Fully Automatic Pet Poop Bag Making Machine
This machine machine converts a roll of poly film into pre-opened pet poop bags on a roll in a single automated process. It handles film thickness from 0.01 to 0.015 mm and produces bags between 100 and 500 mm in length at speeds of 30 to 220 pieces per minute. The machine uses photoelectric automatic tracking, microcomputer length setting, and automatic counting to ensure consistent bag formation and reliable operation. This allows a packaging producer to make its own pet waste bags instead of buying them from a supplier.
- Produces pre-opened pet poop bags on a roll for direct feeding into autobagging systems
- Automated photoelectric tracking and length setting reduce misfeeds and waste
- Speed adjustable from 30 to 220 pieces per minute to match downstream line capacity
- Automatic counting and high-limit stopping prevent overproduction and material waste
- Eliminates the need to purchase finished bags, reducing supply chain dependency
Why Buyers Choose It
- Bought-in pet poop bags carry a supplier margin and long replenishment cycles
- Manual bagging or semi-automated systems are slow and inconsistent for high-volume lines
- Inconsistent bag length or misalignment causes jams in automated bagging equipment
- Lack of control over bag design and core size when sourcing from third parties
Who Runs This Machine
- Pet product packers looking to convert poly film into on-roll bags
- Poly bag makers adding a new product line with minimal line changeover
- Fulfilment operators automating bagging for pet care products
- Packaging converters with existing film slitting or roll handling capability
Where This Machine Is Used
- Pet product manufacturers producing branded poop bags for retail or private label
- 3PL and e-commerce fulfilment centres running roll-fed bagging lines for pet supplies
- Poly bag makers expanding into pet waste packaging with a high-speed automated line
- Packers supplying pre-opened bags to pet stores or veterinary clinics
Features And Specifications
Technical features
- Photoelectric automatic tracking ensures accurate bag positioning
- Microcomputer length setting allows precise control over bag dimensions
- Automatic counting and high-limit stopping stop the machine at the set quantity
- Automatic alarm activates when the set count is reached
- High compensation accuracy maintains consistent bag length and alignment
- Main motor powered by 1.5 kW for stable operation at variable speeds
- Roll feeding width of 240 mm accommodates standard poly film reels
- Finished bag width is 60 mm, suitable for standard pet waste bag applications
Specifications
| Film thickness | 0.01-0.015 mm |
|---|---|
| Production speed | 30—220 pcs/min |
| Bag length | 100-500 mm |
| Paper tube ID/OD | 8 mm / 10 mm |
| Main motor power | 1.5 kW |
| Roll feeding width | 240 mm |
| Finished bag width | 60 mm |
| Machine size | 5.5 x 1.2 x 1.6 m (L x W x H) |
How The Machine Runs
Materials
- Poly film rolls from 0.01 to 0.015 mm thickness
- Standard 240 mm wide film suitable for pet waste bag applications
- Paper core with 8 mm ID and 10 mm OD for rewinding finished bags
Quality Control
- Photoelectric sensor ensures consistent bag positioning across the roll
- Microcomputer length setting maintains uniform bag size within the specified range
- Automatic counting and high-limit stopping prevent overproduction and core overfill
- Machine is tested with customer film before shipment to verify operation
Customisation
- Bag length and count can be set via microcomputer control for different batch sizes
- Power supply can be built to match the voltage and frequency of the destination country
- Paper core size can be adjusted to 8 mm ID / 10 mm OD or other standard sizes on request
- Optional modifications to film guide or tension system may be made for specific film types
Certifications
- ISO9001:2000 certificate obtained in 2005
- CE certificate obtained in 2006
How It Compares
| Buying finished pet poop bags on a roll | Converting in house removes the supplier margin but requires inventory of poly film and machine investment |
|---|---|
| Semi-automatic bag making machines | This machine is fully automatic with photoelectric tracking and counting, reducing operator dependency and increasing consistency |
| Manual bagging | Automated production is faster and more repeatable, especially at volumes above 100 bags per minute |
Running It On Your Floor
- Ensure the poly film roll is properly loaded and aligned on the unwinding stand
- Set the desired bag length and count using the microcomputer control panel
- Start the machine at low speed and check the first few bags for correct length and alignment
- Adjust the photoelectric sensor if tracking drift is observed
- Monitor the rewinding process to ensure even tension and no core overfill
Fully Automatic Pet Poop Bag Making Machine FAQ
What film thickness can the machine handle
It is designed for poly film between 0.01 and 0.015 mm thickness.
How fast can it run in production
Speed is adjustable from 30 to 220 pieces per minute depending on film type and bag length.
What power supply do you build it for
Standard power is 1.5 kW, and we build to the voltage and frequency of your country on request.
What is the machine footprint for installation
The machine is 5.5 x 1.2 x 1.6 m (L x W x H), so plan a level floor with access for handling equipment.
Can it make bags of different lengths
Yes, bag length can be set between 100 and 500 mm using the microcomputer control panel.
What paper core size does it use
It uses a paper core with 8 mm inner diameter and 10 mm outer diameter, standard for roll-fed bagging.
