The Sinotruk HOWO 10m3 fresh water tanker is a 5 ton capacity water transport vehicle built on a 6x2 Foton BJ5089 chassis with a 140 HP diesel engine and 6 shift manual gearbox. It is designed for reliable delivery of potable and industrial water in construction, agriculture, drought relief, and municipal sanitation operations where access to fixed water sources is limited. The truck features a self-suction pump capable of 90 metre head and 20 cubic metres per hour flow, enabling rapid filling from open sources and efficient discharge through front, rear, and side spray nozzles or a 30 metre vertical water cannon.
| Chassis | Foton BJ5089 6x2 |
|---|---|
| Engine | 140 HP diesel, Xichai HW-185 |
| Gearbox | 6 files manual |
| Tank Volume | 5 m³ (5 tons) |
| Pump Flow | 20 m³/h |
| Pump Head | 90 m |
| Suction Lift | 7 m vertical |
| Water Cannon Reach | 30 m vertical |
| Spray Width | 15 m |
| Overall Size | 7600 x 2400 x 2800 mm |
| Tank Size | 3.4 x 1.8 x 1.2 m |
| Curb Weight | 4000 kg |
| Load Capacity | 4085 kg |
| Total Mass | 8280 kg |
| Number of Passengers | 3 |
| Wheelbase | 3360 mm |
| Tire Size | 7.50R16 (7 including spare) |
| Fuel Type | Diesel |
| Emission Standards | GB17691-2005 Country V, GB3847-2005 |
| Lead Time | 20 days |
| Shipping Port | China main port |
| Payment | T/T |
| 4x2 water tanker with 3 m³ tank | Lower capacity and shorter reach but better fuel efficiency and easier handling in urban areas |
|---|---|
| Water truck with no self-suction pump | Cannot fill from open sources without external pumps, requiring more time and equipment |
| Water tanker with fixed spray nozzles only | Limited to rear spray and no high reach capability for trees or tall structures |
Generally 20 days after the advance payment is received. The exact date depends on chassis availability and equipment list.
T/T with 30 percent deposit and 70 percent before delivery. We send photos and videos of the finished truck before you pay the balance.
Yes. The truck can be fitted with a pesticide spraying system. Provide your spray volume and chemical type for system design.
By Ro-ro or bulk ship from a China main port. Trade terms can be EXW, FOB, CFR, or CIF.
The whole vehicle is guaranteed for one year and core parts for two years. Our overseas engineers make regular return visits and provide technical training and manuals before delivery.
Yes. Send your spray pattern, reach, and flow requirements and we will configure the front, rear, and side nozzles accordingly.
Send us your destination port and we will quote price, lead time and freight.
