MBR membranes

Submerged UF Modules for MBR and MCR Submerged PVDF UF modules are designed for MBR and MCR. The module features in high mechanical strength, high flux, and long service life. Reinforced hydrophilic PVDF membrane is excellent for chemical.

Range: UF Membranes
Supplier: Shanghai Liquapure Filtration Co., Ltd, Shanghai, China
Customisation: Micron rating, length and end cap specified to your housing
Photographs on file: 1

Call +86 137 6415 7715 Contact Details

Details

Full Description

Submerged UF Modules for MBR and MCR

Submerged PVDF UF modules are designed for MBR and MCR. The module features in high mechanical strength, high flux, and long service life. Reinforced hydrophilic PVDF membrane is excellent for chemical compatibility and low fouling capacity. The technology is widely used in wastewater, greywater, landfill leachate of municipal and industrial water treatment.

MBR membrane

Ordering Information

______________________________________________________________________________________

Specifications	Model	MBR20	MBR25	MBR30
	Membrane Area(㎡)	20	25	30
	Dimension(mm)	540×1500	785×1500	1250×2000
	Connection	DN20	DN32	DN32
	Filtrate flux(l/m2/hr)	＜ 25
	Material	Hydrophilic PVDF
	Adhesive Materia	Epoxy resin
	Pipe material	ABS
Operation conditions	Operating Mode	Negative Pressure
	Max. TMP Pressure(kpa)	50
	Rec. TMP Pressure(kpa)	＜35
	Max. Backwash Pressure(kpa)	100
	Temperature Range	5~45°C
	PH Range	2-10 Cleaning
		5-9 Operating
	MLSS	6000~10000 mg/L
	Permeate SS	≤5mg/L
	Aeration	＜ 4 Nm³/h
	Back wash frequency	2-4 days
	Off line wash frequency	6 -12months

FAQ

Questions About This Product

Will this fit my existing housing

Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.

Which micron ratings and lengths are available

Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.

What is the production capacity

Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.

Which industries is this used in

Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.

How do I get a quotation

Call +86 137 6415 7715 with the specification and the quantity you need.
