Key Benefits
- Handles whole leaf, flower and coarse blends that jam machines designed for fine cut or fannings
- Ultrasonic sealing avoids heat damage so delicate aromatics are not scorched at the seam
- 6-head electronic weigher holds fill weight to within +/-0.1 g per bag across the 1 to 10 g range
- Narrow seal edge reduces film waste compared to wide heat-sealed borders
- One operator can run the line after training instead of a hand-filling team
- Premade bag input allows faster changeover than roll-fed systems for short runs
Application Scenarios
- Tea blenders packaging single-origin whole leaf tea for retail under their own brand
- Herbal and health tea producers running short batches of multiple blends with quick format changeover
- Contract packers serving several tea brands from one line using premade bags
- Producers of regional teas like Darjeeling, Assam and Ceylon needing a visible, branded pyramid bag with string and tag
Who It Is For
- Tea blenders moving from outsourced packing to in-house pyramid bagging with string and tag
- Herbal and health tea producers whose leaf is too coarse for flat filter paper bags
- Brands that need the leaf visible through a transparent bag with a secure string and tag
- Buyers replacing an ageing machine that uses heat sealing and damages nylon film
Problems It Solves
- Coarse whole leaf bridges and jams in machines designed for cut and fibre grades
- Heat sealing melts a wide edge into nylon film and wastes material on every bag
- Hand filling gives inconsistent bag weight and cannot hold a +/-0.1 g target
- Manual string and tag attachment limits output far below a 35 to 55 bag per minute demand
- Non-food-grade film risks failing customer and retailer safety audits
Technical Features
- Ultrasonic sealing and cutting with two sealing devices for a tight narrow seam
- 6-head electronic weigher with +/-0.1 g accuracy across the 1 to 10 g range
- Accepts premade pyramid bags made from nylon, non-woven fabric, PET and PLA
- Packing roll width selectable at 120, 140, 160 or 180 mm
- Seal length selectable at 50, 60, 70 or 80 mm
- Runs on single phase 220V 50Hz at 3 kW with air supply at 0.6 MPa
Specifications
| Machine model | C88DX |
|---|---|
| Machine type | Pyramid Tea Bag Packing Machine Series |
| Packing material | Nylon, non-woven fabric, PET, PLA |
| Measuring method | 6-head electronic weigher (customizable to 8-head) |
| Filling range | 1-10 g/bag, accuracy +/-0.1 g/bag |
| Packing speed | 35-55 bags/min |
| Packing roll width | 120, 140, 160, 180 mm |
| Sealing length | 50, 60, 70, 80 mm |
| Sealing method | Sealing and cutting by ultrasonic |
| Qty of sealing device | 2 sets |
| Air supply | 0.6 MPa, air compressor can be equipped |
| Motor power | 220V, 50Hz, 3 kW |
| Dimension | 2000 x 1350 x 2450 mm (L x W x H) |
| Machine weight | 950 kg |
Packing Materials It Runs
- Nylon mesh film imported from Japan, non-toxic, heat resistant and food grade
- Non-woven fabric filter film for opaque pyramid bags
- PET film for high clarity pyramid bags
- PLA corn fibre film for 100% biodegradable transparent bags
How the Machine Works
- 1Premade pyramid bag feeding and alignment
- 26-head electronic scale weighing and filling
- 3Ultrasonic sealing by two sealing devices
- 4String and tag attachment
- 5Cutting and discharge
Quality Control Before Shipment
- F
- i
- l
- l
- i
- n
- g
- w
- e
- i
- g
- h
- t
- c
- h
- e
- c
- k
- e
- d
- a
- g
- a
- i
- n
- s
- t
- t
- h
- e
- +
- /
- -
- 0
- .
- 1
- g
- p
- e
- r
- b
- a
- g
- a
- c
- c
- u
- r
- a
- c
- y
- t
- a
- r
- g
- e
- t
- d
- u
- r
- i
- n
- g
- r
- u
- n
- -
- o
- f
- f
- S
- e
- a
- l
- i
- n
- t
- e
- g
- r
- i
- t
- y
- i
- n
- s
- p
- e
- c
- t
- e
- d
- o
- n
- t
- h
- e
- u
- l
- t
- r
- a
- s
- o
- n
- i
- c
- s
- e
- a
- m
- b
- e
- f
- o
- r
- e
- t
- h
- e
- m
- a
- c
- h
- i
- n
- e
- s
- h
- i
- p
- s
- F
- o
- o
- d
- c
- o
- n
- t
- a
- c
- t
- f
- i
- l
- m
- v
- e
- r
- i
- f
- i
- e
- d
- a
- s
- n
- o
- n
- -
- t
- o
- x
- i
- c
- n
- o
- n
- -
- b
- a
- c
- t
- e
- r
- i
- a
- h
- e
- a
- t
- r
- e
- s
- i
- s
- t
- a
- n
- t
- f
- o
- o
- d
- g
- r
- a
- d
- e
- m
- a
- t
- e
- r
- i
- a
- l
- M
- a
- c
- h
- i
- n
- e
- t
- e
- s
- t
- r
- u
- n
- w
- i
- t
- h
- t
- h
- e
- c
- u
- s
- t
- o
- m
- e
- r
- '
- s
- o
- w
- n
- t
- e
- a
- b
- e
- f
- o
- r
- e
- d
- i
- s
- p
- a
- t
- c
- h
- o
- n
- r
- e
- q
- u
- e
- s
- t
Certifications
- ISO
- CE
Customization Options
- Choice of 120, 140, 160 or 180 mm roll width to match your bag size
- Seal length set at 50, 60, 70 or 80 mm
- 6-head or 8-head electronic weigher available based on fill speed needs
- Nylon, non-woven, PET or PLA film supplied to suit your brand and compostability claim
- Air compressor supplied with the machine where site air is not available
- Voltage and plug arranged for the destination market on request
How It Compares
| Flat filter paper tea bag machine | The C88DX handles coarse whole leaf and shows the blend through the film, while filter paper suits fine cut and fannings at lower film cost |
|---|---|
| Heat sealed pyramid machine | Ultrasonic sealing keeps the edge narrow and avoids scorching nylon, at the cost of an air supply requirement |
| Manual pyramid bagging with string and tag | The C88DX replaces a hand-filling team and holds bag weight consistent, but needs a fixed footprint of 2000 x 1350 mm and an operator trained on changeover |
Use Guide
- 1Connect a clean dry air supply at 0.6 MPa and a single phase 220V 50Hz outlet
- 2Load premade pyramid bags matched to your chosen 120, 140, 160 or 180 mm width
- 3Set seal length to 50, 60, 70 or 80 mm for the bag size you are running
- 4Enter target fill weight between 1 and 10 g and calibrate the 6-head electronic weigher with your own tea
- 5Run ten sample bags and check weight and seal before starting the batch
- 6Clean the filling hopper between blends to avoid carry-over of aroma
C88DX Pyramid Tea Bag with String and Tag Packing Machine FAQ
What bag weight range can the C88DX run?
1 to 10 g per bag with an accuracy of +/-0.1 g per bag, set on the 6-head electronic weigher.
How fast does it run?
35 to 55 bags per minute depending on bag size, fill weight and how free-flowing your blend is.
Can it run biodegradable film?
Yes. It runs PLA corn fibre and 100% biodegradable transparent material as well as nylon, non-woven fabric and PET.
Do I need an air compressor?
The machine needs an air supply at 0.6 MPa. If your site has no compressed air we can equip the machine with an air compressor.
What power supply does it need?
220V 50Hz single phase, 3 kW motor power. Tell us your destination voltage and we will arrange it before shipment.
How much floor space and lifting capacity do I need?
The machine measures 2000 x 1350 x 2450 mm and weighs 950 kg, so plan the doorway height and forklift access accordingly.
Is the machine certified?
Sengong is certified to ISO and CE. Certificates are sent by email or WhatsApp on request.
