Power Line Hardware

Adjuster Plates, PT

ADJUSTER PLATES Type Dimensions in Millimeters Specified Failure Load(kN) L1 L2 M d b C L PT-7 45 60 16 18 16 18

ADJUSTER PLATES Type Dimensions in Millimeters Specified Failure Load(kN) L1 L2 M d b C L PT-7 45 60 16 18 16 18

Request A Quote Email Us Request A Sample

GroupTransmission and Distribution

CategoryPower Line Hardware

StandardsIEC and GB

CustomisationOEM and non standard accepted

Overview Specifications Gallery Ordering FAQ Related

Overview

Adjuster Plates, PT Description

ADJUSTER PLATES

Specifications

Codes Ranges and Dimensions

Figures below are reproduced from the CROP catalogue for this item.

Type	Dimensions in Millimeters	Specified Failure Load(kN)
L1	L2	M	d	b	C	L
PT-7	45	60	16	18	16	18	225	345	70
PT-10	50	65	18	20	16	20	225	300	100
PT-12	60	75	22	24	16	24	300	465	120
PT-16	65	50	24	26	18	26	325	505	160
PT-21	70	60	27	30	26	30	350	550	210
PT-30	80	70	36	39	32	38	400	630	300
PT-50	160	80	42	45	38	40	740	1280	500
PT-60	180	90	48	51	42	44	820	1390	600

Product Images

Ordering and Support

From Enquiry To Delivered Order

Send The Requirement

Item code, conductor or cable size and quantity, or a drawing and a photograph for a non standard part.

Quotation

Price, packing, carton quantity and lead time are confirmed against the catalogue reference.

Sample or Tooling

Samples are sent for approval. Parts that need a new mould go through the in house mould division.

Production and Shipment

Production to IEC and GB standards, then packing and shipment on the agreed terms.

Answers

Frequently Asked Questions

How do I choose the right size?

Match your conductor or cable size against the range column in the specification table on this page, then quote the code on that row. If the size falls between two rows, send both figures with your enquiry and the correct item will be confirmed.

Is Adjuster Plates, PT available as a sample before a production order?

Yes. Ask for a sample by WhatsApp on 0086 138 6832 9796 or by email and the item, the packing and the lead time for a full order will be confirmed together.

Which standards do CROP products follow?

All CROP products are made to comply with IEC and GB standards. Where a project calls for a national or utility specification, send the standard reference with your enquiry and the matching item will be quoted.

Can items be produced to our own drawing?

Yes. Non-standard and OEM orders are part of the normal range. Send the drawing, a picture, the weight or the written specification to [email protected] or by WhatsApp and a quotation will be prepared against your requirement. CROP also runs its own mould division for plastic, SMC and stamped parts.

How do I obtain the PDF catalogue?

The catalogue is issued on request. Ask for the section you need by email or WhatsApp on 0086 138 6832 9796 and the PDF will be sent back to you. The catalogue page lists every section that is available.

Next Step

Get A Price For Adjuster Plates, PT

Send the code, the size and the quantity. Drawings for non standard versions are welcome.

Chat on WhatsApp Email Us
