Submerged UF Modules for MBR and MCR

Submerged PVDF UF modules are designed for MBR and MCR. The module features in high mechanical strength, high flux, and long service life. Reinforced hydrophilic PVDF membrane is excellent for chemical compatibility and low fouling capacity. The technology is widely used in wastewater, greywater, landfill leachate of municipal and industrial water treatmen MBR

MBR

Specifications Model MBR20 MBR25 MBR30

Membrane Area(㎡) 20 25 30

Dimension(mm) 540×1500 785×1500 1250×2000

Connection DN20 DN32 DN32

Filtrate flux(l/m2/hr) ＜ 25

Material Hydrophilic PVDF

Adhesive Materia Epoxy resin

Pipe material ABS

Operation conditions Operating Mode Negative Pressure

Max. TMP Pressure(kpa) 50

Rec. TMP Pressure(kpa) ＜35

Max. Backwash Pressure(kpa) 100

Temperature Range 5~45°C

PH Range 2-10 Cleaning

5-9 Operating

MLSS 6000~10000 mg/L

Permeate SS ≤5mg/L

Aeration ＜ 4 Nm³/h

Back wash frequency 2-4 days

Off line wash frequency 6 -12months
