match existing manifold
Custom flange type or mounting bolt pattern for specific machine design
Special paint or coating for corrosion resistance in harsh environments

Honest Comparison

How It Compares With the Alternatives

Standard gear motor	Orbital design offers higher efficiency and smoother torque delivery at low speeds
Fixed displacement vane motor	Orbital motor handles higher pressure and has longer seal life under continuous duty
Piston motor	Lower cost and simpler maintenance, but less precise speed control under variable load

Use Guide

Using It Well

Install with proper alignment to prevent shaft misload and seal damage
Use only clean hydraulic fluid with viscosity matching the motor's operating range
Check for leaks at ports and seals after initial operation and after 50 hours
Replace seals during maintenance if pressure drop or speed loss is detected
Avoid sudden pressure spikes during start-up to prevent internal component stress

Photographs

More Views of This Unit

Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.

Side view of the hydraulic motor with visible flange and mounting holes

Close-up of the motor shaft and seal area with precision machining detail

Motor placed on a wooden pallet with plastic wrap and export label

Source Specification

Manufacturer Text We Hold for This Listing

Various Series Orbital Hydraulic Motor Made In China For Sale Of Factory Price Various Series Orbital Hydraulic Motor Made In China For Sale Of Factory Price Our Product Product Description Displacement cc/r 50 63 80 100 160 200 250 305 370 395 Flow LPM Rated 38 45 53 53 53 53 53 53 53 53 Max 45 57 57 57 57 57 57 57 57 57 Speed RPM Rated 680 610 600 480 305 240 185 154 135 128 Max 850 800 650 520 330 270 210 180 150 140 Pressure Mpa Rated 13.8 13.8 13.8 13.8 12.4 12.4 12.4 10.3 9.0 9.0 Max 15.5 15.5 15.5 15.5 13.8 13.8 13.8 12.4 10.3 10.3 Torque Nm Rated 92 121 150 189 259 315 385 395 405 435 Max 105 137 170 213 287 348 395 465 460 485 Weight KG 6.3 6.7 7.0 7.5 7.7 8.0 8.4 8.8 9.4 9.6 Product Details Product features: Compact in design with spool valving and Gerotor Imported high pressure capacity shaft seal Wide variety of mounting flanges,shafts,ports and speed provides design flexibil

Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
