PS Series Melt Blown Filter Cartridges

PS Series Melt Blown Filter Cartridges PS series melt blown filter cartridges adopt SGS & RoHS approved polypropylene material to be compliance with FDA CFR Title 21 food contact requirements. The 3-layer graded density structure enhance.

Range: Filter Cartridges
Type: Depth Filter Cartridges
Supplier: Shanghai Liquapure Filtration Co., Ltd, Shanghai, China
Customisation: Micron rating, length and end cap specified to your housing
Photographs on file: 1

Call +86 137 6415 7715 Contact Details

Details

Full Description

PS Series Melt Blown Filter Cartridges

PS series melt blown filter cartridges adopt SGS & RoHS approved polypropylene material to be compliance with FDA CFR Title 21 food contact requirements. The 3-layer graded density structure enhance dirt holding capacity, filtration efficiency and at least 1.5 times filter life than traditional single layer spunbonded filters.

PSS is the most common spun filter with smooth surface for both industrial and drinking water filtration, PSF is designed with pinstripe appearance and increase surface area by 35%, PSG is designed with 30 broad grooves and its surface is 60% enlarged, PSL series using the latest material and technology for extremely large surface area and continuous fiber to avoid fiber release for critical applications.

PP melt blown filter

Features

3-layer graded density structure
High dirt holding capacity
High filtration efficiency
Long service life

Applications

Pre-RO
Desalination
Chemicals
Beverage and Food
Electronical
Pharmacy

Dimensions

Outer Diameter: 63mm, 110mm
Inner Diameter: 28mm, 25mm, 30mm
Length: 5”~60”

Materials of Construction

Core: Polypropylene option
Media: Polypropylene, Nylon
O-rings: EPDM, Buna, Silicone, viton

Operating Parameters

Max. Temperature: PP 60℃, Nylon 120℃
Max. Differential Pressure: 2.5 bar @ 21℃
Recommend Change-out：1.5 bar

Ordering Information e.g.: PSS-1-10-P-N-N

Code

Micron

Length

Media

Core

Adapter

O-rings

PSS

PSF

PSG

PSL

0.5

25…

5”

10”

20”

…

60”

P=PP

N=Nylon

N=None

P=PP

N=None

2=226/flat

3=222/flat

7=226/fin

8=222/fin

E=EPDM

V=Viton

B=Buna

S=Silicone

FAQ

Questions About This Product

Will this fit my existing housing

Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.

Which micron ratings and lengths are available

Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.

What is the production capacity

Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.

Which industries is this used in

Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.

How do I get a quotation

Call +86 137 6415 7715 with the specification and the quantity you need.
