Mini Home Office Paper Bubble Machine
The SD-PB300 and SD-PB500 models convert fanfold or roll paper into paper bubble cushioning in a compact, portable unit. Designed for small-scale use, it produces 300mm or 500mm wide bubble paper with a consistent Φ12x5mm cell size at speeds from 1 to 10 m/min. The machine operates on 100-230V power and can be controlled manually with a foot switch, allowing on-demand production of protective packaging for small warehouses, home offices, and local delivery points.
- Produces paper bubble cushioning on demand without needing to stock finished rolls
- Compact size and low weight allow placement in tight spaces like home offices or small warehouses
- Adjustable speed from 1 to 10 m/min lets users match output to immediate packing needs
- Foot switch control enables hands-free operation during continuous use
- Runs on 100-230V power, suitable for use in multiple countries without voltage conversion
- No cutting blade on base models allows simple operation with minimal setup
Why Buyers Choose It
- Plastic bubble wrap is not allowed in some local or regional delivery zones
- Buying pre-made paper bubble rolls requires inventory and long lead times
- Manual wrapping with tape and loose padding is inconsistent and time-consuming
- Small operations lack space or budget for large industrial converting machines
- Need to produce cushioning only when needed without overstocking
Who Runs This Machine
- Home office operators managing their own shipping and packaging
- Small e-commerce businesses with limited storage and low volume output
- Retailers or service providers needing on-site cushioning for small parcels
- Packaging teams in small warehouses with no dedicated converting line
Where This Machine Is Used
- Home office users creating custom bubble paper for shipping small packages
- Small e-commerce sellers producing protective packaging for local delivery
- Express delivery bases making bubble wrap on site for same-day shipments
- Retail stores or chain outlets generating cushioning for fragile in-store items
- Small batch producers needing a low-cost way to test paper bubble performance
Features And Specifications
Technical features
- Converts fanfold or roll paper into paper bubble cushioning with a Φ12x5mm cell size
- Adjustable speed from 1 to 10 m/min for controlled output
- Foot switch control allows hands-free operation during continuous runs
- No cutting blade on base models (SD-PB300 and SD-PB500) reduces maintenance
- Cutting blade available as an option on Pro models (SD-PB300 Pro and SD-PB500 Pro)
- Power supply compatible with 100-230V, suitable for global use
- Compact structure with minimal footprint for space-constrained environments
- In-line feeding supports both fanfold and roll paper formats
Specifications
| Machine model | SD-PB300, SD-PB300 Pro, SD-PB500, SD-PB500 Pro |
|---|---|
| Max paper width | 300 mm (SD-PB300, SD-PB300 Pro), 500 mm (SD-PB500, SD-PB500 Pro) |
| Feeding paper | Fanfold or roll paper (80 gsm usually) |
| Max paper diameter | 250 mm for roll paper |
| Working speed | 1-10 m/min adjustable |
| Bubble size | Φ12 x 5 mm depth |
| Power supply | 100-230 V / 120 W (SD-PB300), 100-230 V / 200 W (SD-PB300 Pro, SD-PB500, SD-PB500 Pro) |
| Machine weight | 22 kg (SD-PB300), 25 kg (SD-PB300 Pro), 40 kg (SD-PB500), 45 kg (SD-PB500 Pro) |
| Machine size | 420 x 460 x 270 mm (SD-PB300), 480 x 600 x 270 mm (SD-PB300 Pro), 660 x 600 x 270 mm (SD-PB500), 700 x 750 x 270 mm (SD-PB500 Pro) |
How The Machine Runs
Materials
- Fanfold or roll paper (80 gsm usually)
- Kraft paper suitable for bubble formation
- Optional laminated backing paper for added strength or moisture resistance
Quality Control
- Speed adjustment ensures consistent bubble formation across the width
- Manual inspection of the first few metres verifies cell size and spacing
- Foot switch control allows immediate stop if misalignment or jam occurs
- Power input range (100-230V) ensures stable operation in different electrical environments
Customisation
- Cutting blade can be added to SD-PB300 and SD-PB500 models upon request
- Power supply can be adjusted to match local voltage and frequency
- Machine size and weight are fixed per model; no structural changes available
- Paper width is limited to 300mm or 500mm based on model; no wider options
Certifications
- ISO9001:2000 certificate obtained in 2005
- CE certificate obtained in 2006
How It Compares
| Buying pre-made paper bubble rolls | On-demand production avoids inventory costs and overstocking, but requires operator time and paper input |
|---|---|
| Full-sized industrial paper bubble machines | This machine is smaller and cheaper but limited to low output and manual operation |
| Plastic bubble wrap machines | Paper bubble is recyclable and accepted where plastic is restricted, though it has lower impact resistance |
Running It On Your Floor
- Ensure the paper roll is within 250 mm diameter and 80 gsm weight for best results
- Start at the lowest speed (1 m/min) and increase gradually to avoid web misalignment
- Use the foot switch to control the run length and stop the machine when needed
- Check the bubble formation on the first 1–2 metres before continuing the full roll
- Clean the forming rollers regularly to prevent paper dust buildup affecting cell quality
Mini Home Office Paper Bubble Machine FAQ
What paper weight does the machine use?
It is designed for fanfold or roll paper with a typical weight of 80 gsm.
How fast does it run?
Speed is adjustable from 1 to 10 m/min, depending on the paper and desired output.
Can I use this machine with different paper widths?
The SD-PB300 handles up to 300 mm width; the SD-PB500 handles up to 500 mm width.
Does it have a cutting blade?
No on base models (SD-PB300, SD-PB500); yes on Pro models (SD-PB300 Pro, SD-PB500 Pro).
What power supply does it use?
100-230V, 120W for SD-PB300, 200W for Pro and SD-PB500 models.
Is it portable?
Yes, the machine weighs 22–45 kg and has a compact footprint suitable for small spaces.
Do you have certifications?
Wenzhou Snda Machinery holds an ISO9001:2000 certificate obtained in 2005 and a CE certificate obtained in 2006.
