Key Benefits
- Ultrasonic sealing creates a narrow, strong seal without heat or adhesive, preserving aroma and preventing film scorching
- Volumetric cup filling ensures consistent 5 to 15 g per bag with minimal giveaway across batches
- Inner and outer bag formed and sealed in one continuous process, reducing manual handling and increasing throughput
- PLC control with human machine interface allows simple setup and real-time monitoring of fill weight and sealing parameters
- SUS304 stainless steel parts in food contact zones meet food safety standards and resist corrosion
- Built-in connector for nitrogen flushing extends shelf life by reducing oxidation in the sealed bag
Application Scenarios
- Coffee roasters packaging small-batch single-origin beans for direct-to-consumer or retail sale
- Contract packers running multiple coffee brands on one line with quick format changeover
- Roasters transitioning from manual bagging to in-house automatic packaging with consistent fill weight
- Brands requiring a premium look with a sealed outer bag and visible inner filter bag
Who It Is For
- Coffee roasters moving from outsourced packing to in-house automatic bagging
- Contract packers serving multiple coffee brands with short batch runs
- Roasters who need nitrogen flushing to extend shelf life without adding extra equipment
- Packaging teams replacing manual or semi-automatic systems with a fully integrated solution
Problems It Solves
- Manual inner and outer bagging leads to inconsistent fill weight and poor seal quality
- Heat sealing damages delicate coffee oils and can cause film degradation at the seam
- Separate machines for inner and outer bagging increase floor space and complexity
- Lack of nitrogen flushing shortens shelf life of roasted coffee in ambient conditions
- Inconsistent bag size and seal position reduce brand consistency and customer trust
Technical Features
- Ultrasonic sealing with two sealing devices for inner and outer bag, no heat or adhesive required
- Volumetric cup filling system for 5 to 15 g per bag with repeatable accuracy
- Stepper motor controlled outer bag sealing for precise bag length positioning
- PID temperature controller for stable and accurate heating in sealing zones
- PLC control system with human machine interface for easy operation and monitoring
- All food contact parts made of SUS304 stainless steel for hygiene and durability
- Optional flat cut, date printer, easy tear device, and nitrogen flush connector
- High specification components including imported cylinders for stable performance
Specifications
| Machine model | C19D |
|---|---|
| Machine type | Drip Coffee Packaging Machine Series |
| Bag type | Ultrasonic sealing |
| Packing material | PLA/Paper/Plastic, Plastic/Aluminum/Plastic, Paper/Aluminum/Plastic, Filter paper |
| Feeding system | Volumetric cup filler |
| Package range | 5-15 g per bag |
| Inner bag size | L: 50-75 mm, W: 50-90 mm |
| Outer bag size | L: 85-120 mm, W: 75-100 mm |
| Inner bag film width | 180 mm |
| Outer bag film width | 200 mm |
| Packing speed | 40-60 bags/min |
| Power supply | Single phase, 220V, 50Hz, 3.7 kW |
| Machine weight | 600 kg |
| Machine dimension | 1200 x 900 x 1900 mm (L x W x H) |
Packing Materials It Runs
- PLA/Paper/Plastic film for compostable coffee bags
- Plastic/Aluminum/Plastic film for moisture and light barrier
- Paper/Aluminum/Plastic film for premium retail appearance
- Filter paper for inner bag in direct contact with coffee
How the Machine Works
- 1Film unwinding and inner bag forming
- 2Volumetric cup filling with 5 to 15 g coffee per bag
- 3Inner bag sealing by ultrasonic device
- 4Outer bag forming and sealing with stepper motor positioning
- 5Optional nitrogen flush through reserved connector
- 6Bag discharge and optional date printing or easy tear feature
Quality Control Before Shipment
- F
- i
- l
- l
- i
- n
- g
- w
- e
- i
- g
- h
- t
- v
- e
- r
- i
- f
- i
- e
- d
- a
- g
- a
- i
- n
- s
- t
- t
- h
- e
- 5
- t
- o
- 1
- 5
- g
- r
- a
- n
- g
- e
- d
- u
- r
- i
- n
- g
- t
- e
- s
- t
- r
- u
- n
- s
- S
- e
- a
- l
- i
- n
- t
- e
- g
- r
- i
- t
- y
- c
- h
- e
- c
- k
- e
- d
- o
- n
- b
- o
- t
- h
- i
- n
- n
- e
- r
- a
- n
- d
- o
- u
- t
- e
- r
- b
- a
- g
- s
- b
- e
- f
- o
- r
- e
- s
- h
- i
- p
- m
- e
- n
- t
- F
- o
- o
- d
- c
- o
- n
- t
- a
- c
- t
- p
- a
- r
- t
- s
- c
- o
- n
- f
- i
- r
- m
- e
- d
- a
- s
- S
- U
- S
- 3
- 0
- 4
- s
- t
- a
- i
- n
- l
- e
- s
- s
- s
- t
- e
- e
- l
- w
- i
- t
- h
- n
- o
- c
- o
- n
- t
- a
- m
- i
- n
- a
- t
- i
- o
- n
- r
- i
- s
- k
- M
- a
- c
- h
- i
- n
- e
- t
- e
- s
- t
- e
- d
- w
- i
- t
- h
- c
- u
- s
- t
- o
- m
- e
- r
- '
- s
- o
- w
- n
- c
- o
- f
- f
- e
- e
- b
- e
- f
- o
- r
- e
- d
- i
- s
- p
- a
- t
- c
- h
- o
- n
- r
- e
- q
- u
- e
- s
- t
Certifications
- ISO
- CE
Customization Options
- Choice of inner and outer bag size within the 50-75 mm and 85-120 mm length range
- Film type selected from PLA/Paper/Plastic, Plastic/Aluminum/Plastic, Paper/Aluminum/Plastic, or filter paper
- Optional flat cut, date printer, easy tear device, or nitrogen flush connector added
- Power supply adjusted to local voltage and plug type on request
- Machine footprint and height verified for site access and installation
How It Compares
| Manual inner and outer bagging | The C19D replaces a hand-filling team and ensures consistent fill weight and seal quality, but requires a fixed 1200 x 900 mm footprint and trained operator |
|---|---|
| Heat sealed coffee bag machine | Ultrasonic sealing avoids film scorching and creates a narrower seal, but requires an air supply and higher initial component cost |
| Separate inner and outer bag machines | The C19D combines both processes into one line, reducing floor space and complexity, but is limited to the specified bag size range |
Use Guide
- 1Connect a clean dry air supply and single phase 220V 50Hz power outlet
- 2Load the selected film roll matching the 180 mm inner or 200 mm outer bag width
- 3Set inner and outer bag size within the 50-75 mm and 85-120 mm range using the control panel
- 4Enter target fill weight between 5 and 15 g and calibrate the volumetric cup with your coffee
- 5Run ten test bags and verify weight, seal quality, and bag positioning before batch start
- 6Clean the volumetric cup and sealing heads between different coffee types to avoid aroma carry-over
C19D Ultrasonic Seal Commercial Java Coffee Packaging Equipment FAQ
What is the fill weight range?
5 to 15 g per bag, with consistent accuracy using the volumetric cup filler
How fast does it run?
40 to 60 bags per minute, depending on bag size, fill weight, and coffee flow rate
Can it run nitrogen flushing?
Yes. A reserved connector allows connection to a nitrogen making machine to flush nitrogen into the bag
What power supply does it need?
Single phase 220V 50Hz, 3.7 kW. We can adjust voltage and plug type for your market
What film types can it use?
PLA/Paper/Plastic, Plastic/Aluminum/Plastic, Paper/Aluminum/Plastic, and filter paper
Is it easy to change bag size?
Yes. Inner and outer bag size can be adjusted within the 50-75 mm and 85-120 mm range using the control panel
How much floor space and lifting capacity do I need?
The machine measures 1200 x 900 x 1900 mm and weighs 600 kg, so plan for forklift access and doorway clearance
