SW Series String Wound Filter Cartridges

SW Series String Wound Filter Cartridges SW series string wound filter cartridges consist of continuous fiber yarn, which is wound around support core. The wound pattern and strength form the filter with various pore size. Filter media are.

Range: Filter Cartridges
Type: Depth Filter Cartridges
Supplier: Shanghai Liquapure Filtration Co., Ltd, Shanghai, China
Customisation: Micron rating, length and end cap specified to your housing
Photographs on file: 1

Call +86 137 6415 7715 Contact Details

Details

Full Description

SW Series String Wound Filter Cartridges

SW series string wound filter cartridges consist of continuous fiber yarn, which is wound around support core. The wound pattern and strength form the filter with various pore size. Filter media are available with polypropylene, bleached cotton, and glass fiber for various applications and temperature requirements

PP string wound filter

Features

Various fiber and core materials option
Suitable for liquid, compressed air, gases
Precision winding patterns ensure ratings

Applications

Pre-RO
Oils
Petrochemicals
Paints/inks
Solvents
Chemicals

Dimensions

Outer Diameter: 63mm, 110mm
Inner Diameter: 28mm, 30mm
Length: 5”~60”

Materials of Construction

Core: PP, Tin, SS304, SS316L
Media: PP, Bleached cotton, fiberglass
O-rings: EPDM, Buna, Silicone, Viton

Operating Parameters

Max. Temperature: PP 80℃, cotton 120℃, glass fiber 200℃
Max. Differential Pressure: 2.4 bar @ 21℃
Recommend Change-out：1.4 bar

Ordering Information e.g.: SWP-5-10-P-8-S

Code

Media

Micron

Length

Core

Adapter

O-rings

P=PP

C=cotton

G=Glass fiber

…

200

5”

10”

20”

…

70”

P=PP

T=tin

S4=SS304

S6=SS316L

N=None

2=226/flat

3=222/flat

7=226/fin

8=222/fin

E=EPDM

V=Viton

B=Buna

S=Silicone

FAQ

Questions About This Product

Will this fit my existing housing

Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.

Which micron ratings and lengths are available

Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.

What is the production capacity

Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.

Which industries is this used in

Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.

How do I get a quotation

Call +86 137 6415 7715 with the specification and the quantity you need.
