Key Benefits
- Forms and seals inner and outer bags simultaneously, reducing cycle time and increasing throughput
- Stepper motor control ensures precise bag length positioning and stable sealing
- Ultrasonic sealing avoids heat damage to coffee aroma and maintains film integrity
- Volumetric cup filling delivers consistent fill weight across 5 to 15 g per bag
- SUS304 stainless steel parts in food contact zones meet food safety standards
- Reserved connector allows integration with nitrogen flushing system to extend shelf life
Application Scenarios
- Coffee roasters packaging single-origin Robusta in drip bags for direct-to-consumer e-commerce
- Contract packers running multiple coffee brands with quick format changeover between 5 to 15 g fills
- Roasters upgrading from manual packing to automated inner and outer bag sealing
- Brands requiring nitrogen flushing to preserve freshness in retail drip bags
Who It Is For
- Coffee roasters transitioning from outsourced packaging to in-house drip bag production
- Contract packers serving multiple coffee brands with short batch runs
- Brands that need consistent inner and outer bag sealing with no heat damage to coffee
- Buyers replacing older machines with unstable sealing or manual bag positioning
Problems It Solves
- Manual inner and outer bag packing causes inconsistent seal quality and high labor cost
- Inaccurate bag length positioning leads to misaligned hanging ears and poor shelf presentation
- Heat sealing damages coffee aroma and weakens film integrity on sensitive materials
- Lack of nitrogen flushing capability shortens shelf life of roasted coffee in sealed bags
- Older machines with mechanical clutches or basic controls fail to maintain consistent fill weight
Technical Features
- Ultrasonic sealing for clean, strong, heat-free closure without adhesive
- Stepper motor control for accurate bag length positioning and stable sealing
- PID temperature controller for precise heat management in sealing zones
- PLC control with human-machine interface for easy operation and parameter setting
- Volumetric cup filler for consistent 5 to 15 g per bag fill across different coffee grades
- Reserved connector for nitrogen flushing system to extend shelf life
- All food contact parts made of SUS304 stainless steel for hygiene and durability
- High specification components including imported cylinders for stable performance
Specifications
| Machine model | C19D |
|---|---|
| Machine type | Drip Coffee Packaging Machine Series |
| Bag type | Ultrasonic sealing |
| Packing material | PLA/Paper/Plastic, Plastic/Aluminum/Plastic, Paper/Aluminum/Plastic, Filter paper |
| Feeding system | Volumetric cup filler |
| Package range | 5-15 g per bag |
| Inner bag size | L: 50-75 mm, W: 50-90 mm |
| Outer bag size | L: 85-120 mm, W: 75-100 mm |
| Inner bag film width | 180 mm |
| Outer bag film width | 200 mm |
| Packing speed | 40-60 bags/min |
| Power supply | Single phase, 220V, 50Hz, 3.7 kW |
| Machine weight | 600 kg |
| Machine dimension | 1200 x 900 x 1900 mm (L x W x H) |
Packing Materials It Runs
- PLA/Paper/Plastic film for compostable drip bags
- Plastic/Aluminum/Plastic laminate for moisture and light barrier
- Paper/Aluminum/Plastic laminate for premium retail packaging
- Filter paper for inner bags in standard drip bag configurations
How the Machine Works
- 1Film unwinding and inner bag forming
- 2Volumetric cup filling with 5 to 15 g precision
- 3Inner bag sealing and positioning
- 4Outer bag forming and sealing
- 5Hanging ear attachment and final discharge
Quality Control Before Shipment
- S
- e
- a
- l
- i
- n
- t
- e
- g
- r
- i
- t
- y
- i
- n
- s
- p
- e
- c
- t
- e
- d
- o
- n
- t
- h
- e
- u
- l
- t
- r
- a
- s
- o
- n
- i
- c
- s
- e
- a
- m
- b
- e
- f
- o
- r
- e
- s
- h
- i
- p
- m
- e
- n
- t
- F
- i
- l
- l
- w
- e
- i
- g
- h
- t
- v
- e
- r
- i
- f
- i
- e
- d
- a
- c
- r
- o
- s
- s
- t
- h
- e
- 5
- t
- o
- 1
- 5
- g
- r
- a
- n
- g
- e
- d
- u
- r
- i
- n
- g
- t
- e
- s
- t
- r
- u
- n
- s
- F
- o
- o
- d
- c
- o
- n
- t
- a
- c
- t
- p
- a
- r
- t
- s
- c
- o
- n
- f
- i
- r
- m
- e
- d
- a
- s
- S
- U
- S
- 3
- 0
- 4
- s
- t
- a
- i
- n
- l
- e
- s
- s
- s
- t
- e
- e
- l
- a
- n
- d
- n
- o
- n
- -
- t
- o
- x
- i
- c
- M
- a
- c
- h
- i
- n
- e
- t
- e
- s
- t
- e
- d
- w
- i
- t
- h
- c
- u
- s
- t
- o
- m
- e
- r
- '
- s
- c
- o
- f
- f
- e
- e
- b
- e
- f
- o
- r
- e
- d
- i
- s
- p
- a
- t
- c
- h
- o
- n
- r
- e
- q
- u
- e
- s
- t
Certifications
- ISO
- CE
Customization Options
- Choice of inner and outer bag sizes within the 50-75 mm and 85-120 mm length range
- Film type selected from PLA/Paper/Plastic, Plastic/Aluminum/Plastic, Paper/Aluminum/Plastic, or filter paper
- Optional flat cut, date printer, or easy tear device added during assembly
- Reserved connector for nitrogen flushing system, ready for integration
- Power supply adjusted to destination market voltage and plug type on request
How It Compares
| Manual inner and outer bag packing | The C19D replaces a hand-filling team and ensures consistent fill weight and seal quality, but requires a fixed footprint of 1200 x 900 mm and trained operator |
|---|---|
| Heat-sealed drip bag machine | Ultrasonic sealing avoids film scorching and maintains aroma integrity, but requires an air supply and higher initial setup cost |
| Single-layer bag machine | The C19D produces both inner and outer bags in one cycle, improving efficiency, but uses more film and requires more space |
Use Guide
- 1Connect a clean dry air supply and single phase 220V 50Hz power outlet
- 2Load the selected film roll matching the inner or outer bag width (180 mm or 200 mm)
- 3Set the bag length and fill weight using the PLC interface and calibrate the volumetric cup
- 4Install optional devices such as date printer or easy tear feature if required
- 5Run a test batch of 10 bags and check fill weight, seal quality, and ear alignment
- 6Clean the filling cup and sealing heads between different coffee types to avoid cross-contamination
C19D Hanging Ear Robusta Coffee Drip Bag Packing Machine FAQ
What is the fill weight range for the C19D?
It runs 5 to 15 g per bag using a volumetric cup filler, with consistent accuracy across the range.
How fast does it pack bags?
The machine runs at 40 to 60 bags per minute, depending on bag size and coffee flow rate.
Can it run nitrogen flushing?
Yes. It has a reserved connector to link with a nitrogen making machine for bag flushing to extend shelf life.
What film types can it use?
It supports PLA/Paper/Plastic, Plastic/Aluminum/Plastic, Paper/Aluminum/Plastic, and filter paper.
What power supply does it need?
Single phase 220V 50Hz, 3.7 kW. We can adjust the voltage and plug type for your market.
Is the machine certified?
Sengong is certified to ISO and CE. Certificates are available on request via email or WhatsApp.
What floor space and lifting access do I need?
The machine measures 1200 x 900 x 1900 mm and weighs 600 kg, so plan for forklift access and doorway clearance.
