Power Line Hardware

QP Type Ball Eyes For Transmission Line

Ball eyes, Overhead line fittings, best quality, best price!

QP type ball eyes for transmission line Material: Hot-dip galvanized drop forged steel.

Request A Quote Email Us Request A Sample

GroupTransmission and Distribution

CategoryPower Line Hardware

StandardsIEC and GB

CustomisationOEM and non standard accepted

Overview Specifications Gallery Ordering FAQ Related

Overview

QP Type Ball Eyes for Transmission Line Description

Ball Eyes QP Type

Specifications

Codes Ranges and Dimensions

Figures below are reproduced from the CROP catalogue for this item.

Type	Dimensions in millimeters	Designatedsize of coupling	Specified Failure Load(kN)
d	Ø	b	d1	h
Q-7	17	22	16	33.3	50	16	70
QP-7	17	20	16	33.3	50	16	70
QP-10	17	20	16	33.3	50	16	100
QP-12	17	24	17	33.3	60	16	120
QP-12G	17	24	17	33.3	60	16	120
QP-16	21	26	20	41	60	20	160
QP-20	25	30	24	49	80	24	200
QP-21D	21	30	24	41	70	20	210
QP-30	25	39	28	49	80	24	300
QP-2120G	21	26	20	41	80	20	210
QP-3224G	25	33	28	49	80	24	320
QP-4228G	29	39	32	57	100	28	420

Product Images

QP Type Ball Eyes For Transmission Line view

Ordering and Support

From Enquiry To Delivered Order

Send The Requirement

Item code, conductor or cable size and quantity, or a drawing and a photograph for a non standard part.

Quotation

Price, packing, carton quantity and lead time are confirmed against the catalogue reference.

Sample or Tooling

Samples are sent for approval. Parts that need a new mould go through the in house mould division.

Production and Shipment

Production to IEC and GB standards, then packing and shipment on the agreed terms.

Answers

Frequently Asked Questions

How do I choose the right size?

Match your conductor or cable size against the range column in the specification table on this page, then quote the code on that row. If the size falls between two rows, send both figures with your enquiry and the correct item will be confirmed.

Is QP Type Ball Eyes For Transmission Line available as a sample before a production order?

Yes. Ask for a sample by WhatsApp on 0086 138 6832 9796 or by email and the item, the packing and the lead time for a full order will be confirmed together.

Which standards do CROP products follow?

All CROP products are made to comply with IEC and GB standards. Where a project calls for a national or utility specification, send the standard reference with your enquiry and the matching item will be quoted.

Can items be produced to our own drawing?

Yes. Non-standard and OEM orders are part of the normal range. Send the drawing, a picture, the weight or the written specification to [email protected] or by WhatsApp and a quotation will be prepared against your requirement. CROP also runs its own mould division for plastic, SMC and stamped parts.

How do I obtain the PDF catalogue?

The catalogue is issued on request. Ask for the section you need by email or WhatsApp on 0086 138 6832 9796 and the PDF will be sent back to you. The catalogue page lists every section that is available.
