3M Groove filter cartridges
3M Groove filter cartridges PS Series Melt Blown Filter Cartridges PS series melt blown filter cartridges adopt SGS & RoHS approved polypropylene material to be compliance with FDA CFR Title 21 food contact requirements. The 3-layer graded.
- Range
- Filter Cartridges
- Supplier
- Shanghai Liquapure Filtration Co., Ltd, Shanghai, China
- Customisation
- Micron rating, length and end cap specified to your housing
- Photographs on file
- 1
Details
Full Description
3M Groove filter cartridges
PS Series Melt Blown Filter Cartridges
PS series melt blown filter cartridges adopt SGS & RoHS approved polypropylene material to be compliance with FDA CFR Title 21 food contact requirements. The 3-layer graded density structure enhance dirt holding capacity, filtration efficiency and at least 1.5 times filter life than traditional single layer spunbonded filters.
3M groove filter
PSS is the most common spun filter with smooth surface for both industrial and drinking water filtration, PSF is designed with pinstripe appearance and increase surface area by 35%, PSG is designed with 30 broad grooves and its surface is 60% enlarged, PSL series using the latest material and technology for extremely large surface area and continuous fiber to avoid fiber release for critical applications.
Features
-
3-layer graded density structure
-
High dirt holding capacity
-
High filtration efficiency
-
Long service life
Applications
-
Pre-RO
-
Desalination
-
Chemicals
-
Beverage and Food
-
Electronical
-
Pharmacy
Dimensions
-
Outer Diameter: 63mm, 110mm
-
Inner Diameter: 28mm, 25mm, 30mm
-
Length: 5”~60”
Materials of Construction
-
Core: Polypropylene option
-
Media: Polypropylene, Nylon
-
O-rings: EPDM, Buna, Silicone, viton
Operating Parameters
-
Max. Temperature: PP 60℃, Nylon 120℃
-
Max. Differential Pressure: 2.5 bar @ 21℃
-
Recommend Change-out：1.5 bar
Ordering Information e.g.: PSS-1-10-P-N-N
__________________________________________________________________________________________________________________________________________
Code |
Micron |
Length |
Media |
Core |
Adapter |
O-rings |
PSSPSFPSGPSL |
0.5151025… |
5”10”20”…60” |
P=PPN=Nylon |
N=NoneP=PP |
N=None2=226/flat3=222/flat7=226/fin8=222/fin |
E=EPDMV=VitonB=BunaS=Silicone |
FAQ
Questions About This Product
Will this fit my existing housing
Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.
Which micron ratings and lengths are available
Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.
What is the production capacity
Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.
Which industries is this used in
Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.
How do I get a quotation
Call +86 137 6415 7715 with the specification and the quantity you need.
